- Page 1 TS-2030EN/TS-2076EN Series Progressive Scan Cameras 10490 Rev. A See the possibilities...
- Page 2 Page ii...
- Page 3 Notice The material contained in this manual consists of information that is proprietary to JAI Inc., and may only be used by the pur- chasers of the product. JAI Inc. makes no warranty for the use of its product and assumes no responsibility for any errors which may appear or for damages resulting from the use of the information contained herein.
- Page 4 Page iv...
-
Page 5: Table Of Contents
Page v Table of Contents Table of Content ......... List of Figures. -
Page 6: Table Of Content
..........34 5.3.2 JAI Inc. Power Cables . - Page 7 Page vii 7.7 Problem 7: JPEG Image is Either Corrupt or Not a Full-Size Image. .47 7.8 Problem 8: EN Camera Does Not Send any FTP Image to the FTP Server ..........47 7.9 Problem 9: FTP servers switch between primary server and second server, even if the hard disk is not full.
- Page 8 Page viii Table of Contents...
-
Page 9: List Of Figures
......... . .32 FIGURE 13. Serial Communications Cable RS-232B-12 (JAI Inc. part number: 310 132 19) FIGURE 14. - Page 10 Page x List of Figures...
-
Page 11: List Of Tables
Page xi List of Tables TABLE 1. Firmware Names and Descriptions ........24 TABLE 2. - Page 12 Page xii List of Tables...
-
Page 13: Introduction
April 24, 2007 TS-2030EN/TS-2076EN Series Progressive Scan Cameras Operation Manual Introduction 1.1 Scope of this Manual This manual covers the operation of the TS-2030EN/TSC-2030EN/TS-2076EN/ TSC-2076EN traffic control camera. For information on how to operate the associated software, please see the software manual. 1.2 Related Documents •... -
Page 14: Product Description
Page 2 TS-2030EN/TS-2076EN Series Progressive Scan Cameras • Frame date/time stamp facility with user-definable text strings • High quality JPEG encoding • Automatic dynamic range control and maximum contrast images using the optional Smart Light Sensor 1.4 Product Description The TS-2030EN/TS-2076EN camera is an all-in-one progressive scan and Ethernet CCD camera, with a built in image capture/storage function, and image-processing software using a built-in PowerPC processor. -
Page 15: Getting Started
For details, please see "Power Supplies and Cable Setup." • PD-12 power supply • Cat5e/6 Ethernet cable • 10/100/1000 Ethernet switch • Debug-232 serial/power cable (JAI Inc. part number 31013219) 2.2 Network Settings 2.2.1 Default Network Settings for the TS-2030EN/TS-2076EN Camera The factory default network setting for the TS-2030EN/TS-2076EN is as follows:: IP address: 10.0.0.65... -
Page 16: Changing The Ip Address Of The Ts-2030En/Ts-2076En Camera
Page 4 TS-2030EN/TS-2076EN Series Progressive Scan Cameras 2.2.2 Changing the IP Address of the TS-2030EN/TS-2076EN Camera If you need to change the IP address of your TS-2030EN/TS-2076EN camera, you can do so using either the EN setup software or the debug RS-232 serial/power cable. Choose the method that is most appropriate for your application, and follow the steps listed. - Page 17 Page 5 TS-2030EN/TS-2076EN Series Progressive Scan Cameras Password: Password Once you log in as Administrator, you can create a new user and set a custom password. To set the properties of each camera connected to the network, follow the steps below: 1.
-
Page 18: Tutorial
Page 6 TS-2030EN/TS-2076EN Series Progressive Scan Cameras Tutorial This section demonstrates typical operations of the EN camera that most applications will require. This tutorial is intended for first-time users of the EN camera. Go through this section step-by-step to familiarize yourself with the EN’s operations. 3.1 Image Capturing 3.1.1 Start Up the EN Setup Software... -
Page 19: Camera Properties
Page 7 TS-2030EN/TS-2076EN Series Progressive Scan Cameras 3.1.2 Camera Properties Properties FIGURE 3. BW EN Cameras Color EN Cameras Click the camera icon on the left side of the window to see all the accessible config/status registers. Tutorial... -
Page 20: Live Image Capturing/Focusing
Page 8 TS-2030EN/TS-2076EN Series Progressive Scan Cameras Camera Properties FIGURE 4. 3.1.3 Live Image Capturing/Focusing Click the “Video” button. Highlight the icon of the camera you want to see. Click the “Full Size” and “Live” video buttons. You will now see a live video image. -
Page 21: Figure 5. Live Image Capturing
Page 9 TS-2030EN/TS-2076EN Series Progressive Scan Cameras Live Image Capturing FIGURE 5. Tutorial... -
Page 22: Figure 6. Focus Bar
Page 10 TS-2030EN/TS-2076EN Series Progressive Scan Cameras Focus Bar FIGURE 6. Use the “Focus Bar” button to make precise adjustments to the lens focus. Tutorial... -
Page 23: Figure 7. Measuring Box Position
Page 11 TS-2030EN/TS-2076EN Series Progressive Scan Cameras Measuring Box Position FIGURE 7. Use the “Measuring Box” button to make sure the license plate or particular target is in the correct side of the video field of view. Tutorial... -
Page 24: Figure 8. Half Size Image Position
Page 12 TS-2030EN/TS-2076EN Series Progressive Scan Cameras Half Size Image Position FIGURE 8. The “Half Size” image button is useful for situations in which two EN cameras together cover a single lane. Using the “Half Size” image button to capture two images: one on the left side of camera1, the other on the right side of camera2. -
Page 25: Figure 9. Quad Size Image Button
Page 13 TS-2030EN/TS-2076EN Series Progressive Scan Cameras Quad Size Image Button FIGURE 9. Click the “Quad Size” image button to capture four images. Each image will then be reduced from the full 1920 x 512 resolution to 960 x 256 resolution for the TS-2030EN. The image will be reduced from 1920 x 768 resolution to 960 x 384 for the TS-2076EN. -
Page 26: Image Properties
Page 14 TS-2030EN/TS-2076EN Series Progressive Scan Cameras The “HW Trigger” and “Rep. Trigger” buttons send the Ethernet trigger command to the EN camera. “HW Trigger” button sends a single Ethernet trigger command. “Rep. Trigger” sends a continuous Ethernet trigger command every second 3.1.4 Image Properties You can monitor the image properties of captured images, whether it’s “Live,”... -
Page 27: Image Transfer
Page 15 TS-2030EN/TS-2076EN Series Progressive Scan Cameras 3.2 Image Transfer 3.2.1 FTP Image Transfer To transfer images via FTP, first make sure to set up the FTP server properly. Please check the following items: The username/password or anonymous login must be set for FTP server. Set the permission of the read/write/create directory. -
Page 28: Adr (Automatic Dynamic Range) Control
Page 16 TS-2030EN/TS-2076EN Series Progressive Scan Cameras 3.3 ADR (Automatic Dynamic Range) Control 3.3.1 Light Sensor Connection ADR control is a process that runs inside the EN camera. It controls the camera every 1/10 second to ensure that when the camera is triggered, it produces a high quality image of the license plate and the vehicle it is mounted on, in all ambient lighting conditions. - Page 29 Page 17 TS-2030EN/TS-2076EN Series Progressive Scan Cameras You can connect up to two light sensors. If two IP addresses and port numbers are identical, then the EN camera tries to connect only a single light sensor. Set the ADR Control register from “Manual” to “ADR Control (Using the Light Sensor).” This will activate the connection to the light sensor.
-
Page 30: Flash Nighttime Light Control
Page 18 TS-2030EN/TS-2076EN Series Progressive Scan Cameras 3.3.2 Flash Nighttime Light Control The strobe and continuous nighttime light can be manually turned on and off. Set “Flash Auto/Manual” and “Night light Control” registers to Manual OFF or ON. Generate an Ethernet trigger or input TTL trigger to see Flash. The “Live” or “Snap” button does not generate Flash, because they are independent from normal trigger operation. -
Page 31: Time Synchronization
Page 19 TS-2030EN/TS-2076EN Series Progressive Scan Cameras 3.4 Time Synchronization The EN camera supports NTP (network time protocol) synchronization. If you disable NTP by clearing the “NTP Client Control” register, then the internal clock will drift approximately 1.5 seconds per day. To reset the clock, set the “Real Time Clock”... -
Page 32: Static Ip Address Assignment
If you know the current IP address of the camera, you can telnet directly to the EN camera. Login as User name = root, Password = JAI PULNiX. If you want to assign a new IP address temporarily, you can use the “ifconfig” utility. If you want to assign a new IP address permanently, you can use the “test_libcamera”... -
Page 33: Dhcp Client
Page 21 TS-2030EN/TS-2076EN Series Progressive Scan Cameras 3.5.1 DHCP Client Make sure that you have a DHCP server in your network. Change the “Static/Dynamic IP Address Allocation” register from “Static” to “Dynamic.” Reboot the camera. In the next power-up, the camera will get the IP address dynamically from the DHCP server. -
Page 34: Maintenance
Page 22 TS-2030EN/TS-2076EN Series Progressive Scan Cameras 3.6 Maintenance 3.6.1 Debug Counters For debugging purposes, some status registers are available as debug counters. Detailed information for each debugging counter is included in the LC-EN Interface document. This tutorial covers the following debug counters. •... -
Page 35: Firmware Upgrade
Page 23 TS-2030EN/TS-2076EN Series Progressive Scan Cameras By generating an Ethernet trigger (“All” and “HW Trigger” button on the EN setup video window), you can see only VINIT and IRQ counters are incrementing. This is because the first four counters are only for the hardware TTL trigger. -
Page 36: Rs-232 Powerpc Debug Port
Page 24 TS-2030EN/TS-2076EN Series Progressive Scan Cameras Firmware Names and Descriptions TABLE 1. Firmware Name Description Filename conversion EN Application Top-level application en_YYMMDDVR.app FPGA Bit file EPGA firmware FPGA_YYMMDDVR.bit OS Image Real-time Linux OS image vmlinux_YYMMDDVR.osi Lib/Drv file Library and driver package libdrv_YYMMDDVR.drv Camera Module H8 firmware... - Page 37 Page 25 TS-2030EN/TS-2076EN Series Progressive Scan Cameras The first method requires setting the Hyperterminal to the following setting (9600-8-N-1. No hardware handshake). Power up the EN camera. You should see the monitor message in the serial terminal. Type the “/” key within three seconds.
- Page 38 Page 26 TS-2030EN/TS-2076EN Series Progressive Scan Cameras After typing the “/” key, you should see the following monitor menu. Enter “3” to select “Change IP addresses” mode. Enter “1” to select Ethernet interface 1. Enter “1” again to select “Change local address. Enter the new IP address.
- Page 39 Page 27 TS-2030EN/TS-2076EN Series Progressive Scan Cameras Type “en -v > version.txt.” View the content of “version.txt” to see the firmware version Enter the command “ps” to see what processes are running. If the “dhcpc” daemon is running, kill this process.
- Page 40 Page 28 TS-2030EN/TS-2076EN Series Progressive Scan Cameras Enter the command “ifconfig eth0 <NEW IP ADDRESS> netmask <SUBNET MASK>.” This is a temporary IP assignment because the EN camera will lose this setting once you restart it. Now you should be able to telnet to the EN cameras. If you want to assign the new IP address permanently, you can use the “test_libcamera”...
-
Page 41: Uploading The Firmware
JAIPULNiX Type “en-v” to see the version numbers for all firmware currently running. #en-v > version.txt #more version.txt Welcome to JAI-PULNiX EN Camera EN version : 050812A0 OS version : 050810A0 Lib/drv version : 050812A0 FPGA version : 050805C0 4.1.2... -
Page 42: Updating The En Application Software
Page 30 TS-2030EN/TS-2076EN Series Progressive Scan Cameras 4.2 Updating the EN Application Software The EN setup software is used to update the EN application software. The method is described below. Uploading the Firmware TS-2030EN/TS-2076EN Series Progressive Scan Shutter Cameras Start the EN setup software. Click the “Properties”... -
Page 43: Updating The Firmware Manually When The Network Is Down
Page 31 TS-2030EN/TS-2076EN Series Progressive Scan Cameras Select “Update H8.” Reboot the EN camera for the changes to take effect. 4.7 Updating the Firmware Manually When the Network is Down It is sometimes necessary to update the firmware by hand when you do not have access to the network. This can happen, for example, if you have forgotten the IP address of the camera or when the update via the network fails. -
Page 44: Connectors And Cables
Page 32 TS-2030EN/TS-2076EN Series Progressive Scan Cameras Connectors and Cables 5.1 Connector Pin Configurations 5.1.1 12-Pin Connector 12-Pin Connector FIGURE 11. The TS-2030EN/TS-2076EN has a 12-pin Hirose connector for power input, serial communication, and signal integration. Pin #1 is Ground and pin #2 is +12V DC. Other pins handle a number of input and output functions, as shown in Table 2 on page 32. -
Page 45: 10/100 Baset Ethernet
Ethernet TxD A- Ethernet RxD B- Ethernet RxD B+ 5.2 RS-232 Communication Cable Serial Communications Cable RS-232B-12 (JAI Inc. part number: FIGURE 13. 310 132 19 The RS-232B-12 interface cable is used to debug the PowerPC processor. This debug port is useful when the network is down and RS-232 is the only choice to connect with the EN camera. -
Page 46: Power Supplies And Power Cable Setup
JAI Inc. Power Cables If you are using JAI Inc. power cables such as the 12P-02S, please refer to the 12-pin connector pin-out diagram. The cable pin-out diagram is shown in Figure 14 below. The color-coded leads use Gray for Ground and Yellow for +12V. -
Page 47: Building Your Own Power Cable
Page 35 TS-2030EN/TS-2076EN Series Progressive Scan Cameras 12P-02S Interface Cable (optional) FIGURE 14. 12P-02S Interface Cable Pin# Lead Color Function Pin# Lead Color Function Gray Black coax Reserved Yellow +12V DC White coax shield Reserved Red coax shield AGND White coax Reserved Red coax Video Out... -
Page 48: Camera Features
Page 36 TS-2030EN/TS-2076EN Series Progressive Scan Cameras Camera Features 6.1 Progressive Scanning Standard TV-system scanning is 525 lines interlace scanning as specified in the RS-170 protocol. Every other horizontal line (odd lines and even lines) is scanned at a 60Hz rate per field, and the scanning is completed with two fields (one frame) at 30Hz rate. -
Page 49: Figure 15. Timing Chart
Page 37 TS-2030EN/TS-2076EN Series Progressive Scan Cameras Timing Chart 1 FIGURE 15. Camera Features... -
Page 50: Adr (Automatic Dynamic Range) Control
Page 38 TS-2030EN/TS-2076EN Series Progressive Scan Cameras 6.3 ADR (Automatic Dynamic Range) Control ADR (Automatic Dynamic Range) control is a key algorithm of EN cameras. The ADR algorithm controls the EN camera parameters on a continuous basis to maintain the contrast-to-noise of the license plates on passing vehicles to a suitable level required for automatic license plate reading algorithms. -
Page 51: Video Amplifier Gain Control
Page 39 TS-2030EN/TS-2076EN Series Progressive Scan Cameras When the EN camera is controlled by light sensor, user can monitor the shutter value in EN setup software by accessing "Camera Shutter" status register (Address = 233). Note that this Shutter value is dial number and not actual exposure time, (left side of the table above). -
Page 52: Flash/Nighttime Light Control
Page 40 TS-2030EN/TS-2076EN Series Progressive Scan Cameras TABLE 8. Gain Table (Color EN Camera) Gain Value 11.8 13.4 15.1 17.0 19.2 21.7 23.4 25.5 27.8 27.7 Note: Gain Value is Gain entry in camera LUT after calibration. When the EN camera is controlled by a light sensor, user can monitor the gain value in the EN setup software by accessing "Camera Gain"... -
Page 53: Ethernet
The color filter array requires software to interpolate color. If the proper interpolation software is not present the camera provides an 8-bit monochrome image. The necessary DLL is available from JAI Inc.. The JAI Inc. TSC-2030EN/TSC-2076EN cameras use the Bayer color mosaic filter pattern (see Figure 16 below). The CFA contains 50% green photo sites and 25% red and 25% blue photo sites. -
Page 54: Image Formats
Page 42 TS-2030EN/TS-2076EN Series Progressive Scan Cameras Because the TSC-2030EN/TSC-2076EN does not contain internal color-processing circuitry, viewer software must perform color interpolation on host PC side. The EN setup software supports color interpolation. After color interpolation, white balance must be properly done. Otherwise, gray or white objects cannot be seen as gray or white. -
Page 55: Image Transfer
Page 43 TS-2030EN/TS-2076EN Series Progressive Scan Cameras If JPEG quality factor is high (above 85) and image contains complex detail information, the output file size of JPEG encoding becomes larger. JPEG image size must be properly defined in “Storage Setup” of JPEG. -
Page 56: Image Buffering
An API (application program interface) for Windows is available. Using an API, the time required to develop software for device discovery, command communication, and image transfer can be shortened. Please contact JAI Inc. for further information. 6.9 Image Buffering Full size TIF images, JPEG images, and ODD/EVEN field images are independently managed in image buffers. -
Page 57: Ntp (Network Time Protocol)
Page 45 TS-2030EN/TS-2076EN Series Progressive Scan Cameras FTP server's IP address, username, password, and subdirectory name must be properly set by FTP command. Additionally, a 2nd FTP server is supported in case the 1st FTP server is accidentally down. Please refer to the “EN-to-LC Interface” document for the FTP command. Additionally, the FTP server must be properly set up. -
Page 58: Frequently Asked Questions And Troubleshooting
Page 46 TS-2030EN/TS-2076EN Series Progressive Scan Cameras Frequently Asked Questions and Troubleshooting 7.1 Problem 1: What Password Allows Login from a RS232 Debug Port or Telnet Session to the EN Camera? User name = root, password = JAIPULNiX 7.2 Problem 2: What is a Password to Start the EN Setup Software? The factory default setting is, user name = Administrator;... -
Page 59: Problem 6: Ttl Trigger/Ethernet Trigger/Serial Rs-485 Trigger Does Not Generate Trigger
Page 47 TS-2030EN/TS-2076EN Series Progressive Scan Cameras If you want to manually set camera parameters instead of light sensor control, you can do so by using EN setup software. In Video control window, right-click on the camera icon. Select “Manual Video Adjust.”... -
Page 60: Problem 9: Ftp Servers Switch Between Primary Server And Second Server, Even If The Hard Disk Is Not Full
7.9 Problem 9: FTP servers switch between primary server and second server, even if the hard disk is not full. 1. JAI has tested various FTP servers to compare performance differences. For Linux, we recommend PureFTP server. We do not recommend vsFTP server. For Windows, we recommend Cerberus FTP server. -
Page 61: Problem 12: Io Board Communication Error
Page 49 TS-2030EN/TS-2076EN Series Progressive Scan Cameras Make sure to set UDP mode in EN LightSensor register. If you want the EN camera to connect multiple MOXA devices (up to 2 MOXAs), do not assign the same port number for performance reasons. Assign different port numbers. For TCP connections (not recommended, but for customers who require TCP connections). -
Page 62: Problem 14: The Day Time Image Is Too Bright And Whites Out Or Saturates The License Plate
For further information and support: Phone: (408) 383-0300 (Request ITS technical support when the telephone call is answered.) (800) 445-5444 Fax: (408) 383-0301 E-mail: imaging@jai.com Mail: JAI Inc. Sales Department 625 River Oaks Parkway San Jose, CA 95134 ATTN: Video Applications Web Site: www.jai.com... -
Page 63: Appendix
1920 (H) x 768 (V) Resolution Digital: 1920 (H) x 512 (V) S/N Ratio 50dB min (BW) 48dB min. (Color) Video Output Digital output: JAI Inc. proprietary protocol over TCP/IP Gamma Gamma 0.55 forBW Linear for Color Lens Mount C-mount Power Req. -
Page 64: Physical Dimensions
Page 52 TS-2030EN/TS-2076EN Series Progressive Scan Cameras 8.2 Physical Dimensions Physical Dimensions FIGURE 18. 8.3 Spectral Response Spectral Response (B/W CCD for TS-2030EN/TS-2076EN) FIGURE 19. Appendix... -
Page 65: Figure 20. Spectral Response (Color Ccd For Tsc-2030En/Tsc-2076En)
Page 53 TS-2030EN/TS-2076EN Series Progressive Scan Cameras Spectral Response (Color CCD for TSC-2030EN/TSC-2076EN) FIGURE 20. TABLE 11. IR Cut Filter Optical Characteristics TABLE 11. Wavelength Transmission from 450 to 650 nm Average 80% above 730 ±20 am Average 50% from 800 to 1,150 nm Average 10% below Appendix... - Page 66 Page 54 TS-2030EN/TS-2076EN Series Progressive Scan Cameras Appendix...
- Page 67 Page 55...
- Page 68 See the possibilities JAI Inc. San Jose, CA 95134 625 River Oaks Pkwy Tel: 408 383 0300 Tel: 800 445 4444 Email: imaging@jai.com www.jai.com w w w . j a i p u l n i x . c o m 10490 Rev.
