3.1 FRONT PANEL
1
2
37
30
29
28
1. MAIN VOLUME sets the volume for the main outputs and the headphones output.
2. [GLOBAL SETTINGS]
SAVE PROJECT menu. A long press opens the LOAD PROJECT menu.
3. QUICK PERF AMOUNT sets the amount of the chosen performance macro.
4. [QPER] key. Used together with the [TRIG 1–10] keys to select which performance macro that should be
controlled by the QUICK PERF AMOUNT knob. The secondary function mutes the performance macros.
5. TRACK LEVEL sets the overall volume level of the active track. Also used for scrolling in menus and
setting various parameter values. The secondary function opens the SOUND BROWSER.
6. [TEMPO]
opens the TEMPO menu. [FUNC] + [TEMPO] makes it possible to tap the o.
7. [YES] key. Used for entering sub-menus and for confirming choices.
8. [NO] key. Used for exiting an active menu and backing one step.
9. Screen.
10. The [ARROW] keys. Used for menu navigation. They are called [UP], [DOWN], [LEFT] and [RIGHT].
11. [ARP] key. Opens the ARPEGGIATOR menu that contains arpeggiator settings for the active track.
12. [NOTE] key. Opens the NOTE menu that contains general note settings for the active track.
13. [PARAMETER] keys switch between the PARAMETER pages of the active track. The text on the keys
indicates the pages for the four synth tracks. The first row of white text under the keys is for the FX
track pages and the second row of white text indicates the CV track pages. A second press on the
[PARAMETER] key will in some cases open secondary PARAMETER pages. The [PARAMETER] keys
indicate if the first (red) or second (green) page is active.
14. [OCT-/+] keys transpose the [KEYBOARD] keys. <OCTAVE> LEDs shows the current transposition.
15. DATA ENTRY knobs. Used for adjusting parameters.
16. The [TRACK] keys select the active track. Four synth tracks, one FX track, and one CV track are avail-
able. They are called [T1–4], [FX], and [CV]. [FUNC] + [TRACK] mutes a track. The color of the [TRACK]
12
3
4
5
6 7
8
31
32
33
34
35
36
27
26
25
opens the GLOBAL SETTINGS menu. The secondary function opens the
9
10
11
12
24
23
13
14
15
16
22
17
18
19
20
21
