Frequency Bands

Mode
GSM850
EGSM900
DCS1800
PCS1900
WCDMA850
(band V)
WCDMA900
(band VIII)
WCDMA1700
(band IV)
WCDMA1900
(band II)
WCDMA2100
(band I)
SocketModem Cell HSPA and SocketModem iCell HSPA MTSMC-H5 Device Guide
Freq. TX (MHz) Freq. RX (MHz)
824.2- 848.8 869.2 - 893.8
890.0 - 914.8 935.0 - 959.8
880.2 - 889.8 925.2 - 934.8
1710.2 - 1784.8 1805.2 - 1879.8
1850.2 - 1909.8 1930.2 - 1989.8
826.4 - 846.6 871.4 - 891.6
882.4 - 912.6 927.4 - 957.6
1710.4 - 1755.6 2112.4 - 2167.6
1852.4 - 1907.6 1932.4 - 1987.6
1922.4 - 1977.6 2112.4 - 2167.6
Channels
128 - 251
0 - 124
975 - 1023
512 - 885
512 - 810
Tx: 4132 - 4233
Rx: 4357 - 4458
Tx: 2712 - 2863
Rx: 2937 - 3088
Tx: 1312 - 1513
Rx: 9662 - 9938
Tx: 9262 - 9538
Rx: 9662 - 9938
Tx: 9612 - 9888
Rx: 10562 - 10838
CHAPTER 6 –APPLICATION NOTES
TX - RX offset
45 MHz
45 MHz
45 MHz
95MHz
80MHz
45MHz
45MHz
400MHz
80MHz
190MHz
30
