INSTRUCTION FOR INSTALLATION AND USE
LUNA
1000 - 1300 RD GOLD GAS
1
Passion for fire
English 06-2012

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LUNA1300 RD GOLD GAS and is the answer not in the manual?

Questions and answers

Summary of Contents for M Design LUNA1300 RD GOLD GAS

  • Page 1 INSTRUCTION FOR INSTALLATION AND USE LUNA 1000 - 1300 RD GOLD GAS Passion for fire English 06-2012...
  • Page 2 V E R Y I M P O R T A N T I N S T A L L A T I O N I N S T R U C T I O N S F O R T H E M - D E S I G N G A S F I R E P L A C E S T H E S U P P L I E R T A K E S N O...
  • Page 3: Table Of Contents

    SUMMARY 1. GENERAL REMARKS .............. 2. CONNECTION ................3. INSTALLING THE FIREPLACE ..........3.1.1 Positioning the fireplace ..........3.1.2 Gas connection ..............3.1.3 Electrical connection ............4. INSTALLING THE CHIMNEY ..........8-11 5. INSULATION AND FINISHING ........... 6. CONVECTION CURRENT............13-14-15 7.
  • Page 4 OPEN AND CLOSE THE DOOR CLOSING OPEN IF SOME DUST OR WASTE IS SEEN ON THE WINDOW ( INSIDE AND OUTSIDE ), CLEAN THIS BEFORE THE FIRST USE OF THE FIREPLACE. CLEANING THE WIN- DOW IS THE ONLY MAINTENANCE ACTION THAT CAN BE DONE BY THE CONSUMER INSTRUCTION FOR INSTALLATION AND USE - LUNA 1000-1300 RD GOLD - GAS...
  • Page 5: General Remarks

    1. GENERAL REMARKS This is a moulding of the closed combustion system, designed for the atmosphere and comfort of your living-room. It constitutes an efficient source of heat and gives the impression of a real chim- ney fire. The gas with air-vent furnaces are based on the principle of natural extraction from the furnace, which eliminates flue gas outside and brings in air (oxygen) from outside the house which is neces- sary for combustion of the gas.
  • Page 6: Installing The Fireplace

    3. INSTALLING THE FIREPLACE After having checked the appliance, you ready to install your appliance. This is done as follows 3.1.1 POSITIONING THE FIREPLACE Place the fireplace on a stable surface using the adjustable feet. Adjust the height of the fireplace by turning the bolt ( pic 1 ) The stove may not be placed direct ont the floor to allow natural convection.
  • Page 7: Gas Connection

    3.1.2 GAS CONNECTION The appliances are standard delivered with a 1/2” gas solded connection ( pic. 1 ). It is always located at the back side of the appliance. Make sure nothing remains in the gas lines, since this may easely lead to blockage. An approved gas valve should always be connected to the appliance, wich must be accesible at all time .
  • Page 8 PIC. 1 ROOF EXIT ( C31 ) Ø 200 / 130 Appliance C (min) C (max) Restriction 1000 RD Ø 75 1300 RD Ø 75 Ø 150/100 after elbow 90° Ø 200/130 Appliance C (min) C (max) Restriction 1000 RD Ø...
  • Page 9 PIC. 2 ROOF EXIT VIA EXISTING CHIMNEY (C91) Ø200(min) / Ø 130 Appliance C (min) C (max) Restriction HR+ (as from 2 m) 1000 RD Ø 75 1300 RD Ø 75 It is obligatory to use the sanitation set USSAN with placing. This USSAN piece must be saeled at the roof.
  • Page 10 Pic. 3 WALL EXIT (C Ø 200 / 130 Appliance A (min) B (min) B (max) Restriction 1000 RD wall exit Ø 75 1300 RD wall exit wall exit Ø 75 DO NOT USE A REDUCTION 200/130 to 150/100 IN THIS CASE elbow min.
  • Page 11 Pic. 5 ROOF EXIT with 90° bends Ø 200/130 Appliance A (min) B (max) C (min) (A+B+C )max 1000 Rd B-A-9m 12 m 1300 RD A+C-1 B-A+1 10 m FIG. 5 Ø 150/100 and Ø 200/130 Appliance 1000 RD / 1300 RD for each 90°...
  • Page 12: Insulation And Finishing

    For insulation of the furnace, we advise you to use M Design insulating plates. You are advised against using any other insulation product. Inflammable materials as well may not be used for the finishing.
  • Page 13: Convection Current

    6. CONVECTION CURRENT Please , follow this instruction. The appliance can overheat if you not apply those instructi- ons. Errorcode F02 will appear ! The enclosure of the furnace must be provided with ventilation grills or openings allowing for the elimination of heat by convection.
  • Page 14 INSTRUCTION FOR INSTALLATION AND USE - LUNA 1000-1300 RD GOLD - GAS...
  • Page 15 YOU HAVE TO CONNECT AT LEAST THE TWO APPERTURES SITUATED AT THE TOP OF THE APPLIANCE FOLLOWING PIC. 1 THE STOVE MAY NOT BE PLACED DIRECT ON THE STOVE MAY NOT BE PLACED DIRECT ON THE FLOOR, WTHOUT THE FEETS. THIS TO ALLOW NATURAL CONVECTION. THE APPERTURES FOR THE AIR SUPPLY ARE SITUATED UNDERNEATH THE APLLIANCE.
  • Page 16: Mounting A 3 Sided Frame

    7. MOUNTING A 3-SIDED FRAME 3-sided frame pic 1 upper frame sideframe 2,25cm 4 sided frame (lower piece) pic 2 Fireplace is delivered standard with 4sided frame 3,5cm, an upper and 2 sideframes ( see pic. 2 ) Before mounting the 3 sided frame, remove 4 sided frame ( lower piece ) by lift it carefully up. Pull out the upper frame and in second way the left and right sideframes.
  • Page 17: Positioning The Logs, Diamond, Sapphire And White Pebbles

    8. PUTTING IN PLACE THE LOGS, DIAMOND, SAPPHIRE AND WHITE STONES • Please check that the pilot light is switched off and that the furnace has cooled down. • Move the window to the front by pulling it. The window tips open at 45°. •...
  • Page 18: 1000Rd

    INSTRUCTION FOR INSTALLATION AND USE - LUNA 1000-1300 RD GOLD - GAS...
  • Page 19 INSTRUCTION FOR INSTALLATION AND USE - LUNA 1000-1300 RD GOLD - GAS...
  • Page 20: 1150Rd

    INSTRUCTION FOR INSTALLATION AND USE - LUNA 1000-1300 RD GOLD - GAS...
  • Page 21 INSTRUCTION FOR INSTALLATION AND USE - LUNA 1000-1300 RD GOLD - GAS...
  • Page 22: First-Time Use

    After the first few fires, a light deposit may appear on the window. It comes from the paint- work. Once the furnace is cold you can get rid of this deposit by using M Design’s Bio-Clean cleaning product. This product may be used later on for cleaning the window.
  • Page 23: Startpilot

    11. STARTPILOT The M-Design Gas appliance are provided with “Constant startpilot”. After the first use or when the winterperiod is coming and you use the fireplace daily, you must let the startpilot switch ON. Don’t switch it off after each use. This startpilot avoids condensation in the fireplace and protects the whole appliance and even the electronic parts against humidity.
  • Page 24 INSTRUCTION FOR INSTALLATION AND USE - LUNA 1000-1300 RD GOLD - GAS...
  • Page 25 INSTRUCTION FOR INSTALLATION AND USE - LUNA 1000-1300 RD GOLD - GAS...
  • Page 26: Drawings

    LUNA 1000 RD GOLD gas connection gas on the back side INSTRUCTION FOR INSTALLATION AND USE - LUNA 1000-1300 RD GOLD - GAS...
  • Page 27 LUNA 1300 RD GOLD gas connection gas on the left side INSTRUCTION FOR INSTALLATION AND USE - LUNA 1000-1300 RD GOLD - GAS...
  • Page 28: Guarantee

    14. GUARANTEE This page is your warranty card. The guarantee is only valid for faults caused by construction defects or defects in the parts used to build the furnace. M-Design offers a 12 month guarantee on all electronic parts and a 8 year guarantee on the furnace construction.
