LUNA 850 V / 550 V GOLD GAS
LUNA 850 DV / 550 DV GOLD GAS
INSTRUCTION FOR INSTALLATION AND USE
English 11-2012
Passion for fire

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LUNA 850 V Gold Gas and is the answer not in the manual?

Questions and answers

Related Manuals for M Design LUNA 850 V Gold Gas

Summary of Contents for M Design LUNA 850 V Gold Gas

  • Page 1 LUNA 850 V / 550 V GOLD GAS LUNA 850 DV / 550 DV GOLD GAS INSTRUCTION FOR INSTALLATION AND USE English 11-2012 Passion for fire...
  • Page 2 V E R Y I M P O R T A N T I N S T A L L A T I O N I N S T R U C T I O N S F O R T H E M - D E S I G N G A S F I R E P L A C E S T H E S U P P L I E R T A K E S N O...

  • Page 3: Table Of Contents

    SUMMARY 1. GENERAL REMARKS .............. 2. CONNECTION ................3. INSTALLING THE FIREPLACE ..........3.1.1 Positioning the fireplace ..........3.1.2 Gas connection ..............3.1.3 Electrical connection ............4. INSTALLING THE CHIMNEY ..........7-12 5. INSULATION AND FINISHING ........... 6. CONVECTION CURRENT............14-15-16 7.
  • Page 4 OPEN AND CLOSE THE DOOR CLOSING OPEN IF SOME DUST OR WASTE IS SEEN ON THE WINDOW ( INSIDE AND OUTSIDE ), CLEAN THIS BEFORE THE FIRST USE OF THE FIREPLACE. M-DESIGN INSTRUCTION FOR INSTALLATION AND USE - LUNA 550V - 550DV - 850V - 850DV GOLD - GAS...

  • Page 5: General Remarks

    1. GENERAL REMARKS This is a moulding of the closed combustion system, designed for the atmosphere and comfort of your living-room. It constitutes an efficient source of heat and gives the impression of a real chimney fire. The gas with air-vent furnaces are based on the principle of natural extraction from the furnace, which eliminates flue gas outside and brings in air (oxygen) from outside the house which is necessary for combustion of the gas.

  • Page 6: Installing The Fireplace

    3. INSTALLING THE FIREPLACE After having checked the appliance, you ready to install your appliance. This is done as follows 3.1.1 POSITIONING THE FIREPLACE Place the fireplace on a stable surface using the adjustable feet. Adjust the height of the fireplace by turning the bolt ( pic 1 ) The stove may not be placed direct ont the floor to allow natural convection.

  • Page 7: Gas Connection

    3.1.2 GAS CONNECTION The appliances are standard delivered with a 1/2” gas solded connection ( fig. 1 ). It is always located at the left-hand side of the appliance. Make sure nothing remains in the gas lines, since this may easely lead to blockage. An approved gas valve should always be connected to the appliance, wich must be accesible at all time .
  • Page 8 Fig. 1 ROOF EXIT ( C31 ) TAB. 1 This is recommanded with a roof exit > 3m Ø 150/100 Appliance C (min) C (max) Restrictiion HR+ (as from 4m) LUNA 850 V / 550 V Ø 60 LUNA 850 DV / 550 DV Ø...
  • Page 9 Fig. 2 ROOF EXIT VIA EXISTING CHIMNEY (C ou/of USDHC10 TAB. 1 USDHC13  150(min) Ø 100 Aplliance C (min) C (max) Restriction HR+ (as from 4m) LUNA 850 V / 550 V Ø 60 LUNA 850 DV / 550 DV Ø...
  • Page 10 Fig. 3 WALL EXIT (C Ø 150/100 with reduction USVK13 on the aplliance Appliance A (min) B (min) B (max) Restriction HR+ 850 V / 550 V 1,25m wall exit A+0,5m Ø 75 850 DV / 550 DV 1,25 wall exit Ø...
  • Page 11 Ø 200/130 Appliance A (min) B (min) Restriction HR+ B (max) 850 V / 550 V wall exit Ø 75 A+8m 850 DV / 550 DV wall exit Ø 75 A+7m 3° Pic. 5 Pic.6 IMPORTANT : BE CAREFULL EVERY HORIZONTAL PART DOES NOT HAVE AN NEGATIVE INCLINATION (pic.5) IN DIRECTION OF OUTLET.
  • Page 12 Fig. 5 ROOF EXIT with 90° bends Ø 150/100 with reduction USVK13 on the appliance Appliance A (min) B (max) C (min) (A+B+C ) max 850 V / 550 V 1,25 m 850 DV / 850 DV 1,25 m A+C+0,5 B-A-0,5 Fig.

  • Page 13: Insulation And Finishing

    The built-in part of the furnace tends to be very warm. Please check that the furnace is not too narrowly fitted and that there is ade- quate space for the elimination of hot air. For insulation of the furnace, we advise you to use M Design insulating plates. You are advised against using any other insulation product.
  • Page 14 6. CONVECTION CURRENT Please , follow this instruction. The appliance can overheat if you not apply those instructions. Errorcode F02 will appear ! The enclosure of the furnace must be provided with ventilation grills or openings allowing for the elimination of heat by con- vection.
  • Page 15 Design Grill ( OUTLET ) 4 dm² 2 dm² INLET INLET M-DESIGN INSTRUCTION FOR INSTALLATION AND USE - LUNA 550V - 550DV - 850V - 850DV GOLD - GAS...
  • Page 16 YOU HAVE TO CONNECT AT LEAST TWO APPERTURES SITUATED AT THE TOP OF THE APPLIANCE. URES. THE STOVE MAY NOT BE PLACED DIRECT ON THE STOVE MAY NOT BE PLACED DIRECT ON THE FLOOR, WTHOUT THE FEETS. THIS TO ALLOW NATURAL CONVECTION. THE APPERTURES FOR THE AIR SUPPLY ARE SITUATED UNDERNEATH THE APLLIANCE.

  • Page 17: Mounting A 3 Sided Frame

    7. MOUNTING A 3-SIDED FRAME 3-sided frame pic 1 pic 3 pic 4 upper frame sideframe 2,25cm 4 sided frame pic 6 pic 5 (lower piece) Fireplace is delivered standard with 4sided frame 3,5cm, an upper and 2 sideframes ( see pic. 2 ) Before mounting the 3 sided frame, remove 4 sided frame ( lower piece ) by lift it carefully up.

  • Page 18: Positioning The Logs, Diamond, Sapphire And White Pebbles

    8. PUTTING IN PLACE THE LOGS, DIAMOND, SAPPHIRE AND WHITE STONES • Please check that the pilot light is switched off and that the furnace has cooled down. • Move the window to the front by pulling it. The window tips open at 45°. •...

  • Page 19: 850 V / 850 Dv

    LUNA 850V / 850DVGAS M-DESIGN INSTRUCTION FOR INSTALLATION AND USE - LUNA 550V - 550DV - 850V - 850DV GOLD - GAS...
  • Page 20 LUNA 850V 850DV GAS M-DESIGN INSTRUCTION FOR INSTALLATION AND USE - LUNA 550V - 550DV - 850V - 850DV GOLD - GAS...
  • Page 21 LUNA 850 V GAS / GAZ Only for 850V with two burners Seulement pour appareil 850V avec deux brûleurs en escaliers M-DESIGN INSTRUCTION FOR INSTALLATION AND USE - LUNA 550V - 550DV - 850V - 850DV GOLD - GAS...

  • Page 22: 550 V / 550 Dv

    LUNA 550 V / 550 DV M-DESIGN INSTRUCTION FOR INSTALLATION AND USE - LUNA 550V - 550DV - 850V - 850DV GOLD - GAS...
  • Page 23 LUNA 550 V / 550 DV M-DESIGN INSTRUCTION FOR INSTALLATION AND USE - LUNA 550V - 550DV - 850V - 850DV GOLD - GAS...

  • Page 24: First-Time Use

    After the first few fires, a light deposit may appear on the window. It comes from the paintwork. Once the furnace is cold you can get rid of this de- posit by using M Design’s Bio-Clean cleaning product. This product may be used later on for cleaning the window.

  • Page 25: Startpilot

    11. STARTPILOT The M-Design Gas appliance are provided with “Constant startpilot”. After the first use or when the winterperiod is coming and you use the fireplace daily, you must let the startpilot switch ON. Don’t switch it off after each use. This startpilot avoids condensation in the fireplace and protects the whole appliance and even the electronic parts against humidity.

  • Page 26: Specification Sheet

    13. SPECIFICATION SHEET LUNA 850 V / 850 DV Gold gas Type of Gas NATURAL GAS BUTANE-PROPANE / LPG Category 3B/P Category Type Entry pressure (mbar) 28-30 Burner pressure (mbar) 23.8 19,3 28,2 1.132 0,789 0,344 0,389 0,389 0,295 Consumption (m Burner injector Fr./Re.* 6 x 0,80 / 6x0.75 6 x 0,80 / 6 x 0,5...
  • Page 27 LUNA 550V / DV GOLD gas Type of Gas NATURAL GAS BUTANE-PROPANE / LPG Category 3B/P Category Type /Type Entry pressure (mbar) 28-30 Burner pressure (mbar) 23,28 19,1 28,2 1,132 1,026 0,344 0,389 0,389 0,295 Consumption (m Burner injector Fr./Re.* 6x0,85 6x0,85 6x0,50...

  • Page 28: Drawings

    LUNA 850 V GOLD GAS connection gas on the left side 850V with one burner ( saphir, diamon, white stones ) 850V with two burner ( woodset ) M-DESIGN INSTRUCTION FOR INSTALLATION AND USE - LUNA 550V - 550DV - 850V - 850DV GOLD - GAS...
  • Page 29 LUNA 850 DV GOLD GAS connection gas on the left side M-DESIGN INSTRUCTION FOR INSTALLATION AND USE - LUNA 550V - 550DV - 850V - 850DV GOLD - GAS...
  • Page 30 LUNA 550 V GOLD GAS connection gas on the left side M-DESIGN INSTRUCTION FOR INSTALLATION AND USE - LUNA 550V - 550DV - 850V - 850DV GOLD - GAS...
  • Page 31 LUNA 550 DV GOLD GAS connection gas on the left side M-DESIGN INSTRUCTION FOR INSTALLATION AND USE - LUNA 550V - 550DV - 850V - 850DV GOLD - GAS...

  • Page 32: Examples With Or Wihout Finishing Frame

    Example how to mount with a 4-sided frame Two flexible tubes can be connected to one Connecting Flex tubes design grid ( 2 connections ) 700H/ 1000H/1150H/1300H : 2x ( obliged) 1600H : 4 x ( obliged ) / 1900H : 6x (obliged) 4-sided frame 3,5 - 7 or 10 cm Inlet convection: OBLIGED ! TYPE...
  • Page 33 Example how to mount without a 4-sided frame Connecting Flex tubes 700H/1000H/1150H/1300H : 2x ( obliged) Two flexible tubes can be connected to one 1600H : 4 x ( obliged ) / 1900H : 6 x (obliged) design grid ( 2 connections ) 4-sided frame 3,5 - 7 or 10 cm Inlet convection: OBLIGED ! TYPE...

  • Page 34: Finishing Frame

    4-sided frame 4th -side frame X = 3,5 cm TYPE 700H DETAIL Z onderlat / baguette 1000H/DH 1150H/DH 1073 X = 7 cm 1300H/DH 1223 1600H/DH 1523 1900 H 1823 550V/DV X = 10,5 cm 850V/DV TYPE 700H 1000H/DH 1150H/DH 1081 1300H/DH 1231...
  • Page 35 X = 850V, 550V, 14. SPARE PARTS M-DESIGN INSTRUCTION FOR INSTALLATION AND USE - LUNA 550V - 550DV - 850V - 850DV GOLD - GAS...

  • Page 36: Spare Parts

    14. SPARE PARTS X = 850DV, 550DV M-DESIGN INSTRUCTION FOR INSTALLATION AND USE - LUNA 550V - 550DV - 850V - 850DV GOLD - GAS...

  • Page 37: Guarantee

    15. GUARANTEE This page is your warranty card. The guarantee is only valid for faults caused by construction defects or defects in the parts used to build the furnace. M-Design offers a 12 month guarantee on all electronic parts and a 8 year guarantee on the furnace construction. Caution: The following items are always excluded from the guarantee: The glass, door, joints and internal decor.

  • Page 38: Identification Boards

    16. IDENTIFICATION BOARDS 0461/2010 PN 0461BS0880 0461/2010 PN 0461CL0981 M-DESIGN M-DESIGN Serie N° LUNA 550V Gold Serie N° LUNA 550DV Gold Qn(Hi) Pn (Hi) Qn(Hi) Pn (Hi) m³/h m³/h BE/FR I2E+ G20/G25-20/25mbar 1.026 BE/FR I2E+ G20/G25-20/25mbar 1.026 DE/LU/PL G20 - 20 mbar 1.026 DE/LU/PL G20 - 20 mbar...
  • Page 39 0461/2010 PN 0461BS0880 M-DESIGN 0461/2010 PN 0461CL0981 M-DESIGN Serie N° LUNA 850V Gold Serie N° LUNA 850DV Gold Qn(Hi) Pn (Hi) Qn(Hi) Pn (Hi) m³/h m³/h BE/FR I2E+ G20/G25-20/25mbar 1.026 BE/FR I2E+ G20/G25-20/25mbar 1.026 DE/LU/PL G20 - 20 mbar 1.026 DE/LU/PL G20 - 20 mbar 1.026...

  • Page 40: Ce Certification

    17. CE CERTIFICATION M-DESIGN INSTRUCTION FOR INSTALLATION AND USE - LUNA 550V - 550DV - 850V - 850DV GOLD - GAS...
  • Page 41 M-DESIGN INSTRUCTION FOR INSTALLATION AND USE - LUNA 550V - 550DV - 850V - 850DV GOLD - GAS...
