INSTRUCTIONS FOR INSTALLATION AND USE
Luna Diamond
1000 RD - 1300 RD
CLOSED GASFIREPLACES
Distributor/Manufacturer
M-Design Benelux BVBA
B-8210 Zedelgem - Belgium
V12-2019

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Luna Diamond Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for M Design Luna Diamond Series

Summary of Contents for M Design Luna Diamond Series

  • Page 1 INSTRUCTIONS FOR INSTALLATION AND USE Luna Diamond 1000 RD - 1300 RD CLOSED GASFIREPLACES Distributor/Manufacturer M-Design Benelux BVBA B-8210 Zedelgem - Belgium V12-2019...
  • Page 2 V E R Y I M P O R T A N T I N S T A L L A T I O N I N S T R U C T I O N S F O R T H E M - D E S I G N G G A S F I R E P L A C E S T H E S U P P L I E R T A K E S N O R E S P O N S B I L I T Y F O R A N Y P O S S I B L E D A M A G E , P O O R W O R K I N G A P P L I A N C E S A N D...

  • Page 3: Table Of Contents

    SUMMARY 1. GENERAL REMARKS ............2. CONNECTION ..............3. INSTALLING THE FIREPLACE ..........3.1.1 Positioning the fireplace ..........3.1.2 Nearbox (Gasunit) ............3.1.3 The Gas connection ............ 3.1.4 Electrical connection ............ 3.1.5 Modification natural gaz to propane ......4. INSTALLING THE CHIMNEY ..........10-13 5.
  • Page 4 OPEN EN CLOSE THE DOOR For initial setup, you need to clean the window and clear the fireplace of any dust and grease that is left behind. This is also the only maintenance action that may be performed on the device by the user. Thanks to a patented system, the door can be easily opened at an angle of 45°...

  • Page 5: Installing The Fireplace

    3. Installing the fireplace After having checked the appliance, you are ready to install your appliance. This is done as follows 3.1.1 Positioning the appliance Place the appliance on a stable surface using the adjustable feet. Adjust the height of the appliance turning the bolt.

  • Page 6: Nearbox (Gasunit)

    3.1.2 Nearbox (gasunit) For safety reasons, The gasbattery or “NEARBOX” is fixed with screws on the pallet. Unscrew and remove the gasunit before installation to main burner gas connection 1/2” Gas valva reciever VK4105ME5004 Transmitter burner S4965C3029 DFGT-03MC01 V09 Dimensions gasunit : L365 xB188 x H64mm INSTRUCTIONS FOR INSTALLATION AND USE 1000-1300RD GAS...

  • Page 7: The Gas Connection

    3.1.3 The Gas connection After the “NEARBOX” has removed from the of the back of the fire, you can place it loosely on the ground in proximity to the opening provided in the wall of mantelpiece. The device is always con- nected with an approved gas tap 1/2, and preferably with a yellow gasflexible that is reachable at all times.

  • Page 8: Electrical Connection

    3.1.4 Electrical connection These appliances are equipped with a radiographic remote control, making an earthened 220V socket necessary. You should bear in mind that the appliance must be connected to all electrical supplies for the purposes of service. It’s obligatory to connect an earth current. 3.1.5 Modification natural gaz to propane Modification of the fireplace can only be done by the manufacturer or an approved installer.

  • Page 9: Installing The Chimney

    4. Installing the chimney Install the concentric flue duct as indicated by ONTOP - METALOTERM. The only authorised pipes are ONTOP Metaloterm™. ONTOP-METALOTERM tested our appliances with their conduct and we only guarantee a good working of the appliance with those. Between the external wall of the pipe and the wall or the ceiling, you should allow for a clearance of at least 50mm and protection that is suitable against temperatures of around 130°C.
  • Page 10 4.2. ROOF EXIT VIA EXISTING CHIMNEY (C91S) Ø200(min) / Ø 130 Appliance C (min) C (max) 1000 RD 1300 RD This USSAN piece must be sealed at the top of the chemney! USDVC13 flex 130mm This USSAN piece must be sealed at the roof! INSTRUCTIONS FOR INSTALLATION AND USE 1000-1300RD GAS...
  • Page 11 4.3. WALL EXIT (C11) Ø 200/130 Appliance A (min) B (min) B (max) 1000 RD Wall exit 1300 RD Wall exit Wall exit Be carefull every horizontal part does not have a negative in clination in direction of IMPORTANT: the outlet. It is even better, when possible to have a little inclination of 2 or 3 degrees ascending to avoid rain and condenstation in the tube.
  • Page 12 Picture 4: ROOF EXIT WITH BEND Ø 200/130 without reduction Appliance A (min) B (max) C (min) (A+B+C )max 1000 RD 1300 RD A+C-1 B-A+1 Ø 200/130 Appliance 1000 / 1300 RD for each 90° bend subtract 1m horizontally or add 1m vertically for each 45°/30°/15°...

  • Page 13: Flame Adjustment Settings

    5. Flame adjustment settings Before initial setup, you need to clean the window (from outside and inside) and fireplace of any dust and grease. If INSTALLING –SETTING OF AIR INTAKE GAS18 you do not clean the glass properly, after lightning up the fireplace it can remained still on the glass. After installing efore initial setup, you need to clean the window (from outside and inside) the fireplace correctly on the concentric tube or chimney system, you must make a flame adjustment according to the nd fireplace of any dust and grease.

  • Page 14: Convection Current

    7. Convection current Please, follow this instructions. The appliance can overheat if you not apply those instructions. Errorcode F02 will appear! It is MANDATORY to equip the fireplace with a convection kit consisting of inlets and out- lets which are connected to stretchable hoses from 3m to 5m. In this way is created a circualtion and evacuation of the heat by convection.
  • Page 15 7.1. CONVECTION GRILLS EXIT CONVECTION: You can choose between 3 models of grids according to your taste or according to the fireplace: Grid Design (2 connections), Grille design long small model (2 connections) or long model (4 connections) AIR ARRIVAL (ENTRY CONVECTION): You have the option to choose between inlets 2dm3 or 4dm3 Design Grill Long (outlet) Design Grills (outlet )
  • Page 16 You have to connect at least two appertures situated at the top of the appliance. The appliance may not be placed directly on the floor, without the feet. This is to allow na- tural convection. The appertures for the air supply are situated underneath the aplliance.

  • Page 17: Positioning The Logs

    9. Positioning the logs, diamond, sapphire and white pebbles Please check that the pilot light is switched off and that the appliance has cooled down. • Move the window to the front by pulling it. The window tips open at 45°. •...
  • Page 18 Logs for Luna Diamond 1000 RD Gas INSTRUCTIONS FOR INSTALLATION AND USE 1000-1300RD GAS...
  • Page 19 Logs for Luna Diamond 1300 RD Gas INSTRUCTIONS FOR INSTALLATION AND USE 1000-1300RD GAS...

  • Page 20: First-Time Use

    After the first few fires, a light deposit may appear on the window. It comes from the paintwork. Once the appliance is cold you can get rid of this deposit by using M Design’s Bio-Clean cleaning product. This product may be used later on for cleaning the window.

  • Page 21: Guarantee

    11. Guarantee This page is your warranty card. The guarantee is only valid for faults caused by construction defects or defects in the parts used to build the appliance. M-Design offers a 12 month guarantee on all electronic parts and a 8 year guarantee on the appliance construction.

  • Page 22: Specifications

    12. Specifications Luna 1000RD gas INSTRUCTIONS FOR INSTALLATION AND USE 1000-1300RD GAS...

  • Page 23: Specifications

    11. Specifications Luna 1300RD gas INSTRUCTIONS FOR INSTALLATION AND USE 1000-1300RD GAS...

  • Page 24: Remote Control

    12. Remote control (direct ingnition) 1. First use (Connect the remote control) Keep pressing the button until 24:00 appears in the top left corner (1). Press several times on until you see “bnd” on the screen (2) Press shortly on You see the temperature on the screen.

  • Page 25: Remote Control

    5. ECO WAVE each model is standard delivered with ECO-WAVE ECO-WAVE is an automatic cycle of fluctuating flames. At each start-up of the fire, the system starts in ECO-WAVE mode ! Switch off WAVE Press 1x short on the menu Symbol that indicates Press the arrow up or down.
  • Page 26 14. DIMENSIONS DESIGN GRILLS Grille design (sortie) avec 2 raccordements 1223 Grille design longue grand model (sortie) Grille design longue petit model (sortie) Grille d’arrivée d’air (entrée) Grille d’arrivée d’air (entrée) INSTRUCTIONS FOR INSTALLATION AND USE 1000-1300RD GAS...

  • Page 27: Drawings

    15. DRAWINGS Luna Diamond Gaz 1000RD Ø200/130 1060 Ø150 1070 Luna Diamond Gaz 1300RD Luna Gas 1000RD - (Type 2 - 30mm) Ø200/130 ver. 15.9.2019 1204 1360 1274 Ø150 1284 1370 INSTRUCTIONS FOR INSTALLATION AND USE 1000-1300RD GAS...
