Table A.4: CN6: SATA

Part Number
Footprint
Description
Pin
1
2
3
4
5
6
7
Table A.5: CN7:SATA POWER
Part Number
Footprint
Description
Pin
1
2
3
4
5
UTC-315 User Manual
1654004659
WF_5P_98_BOX_D
WAFER BOX 5P 2.5mm 180D(M) DIP 2503-WS-5
Pin name
GND
TX+
TX-
GND
RX+
RX-
GND
1659254005
SATA_7P_WATM-07DBN4A3B8UW_D
Serial ATA 7P 1.27mm 180D(M) DIP WATM-07DBN4A3B8
Pin name
+3.3V
GND
+5V
GND
+12V
28
