LUNA DIAMOND GAS
700-1000-1150-1300-1600-1900H
INSTRUCTIONS FOR INSTALLATION AND USE
02-2019

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LUNA DIAMOND Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for M Design LUNA DIAMOND Series

Summary of Contents for M Design LUNA DIAMOND Series

  • Page 1 LUNA DIAMOND GAS 700-1000-1150-1300-1600-1900H INSTRUCTIONS FOR INSTALLATION AND USE 02-2019...
  • Page 2 V E R Y I M P O R T A N T I N S T A L L A T I O N I N S T R U C T I O N S F O R T H E M - D E S I G N G G A S F I R E P L A C E S T H E S U P P L I E R T A K E S N O R E S P O N S B I L I T Y F O R A N Y P O S S I B L E D A M A G E , P O O R W O R K I N G A P P L I A N C E S A N D...

  • Page 3: Table Of Contents

    SUMMARY 1. GENERAL REMARKS ......................2. CONNECTION .......................... 3. INSTALLING THE FIREPLACE..................3.1. Positioning the fireplace ..................3.2. Nearbox (Gasunit) ...................... 3.3. The Gas connection ....................3.4. Electrical connection ....................3.5. Modification natural gaz to propane ............4. INSTALLING THE CHIMNEY ..................4.1.
  • Page 4 OPEN EN CLOSE THE DOOR For initial setup, you need to clean the window and clear the fireplace of any dust and grease that is left behind. This is also the only maintenance action that may be performed on the device by the user. Thanks to a patented system, the door can be easily opened at an angle of 45°...

  • Page 5: General Remarks

    1. General remarks This is an appliance using the closed combustion system, designed for the atmosphere and comfort of your living-room. It constitutes an efficient source of heat and gives the impression of a real fire. The balanced flue appliances are based on the principle of natural extraction from the firebox, which eliminates flue gas outside and brings in air (oxygen) from outside the house which is necessary for combustion of the gas.

  • Page 6: Installing The Fireplace

    3. Installing the fireplace After having checked the appliance, you are ready to install your appliance. This is done as follows 3.1. Positioning the appliance Place the appliance on a stable surface using the adjustable feet. Adjust the height of the appliance turning the bolt ( pic 1 ) The appliance must not be placed directly on the floor as you need to allow natural convection.

  • Page 7: Nearbox (Gasunit)

    3.2. Nearbox (gasunit) For safety reasons, The gasbattery or “NEARBOX” is fixed with screws at the rear of the unit during transport . THE UNIT CANNOT BE INSTALLED WITH THIS NEARBOX FIXED AT THE REAR, IT IS MANDATORY TO UNSCREW THE BATTERY FROM THE REAR PRIOR TO INSTALLATION . unscrew 4 screws in the corners (key 8) to second burner or side burner...

  • Page 8: The Gas Connection

    3.3. The Gas connection After the “NEARBOX” has removed from the of the back of the fire, you can place it loosely on the ground in proximity to the opening provided in the wall of mantelpiece. The device is always connected with an approved gas tap 1/2, and preferably with a yellow gasflexible that is reachable at all times.

  • Page 9: Electrical Connection

    3.4. Electrical connection These appliances are equipped with a radiographic remote control, making an earthened 220V socket necessary. You should bear in mind that the appliance must be connected to all electrical supplies for the purposes of service. It’s mandatory to connect an earth current. 3.5.

  • Page 10: Installing The Chimney

    4. Installing the chimney Install the concentric flue duct as indicated by ONTOP - METALOTERM. The only authorised pipes are ONTOP Metaloterm™. ONTOP-METALOTERM tested our appliances with their conduct and we only guarantee a good working of the appliance with those. Between the external wall of the pipe and the wall or the ceiling, you should allow for a clearance of at least 50mm and protection that is suitable against temperatures of around 130°C.

  • Page 11: Roof Exit Via Existing Chimney

    4.2. ROOF EXIT VIA EXISTING CHIMNEY (C91S) Ø 150 (min) / Ø 100 Ø 150 (min) / Ø 100 Appliance C (min) C (max) Restriction (as from 4m) 700 H / 1000 H Ø 60 1150 H Ø 53 1300 H Ø...

  • Page 12: Wall Exit (C11)

    4.3. WALL EXIT (C11) Picture 1 Ø 150/100 Ø 150/100 With reduction usvk13 on appliance (pic. 1 ) Appliance A (min) B (min) B (max) Restriction 700H / 1000 H 1 *m Wall Exit A+1m Ø 75 1150 H 1 *m Wall Exit A+0,5m Ø...

  • Page 13: Roof Exit With Bend

    4.4. ROOF EXIT WITH BEND Ø 150/100 Ø 150/100 With reduction USVKk13 on appliance Appliance A (min) B (max) C (min) (A+B+C )max 700 H /1000 H 1,25* m A+C+0,5m B-A-0,5m 1150 H 1,25* m A+C+0,5 B-A-0,5 1300 H 1,25* m 1600 H 1,25* m A+C-0,5m...

  • Page 14: Insulation And Finishing

    For insulation of the appliance, we advise you to use M Design insulating plates. You are advised against using any other insulation pro- duct. Inflammable materials as well may not be used for the finishing.

  • Page 15: Convection Current

    7. Convenction current Please, follow this instructions. The appliance can overheat if you not apply those instructions. Errorcode F02 will appear! It is MANDATORY to equip the fireplace with a convection kit consisting of inlets and outlets which are connected to stretchable hoses from 3m to 5m. In this way is created a circualtion and evacuation of the heat by convection.
  • Page 17 You have to connect at least two appertures situated at the top of the appliance. For the Luna 1600, you must connect 4 appertures. The appliance may not be placed directly on the floor, without the feet. This is to allow natural convection. The appertures for the air supply are situated underneath the aplliance Every opening you make must be connected with a flexible tube dia 150MM (see pic below).

  • Page 18: Positioning The Logs

    8. Positioning the logs, diamond, sapphire and white pebbles Please check that the pilot light is switched off and that the appliance has cooled down. • Move the window to the front by pulling it. The window tips open at 45°. •...
  • Page 19 Luna 700H Gas Luna 1000H Gas Remark : set for 700H and 1000H are the same.
  • Page 20 Luna 1150H Gas Luna 1150H Gas...
  • Page 21 Luna 1300H Gas...
  • Page 22 Luna 1600H Gas...
  • Page 23 Luna 1900H Gas...

  • Page 24: First-Time Use

    After the first few fires, a light deposit may appear on the window. It comes from the paintwork. Once the appliance is cold you can get rid of this deposit by using M Design’s Bio-Clean cleaning product. This product may be used later on for cleaning the window.

  • Page 25: Guarantee

    11. Guarantee This page is your warranty card. The guarantee is only valid for faults caused by construction defects or defects in the parts used to build the appliance. M-Design offers a 12 month guarantee on all electronic parts and a 8 year guarantee on the appliance construction.

  • Page 26: Remote Control

    12. Remote control (direct ingnition) 1. First use (Connect the remote control) Keep pressing the button until 24:00 appears in the top left corner (1). Press several times on until you see “bnd” on the screen (2) Press shortly on You see the temperature on the screen.
  • Page 27 4. Manual control (Triple Line Burner) To light up the side burners 2, press First you see the wave settings (page 30). Press a second time and you will see a “b0” or “b0” Remark: If after a previous use of the fireplace, you turned it off in “b1” mode, next ignition, the burners 1,2 and 3 will light simultaneously.
  • Page 28 5. Thermostatic control In case you want to go to a thermostatic control, you follow the next steps: Press 2x the button until you see the screen with the symbols shown in picture 2. Press until the symbols are blinking (pic 2). Confirm your choise by pressing ( pic.3).
  • Page 29 13. Drawings Luna 700 H Gold gas/gaz Ø200 Ø130 631 ext. 357.5 2x Ø150 Luna Diamond 700H - Gas/Gaz variation frames: see website Veränderung Rahmen : sehe website...
  • Page 30 Luna 1000 H Gold gas/gaz Ø200 Ø130 931 ext. 2x Ø150 Luna Diamond 1000H - Gas/Gaz...
  • Page 31 Luna 1150 H Gold gas/gaz Ø200 1146 Ø130 1081 ext. 1029 1079 2x Ø150 Luna Diamond 1150H Gas/Gaz - Type 2 - 30mm...
  • Page 32 Luna 1300 H Gold gas/gaz Ø200 1296 Ø130 1231 ext. 1179 1229 4x Ø150 Luna Diamond 1300H - Gas/Gaz - Type 2 - 30mm...
  • Page 33 Luna 1600 H Gold gas/gaz Ø200 1596 Ø130 1531 ext. 1479 1529 4x Ø150 Luna Diamond 1600H - Gas/Gaz...
  • Page 34 Luna 1900 H Gold gas/gaz Ø200 1896 Ø130 1831 ext. 1779 1829 6x Ø150 Luna Diamond 1900H - Gas/Gaz...
  • Page 35 15. Identification boards...
  • Page 36 CE -1299CR0190 €10/2016 M-DESIGN sign 1299 LUNA 1900H ° Serie N Pn (Hi) Qn(Hi) BE/FR 12E+ G20/G25-20/25mbar 13,8 11,6 1.355 DE/LU/PL G20 - 20 mbar 13,8 11,6 1,355 G25 - 25 mbar 12,6 10,8 1,442 AT/CH/CY/CZ/DK/ G20 - 20 mbar 13,8 11,6 1,355...

This manual is also suitable for:

Luna diamond 700hLuna diamond 1000hLuna diamond 1150hLuna diamond 1300hLuna diamond 1600hLuna diamond 1900h
