CHAPTER 6 –APPLICATION NOTES
LED 4 – GPS Status – GP Builds
LED 4 Signal GPS Status LED
OFF No power to the unit.
ON Continuously lit
Blinking

RF Performances

RF performances are compliant with the ETSI recommendation 05.05 and 11.10. The module's radio transceiver
meets the requirements of 3GPP Release 5 & 6. All values indicated are conducted.

Receiver Features

Category
GSM 850 Sensitivity
E-GSM 900 Sensitivity
DCS 1800 Sensitivity
PCS 1900 Sensitivity
UMTS Band I 2100 Sensitivity
UMTS Band II 1900 Sensitivity
UMTS Band V 850 Sensitivity
UMTS Band VI 800 Sensitivity

Transmitter Features

Category
Maximum output power (GSM 850 / GSM 900)
Maximum output power (DCS 1800 / PCS 1900)
Maximum output power (UMTS Band II 1900, V 850, &VI 800)
Maximum output power (UMTS Band I 2100)

RF Connection and Antenna

The RF connector on the SocketModem is a UFL standard type. See the Universal Socket Developer Guide for
antenna details.
29
Satellite not acquired.
Satellite acquired.
Description
< -109 dBm
< -106 dBm
< -105 dBm
< -105 dBm
< -109 dBm
< -108 dBm
< -110 dBm
< -110 dBm
SocketModem Cell HSPA and SocketModem iCell HSPA MTSMC-H5 Device Guide
Description
+32 dBm ± 1 dBm GSMK mode (class 4)
+27 dBm ± 1 dBm 8PSK mode (class E2)
+29 dBm ± 1 dBm GSMK mode (class 1)
+26 dBm ± 1 dBm 8PSK mode (class E2)
+23 dBm ± 1 dBm (class 3)
+23 dBm ± 1 dBm (class 3)
