Chapter 3 – Specifications

Technical Specifications

Category
General
Standards
Frequency Bands
Speed
Data Speed
Interface, Ports
USB Interface
Serial Modem Interface
Ports
Physical Description
Weight
Dimensions
Connectors
Antenna Connector
SIM Holder
Environment
Operating Temperature -40° C to +85° C
Storage Temperature
Humidity
Power Requirements
Operating Voltage
Input Power
IP, M2M, SMS
Supported IP Protocols
M2M Applications
SMS
SocketModem Cell HSPA and SocketModem iCell HSPA MTSMC-H5 Device Guide
Description
Penta-band HSPA+ 21
Quad-band GSM/GPRS/EDGE
SMS is based on CS/Packet-Switched (PS) domain of GSM and WCDMA
USB Interface is CDC-ACM compliant
Penta-band HSPA+: 850/900/1700/1900/2100 MHz
Quad-band GSM/GPRS/EDGE: 850/900/1800/1900 MHz
HSPA+: Up to 21.0 Mbps downlink/5.76 Mbps uplink
EDGE: Up to 296 Kbps downlink/236.8 Kbps uplink
GPRS: Up to 107 Kbps downlink/85.6 Kbps uplink
MI builds: USB 2.0 full speed
High speed on other builds: 480 Mbps
Up to 921.6 Kbps
GPIO ports – MI builds only
0.4 oz. (10g)
Refer to mechanical drawing for details.
3 surface mount UFL: cellular, GPS, RX diversity
Standard 1.8V and 3V.
-40° C to +85° C
20%-90% RH, non-condensing
3.3V - 5V
3.3 - 5VDC
DNS resolve, FTP client, Ping, POP3 client, PPP (dialout), SMTP client, TCP RAW client &
server
Universal IP models: Automatic connect/reconnect, device monitor, modem emulation,
Ping & TCP keep alive, wake-up on caller ID, wake-up on ring, GPS tracking (GP model
only)
Point-to-Point messaging
Mobile-Terminated SMS
Mobile-Originated SMS
