User's Manual
TM/TMC-2030GE
Progressive Scan Cameras
Document Version: C
Document P/N:10446

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the RM-2030GE and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for JAI RM-2030GE

  • Page 1 User’s Manual TM/TMC-2030GE Progressive Scan Cameras Document Version: C Document P/N:10446...
  • Page 2 TM/TMC/RM/RMC-2030GE - ii -...
  • Page 3 The material contained in this manual consists of information that is proprietary to JAI Inc., and may only be used by the purchasers of the product. JAI Inc. makes no warranty for the use of its product and assumes no responsibility for any errors which may appear or for damages resulting from the use of the information con- tained herein.
  • Page 4 Changes or modifications to this unit not expressly approved by the party responsible for FCC compliance could void the user’s authority to operate the equipment. TM-2030GE Series Operation Manual JAI Inc. 625 River Oaks Parkway San Jose, CA 95134 Tel:(408) 383-0300...
  • Page 5 TM/TMC/RM/RMC-2030GE - v -...
  • Page 6 TM/TMC/RM/RMC-2030GE - vi -...
  • Page 7: Table Of Contents

    TM/TMC/RM/RMC-2030GE Table of Contents Table of Contents ..........vii List of Figures .
  • Page 8: Table Of Contents

    TM/TMC/RM/RMC-2030GE GigE Series Camera Serial Commands ....... . . 25 Introduction .
  • Page 9 TM/TMC/RM/RMC-2030GE 10.5 Electronic Shutter ........56 10.5.1 Programmable Exposure-Continuous Mode .
  • Page 10 TM/TMC/RM/RMC-2030GE Table of Contents - x -...
  • Page 11: List Of Figures

    Figure 45. The setting does not activate until the Send Knees button is clicked..39 Figure 46. Please contact JAI, Inc. for password access......39 Figure 47.
  • Page 12 TM/TMC/RM/RMC-2030GE Figure 48. GigE Ethernet Connector ........45 Figure 49.
  • Page 13 TM/TMC/RM/RMC-2030GE List of Tables Table 1. Hirose Connector, Pin Assignment ....... . .6 Table 2.
  • Page 14 TM/TMC/RM/RMC-2030GE List of Tables - xiv -...
  • Page 15: Software Introduction

    1Software Introduction 1.1 Scope of the Document This manual describes how to access and use features of the JAI Gigabit Ethernet camera, the TM- 2030GE. The camera’s different operation modes are described in the hardware section of this man- ual, which begins on page 41.
  • Page 16: Software Installation

    To install the JAI GigE camera-control software, read and follow the directions included in the docu- ment download card. If the computer does not have Internet access, call JAI Inc. at 1 800 445-5444 to request the software on a CD-ROM.
  • Page 17: Uninstalling The Software

    1.4.3 Uninstalling the Software To uninstall the JAI GigE camera-control software from the control panel, use the following steps: 1. Open Add or Remove Programs in the control panel. 2. Select JAI Cam2Net from the list of installed software.
  • Page 18: Quick-Start

    TM/TMC/RM/RMC-2030GE Figure 3. Change and Remove Buttons 1.4.4 Quick-Start Use the following quick-start process when the Camera Interface Application is installed on your PC. 1. Connect the camera. The Hirose pin layout is shown in Table 1 on page 6. Both the Hirose and the network cable (RJ-45) are illustrated in Figure 6.
  • Page 19: Figure 5. Select Camera Window

    TM/TMC/RM/RMC-2030GE Figure 5. Select Camera Window 5. Go to the Acquisition tab and click Start. An image stream should appear. 6. Click on the Configure button at the bottom of the Coyote screen, and open the GigE Camera Software dialog box. This is your integrated control software. Note: The color version (TMC-2030GE) requires that color interpolation be performed using the host computer’s CPU.
  • Page 20: Connectors

    TM/TMC/RM/RMC-2030GE 2 Connectors The camera has two sockets, as shown in Figure 6 below: • 12-pin Hirose for power, trigger, RS-232 communication and TTL I/O. • RJ-45 for Gigabit Ethernet. Figure 6. TM-2030GE Back Panel Connectors GigE POWER These connectors are described in Section 2.1 and Section 2.2. 2.1 Power and Signals Connector The GE camera receives power and signal through a 12-pin Hirose connector.
  • Page 21: Ethernet

    PC, you must use a cross-over cable. Refer to the Cam2Net User's Manual for details. Figure 8. Ethernet GigE Socket GigE 1. JAI recommends the use of shielded cables to reduce emissions and for CE/FCC compliance. Double-shielded cables further reduce emissions. - 7 - Connectors...
  • Page 22: Configuring The Tm-2030Ge Camera

    TM/TMC/RM/RMC-2030GE 3 Configuring the TM-2030GE Camera The configuration of the GigE camera consists of two parts: • The imager configuration (CCD and control circuits) • The internal frame grabber configuration The imager can be configured for partial scan, binning, and so on, just like a Camera Link camera. The internal frame grabber is automatically configured for the pixel type, windowing, image size, I/O and so on, by the GigE camera software.
  • Page 23: To Use The Integrated Gige Camera Software

    TM/TMC/RM/RMC-2030GE 3.1.1 To use the integrated GigE camera software: 1. Start the Camera Interface Application (this is the Coyote application used above). The dialog box shown in Figure 9 appears. 2. Click the Detect button to detect the device and driver in the “Device Actions” panel. 3.
  • Page 24: Configuring The Imager

    TM/TMC/RM/RMC-2030GE 3.2 Configuring the Imager To configure the TM-2030GE’s imager, use the integrated GigE camera software that is part of the Cam2Net Camera Interface Application. You can also use the dual-tap AccuPiXEL GigE control tool, but that will not update any internal grabber settings. See “Hardware Introduction” on page 41. for a description of the different image settings of the camera.
  • Page 25: Gui Features

    TM/TMC/RM/RMC-2030GE 3.2.1 GUI Features You can control the following camera functions using the integrated camera software. • Shutter Speed and Mode • Scan Mode • Gain Control • Offset Level • Memory Pages • LUT (Look-Up Table) Control • 8, 10, 12-bit Selectable •...
  • Page 26: Exposure Control

    TM/TMC/RM/RMC-2030GE Figure 12. Advanced Configuration - Port Communication 3.4.2 Exposure Control In Exposure Control, under the GigE Camera software tab, shown in Figure 13, you can specify the shutter mode and set the shutter speed and direct shutter values. Figure 13. Exposure Control Configuring the TM-2030GE Camera - 12 -...
  • Page 27: Figure 14. Mode Control Pull-Down

    TM/TMC/RM/RMC-2030GE 3.4.2 (a) Shutter Mode The exposure control has two different settings. Select the desired setting using the drop down list box shown in Figure 14. Figure 14. Mode Control Pull-down Shutter Speed The shutter speed setting, shown in Figure 15, allows you to select the specific shutter speed for manual shutter and Async shutter.
  • Page 28: Gain Settings

    TM/TMC/RM/RMC-2030GE 3.4.3 Gain Settings 3.4.3 (a) Gain The Gain Settings control box allows you to change the Gain value from 0 to 4095. Change the value by clicking on the up or down button beside the current setting or enter the value directly into the text box.
  • Page 29: Offset Level

    TM/TMC/RM/RMC-2030GE Figure 19. Gain Settings Checkbox Cleared If the camera has a high gain setting it takes longer to balance the channel. Channel Balance may not work properly if a high-speed shutter is used under a low-frequency light, such as a fluorescent light. 3.4.4 Offset Level The Channel A offset level is the master, channel B is the slave.
  • Page 30: Look-Up Table

    TM/TMC/RM/RMC-2030GE 3.4.5 Look-Up Table The look-up table (LUT) control, shown in Figure 21, allows you to change two knee point values. Figure 21. Look-Up Table Enter X values directly to adjust the knee curve. In the integrated camera software, the look-up table can also be controlled interactively.
  • Page 31: Free-Running Mode

    1. Page 0 is password-protected and you cannot write to it. If you find that you do need to write to page 0, contact JAI Inc. for password access. Note: Configurations such as grabber settings, pulse generator, GPIO, and image setting must be saved into the XML file.
  • Page 32: White Balance Control (Color Versions Only)

    TM/TMC/RM/RMC-2030GE The XML file will not, however, save camera parameters such as shutter mode, shutter speed, gain settings, offset level, scan mode, and LUT. For more information about saving these camera parame- ters, please refer to Section 3.4.6, “Memory Pages,” on page 16. 3.4.11 White Balance Control (Color Versions Only) To determine white balance, use the following steps: 1.
  • Page 33: Version

    TM/TMC/RM/RMC-2030GE 3.4.13 Version View the version number of the Cam2Net camera interface application by clicking on Help=>About. The version number of the integrated GigE camera software is seen in a text box control called Ver- sion in the GigE Camera tabbed dialog box. 3.4.14 Exit From the main menu, select File, and click Exit to exit the software.
  • Page 34: Figure 24. Ge Camera Gpio Control Block

    TM/TMC/RM/RMC-2030GE Figure 24. GE Camera GPIO Control Block EXT_VD EXT_HD TTLIN(EXT_TRIG) TTLOUT(STROBE) TTLIN(EXT_VD) CTRL2 EVINIT TTLIN(EXT_HD) INTG_CON CTRL1 TTLN(INT) CAM_STROBE 8-to-16 CTRL0 TRIG RESV pulse_out0 pulse_trig0 Pulse_Gen0 pulse_out1 pulse_trig1 Pulse_Gen1 pulse_out2 pulse_trig2 Pulse_Gen2 pulse_out3 pulse_trig3 Pulse_Gen3 Inputs I0 through I7 can be either external or internal inputs to the look-up table. The outputs are used by the imager part of the GE camera.
  • Page 35: Figure 25. Gpio Look-Up Table

    TM/TMC/RM/RMC-2030GE Figure 25. GPIO Look-Up Table Q0 = I4 Figure 26. The GPIO Configuration - 21 - Signal Handling...
  • Page 36: Gpio Label Table

    TM/TMC/RM/RMC-2030GE 4.4 GPIO Label Table Table 2 shows which GPIO inputs carry the different signals. The top line for each label contains the default signal. Table 2. GPIO Look-Up Table Input Labels Input Signal Description Label TTL_IN(EXT_TRIG) TTL-input 0. Used for external trigger. Internal signal.
  • Page 37: Table 3. Gpio Look-Up Table Output Labels

    TM/TMC/RM/RMC-2030GE Table 3 shows which output labels carry the output signals. Table 3. GPIO Look-Up Table Output Labels Output label Signal Description TTL-OUT(STROBE) Strobe output EVINIT Trigger INTG_CON Integration control EXT_VD Vertical Drive EXT_HD Horizontal Drive pulse_trig1 Pulse Generator 1 gets its trigger here pulse_trig0 Pulse Generator 0 gets its trigger here pulse_trig3...
  • Page 38: Pulse Generators

    TM/TMC/RM/RMC-2030GE 4.5 Pulse Generators The TM-2030GE camera has four independently programmable pulse generators. These generators can run as either periodic or triggered. To run the pulse generators as triggered, they can be trig- gered on either levels or signal edges. These generators can be tied to the camera inputs (camera- control lines).
  • Page 39: Gige Series Camera Serial Commands

    TM/TMC/RM/RMC-2030GE 5 GigE Series Camera Serial Commands You can control the GigE series cameras by serial command either using RS-232 or Camera Link. The Start character is always “:” and the End character is always <CR> (return). For example, to set Asyn- chronous Pulse Width Mode, send the command :ASH=9<CR>...
  • Page 40 TM/TMC/RM/RMC-2030GE Command Parameter End of Cmd Ack. Response Description :NLUT <cr> :o<cr> Set Positive Knee or Negative Knee (X = 0 Positive, X = 1 Negative) :LUT? <cr> :o[lut]<cr> Inquire current LUT setting Channel Balance :EABL <cr> :oAB0<cr> Enable Gain Balancing :DABL <cr>...
  • Page 41: Table 5. Command Responses

    TM/TMC/RM/RMC-2030GE Command Parameter End of Cmd Ack. Response Description :CCS= <cr> :o<cr> Select Camera Control signals (X = 0 CL Conn, X = 1 Hirose Conn) :TAH= <cr> :o<cr> External Trigger Polarity (X = 1 Active High, X = 0 Active Low) :TPTN <cr>...
  • Page 42 TM/TMC/RM/RMC-2030GE Command Parameter End of Cmd Description Bit 6 Data Depth 0 00=8bit 01=10bit Bit 7 Data Depth 1 10=12bit Byte 11 Function Flag 2 Bit 0 Look-up table 0 00=Linear 01=Gamma.45 Bit 1 Look-up table 1 10=User Knee Table Bit 2 Rsvd Camera Control...
  • Page 43: Introduction

    Cam2Net to configure camera functionality. The Cam2Net and AccuPiXEL software can not run simultaneously. The Dual-Tap AccuPiXEL series cameras are high-resolution, progressive scan cameras with JAI, Inc.- proprietary LUT control and other excellent features. The software for these cameras was developed to function as standard software for the entire Dual-Tap AccuPiXEL series, and can open either the RS-232 serial port (COM) or Camera Link.
  • Page 44: Figure 28. The Setup Icon Installs Dual Tap Accupixel V 2.5.X.x

    TM/TMC/RM/RMC-2030GE 6.1.2 Installing the Software To install the Dual-Tap AccuPiXEL series camera-control software, obtain the software from the JAI, web site and run “Setup.exe.” The installer will direct you to install the application code. If dual tap software is already installed on your computer, uninstall the software using the steps in the Uninstall section.
  • Page 45: Uninstalling The Software

    6.3 Using the GigE mode • The IP address is initially configured using the Coyote software provided by JAI, Inc. To obtain the software visit the JAI, Inc. web site, customer support link (http://www.pulnix.com/Support/ SWdownload.php). To review IP address assignment see “Quick-Start” on page 4...
  • Page 46: Gui Features

    TM/TMC/RM/RMC-2030GE 7GUI Features The following is a list of camera functions that PC serial commands can control. The Dual-Tap Accu- PiXEL series Camera Link cameras use differential serial communication through the Camera Link con- nector on the rear panel of the camera. The interface shown here is for the TM/TMC 2040 CL cameras.
  • Page 47: Operating The Control Software

    TM/TMC/RM/RMC-2030GE 7.1 Operating The Control Software 7.1.1 Exposure Control The TM-2030CL exposure control allows you to select Continuous or Trigger modes using the appropri- ate radio button. Notice that Continuous and Trigger mode offer slightly different menus. 7.1.1 (a) Continuous Mode Shutter Speed The Shutter Speed drop-down list box allows you to select the specific shutter speed for manual shut- ter and Async shutter.
  • Page 48: Configuring Trigger Settings

    TM/TMC/RM/RMC-2030GE 7.1.1 (c) Programmable Shutter Speed “Programmable” Shutter Speed is set by entering a number in the “Expo (lines)” text box. Program- mable is available in Continuous or Trigger mode. The Expo setting is used instead of the Scan Area selection.
  • Page 49: Gain Control

    TM/TMC/RM/RMC-2030GE 7.1.2 (b) PIV Fixed Exposure In Particle Imaging Velocimetry (PIV) Fixed Exposure Mode, when an external trigger is applied, the first time exposure starts the same as PWC mode does. It lasts a very short period (8µs). The second time exposure starts during the transferring time of the first image accumulated in the first exposure time.
  • Page 50: Offset Voltage

    TM/TMC/RM/RMC-2030GE 7.1.4 Offset Voltage Offset is changed by raising on lowering the number in the “Master Offset” or “R Fine Offset” box either by clicking on the arrows or typing a new value in the box. Checking the “Auto Offset” check box causes the camera to automatically adjust the offset. The camera continues to adjust the offset unless the user unchecks the auto offset;...
  • Page 51: Lut (Look-Up Table)

    TM/TMC/RM/RMC-2030GE Figure 40. Image Pre-processing Cover the lens with the lens cap before enabling the blemish calibration. Activate this control by clicking the Blemish Calibration button and then check the “Enable Blemish Compensation” check box. The blemish compensation activates. Note: Blemish Calibration is necessary only after a camera has been powered off and restarted.
  • Page 52: Figure 43. Table Drop Down Menu

    TM/TMC/RM/RMC-2030GE Figure 43. Table drop down menu: The Table drop down menu offers three options. The Linear option gathers light in a proportional manner. In this particular selection the LUT is config- ured to speed the light gathering capability at the beginning of the exposure. The Gamma.45 option is designed to cause the camera to gather light for a result very similar to what the human eye sees.
  • Page 53: Main Menu: "Option

    When you have chosen the value you want and are ready to set this value to the camera, click the “Send Knees” button. 7.1.8 Main Menu: “Option” 7.1.8 (a) Password The password allows access to the EEPROM to rewrite factory default settings. Figure 46. Please contact JAI, Inc. for password access. - 39 - GUI Features...
  • Page 54: Eeprom

    TM/TMC/RM/RMC-2030GE 7.1.9 EEPROM Dual-tap AccuPiXEL cameras have seven pages available to restore the camera settings. Page 0 is the factory default page and cannot be edited without a password. Page 1 is power up default. This page will allow you to save default setting to load at power up. 7.1.9 (a) Load Page From the main menu, select “file”...
  • Page 55: Hardware Introduction

    Operation Manual 8 Hardware Introduction 8.1 Product Description The JAI, Inc. TM-2030GE series is a Gigabit Ethernet output, high-resolution progressive scan CCD camera. The interline-type CCD permits full vertical and horizontal resolution of very high speed shutter images and applications. The electronic shutter, which has speeds to 1/26,000 sec., can be reset asynchronously by external pulse control.
  • Page 56 TM/TMC/RM/RMC-2030GE High-speed electronic shutter capability for high dynamic resolution of moving objects that eliminates the need for a mechanical shutter. Progressive scan CCD eliminates interlace deterioration of image and increases ease of com- puter interface. High sensitivity and low noise during fast scanning. The CCD has an excellent S/N ratio at the default setting that is greater than 54dB.
  • Page 57: Installation

    9.1.2 Components When you receive your TM-2030GE camera from JAI, Inc., the contents of the shipping box should include the camera and a document download card. If either of these items are missing, please con- tact your JAI, Inc.
  • Page 58: Camera Setup

    For optimal performance, JAI, Inc. recommends using a cooling fan to set up a positive air flow around the cam- era and following the precautions below.
  • Page 59: Power Supplies And Power Cable Setup

    The TM-2030GE camera requires 12V DC power that is obtained through the 12-pin connector located on the rear panel of the camera. JAI, Inc. power supplies feature a 122-240V AC/12V DC 1.2A univer- sal voltage power supply. JAI, Inc. recommends the following power supplies:...
  • Page 60: Figure 49. 12P-02S Interface Cable (Optional)

    JAI, Inc. Power Cables If you are using JAI, Inc. power cables such as the 12P-02S, please refer to the 12-pin connector pin- out diagram below. The cable pin-out diagram is shown in Figure 49. The color-coded leads use Gray for Ground and Yellow for +12V.
  • Page 61: Attaching The Camera Lens

    TM/TMC/RM/RMC-2030GE 9.2.4 Attaching the Camera Lens The TM-2030GE camera accepts 1-inch or larger format size C-mount lenses. To attach the C-mount lens to the camera, carefully engage the threads and rotate the lens clockwise until it firmly seats on the mounting ring. Do not force the lens if it does not seat properly. Some lenses with extremely long flange backs may exceed the mounting depth of the camera.
  • Page 62: Operation

    TM/TMC/RM/RMC-2030GE Figure 50. Back Focus Set-Screw Locations Loosen the three 2mm screws around the perimeter of the C-mount lens collar to adjust the backfocus. Unless you absolutely must, do not attempt to adjust this focus. 10 Operation 10.1 Progressive Scanning Standard TV-system scanning is 525 lines interlace scanning as specified in the RS-170 protocol.
  • Page 63: Preset Scan Area

    TM/TMC/RM/RMC-2030GE 10.1.1 Preset Scan Area TM/TMC-2030GE has full scan mode, all active lines of the CCD sensor, 1080 lines, are transferred out line by line. 10.1.2 Full Scan Area 2x2 Binning TM/TMC-2030GE has a 2x2 binning of the full scan area. In 2x2 binning mode, pixel (i, j) includes all the information of pixel (2i-1, 2j-1), (2i-1, 2j), (2i, 2j-1) and (2i, 2j) in normal full scan mode (where i=1 2, ..., 800;...
  • Page 64: Bayer Color Filter (Color Versions)

    On-chip micro lenses mean increased sensitivity. 10.2.1 Color Filter Array JAI, Inc. AccuPiXEL cameras use Bayer CFA (color filter array) as their standard primary color filter. This filter provides the most popular color interpolation supported by numerous software suppliers.
  • Page 65: Bayer Color Filter Array (Cfa)

    TM/TMC/RM/RMC-2030GE 10.2.2 Bayer Color Filter Array (CFA) The Bayer CFA is an R, G, B primary color filter array. This is the most widely accepted CFA for the single-chip CCD progressive scan format. This type of array layout has a specific order for each color’s pixels.
  • Page 66: Starting Pixel Configuration

    G/B start and B/G start. Once the correct scanning is configured, the rest of the interpola- tion is exactly the same. Contact JAI, Inc. for further information regarding CCD manufacturers. Figure 53. Example of Color CCD CFA Pattern...
  • Page 67: Sync And Data

    TM/TMC/RM/RMC-2030GE 10.2.4 Sync and Data The individual color data is exactly the same as the pixel data. This means that the timing relation- ships of the color cameras are also the same as of the monochrome cameras. For a detailed timing chart, please refer to each monochrome camera’s data sheet and manual. The following diagram is an example of the TMC-2030GE default mode.
  • Page 68: Camera Functions

    All AccuPiXEL color cameras are carefully designed for maximum color performance. JAI, Inc. strongly suggests that you use digital output for the best performance. Some software is used on board (FPGA or DSP) to perform the interpolation. Other software simply uses the host computer’s memory and CPU.
  • Page 69: Dynamic Range Control

    TM/TMC/RM/RMC-2030GE 10.3 Dynamic Range Control Figure 55. Output and Blooming Blooming adj. = 13. 5 V Lens: F=5.6 Vsub = 8 V Max. Digital dynamic range at 3 dB amp Vsub = 10 V Vsub = 12 V Vsub = 14 V Vsub = 16 V Digital saturation at 16 dB amp Vsub = 18 V...
  • Page 70: External Sync And Pixel Locking

    TM/TMC/RM/RMC-2030GE 10.4 External Sync and Pixel Locking The TM-2030GE accepts an external sync of standard HD and VD at TTL level for general locking to a system sync and clock. The frequency requirement is as follows: Full Progressive Scan: fHD = 36.36 KHz ± 2% fVD = 32.32 Hz ±...
  • Page 71: Asynchronous No Shutter Mode

    TM/TMC/RM/RMC-2030GE 10.5.2 Asynchronous No Shutter Mode In Asynchronous No Shutter Mode, applying the external trigger starts a camera scan reset. The cam- era finishes the line it is scanning and scans an additional 9 video lines, this charge is sent to the hor- izontal register.
  • Page 72: Asynchronous Programmable Exposure Mode

    TM/TMC/RM/RMC-2030GE 10.5.3 Asynchronous Programmable Exposure Mode In Asynchronous Programmable Exposure Mode, when an external trigger is applied, the exposure starts after one discharge signal (Vsub), which happens after the trigger’s active edge is off. Because the discharge signal (Vsub) synchronizes with LDV in this mode, there is a maximum one video line of jitter between the trigger active edges to discharge signals (Vsub) off.
  • Page 73: Pulse Width Control Mode

    TM/TMC/RM/RMC-2030GE 10.5.4 Pulse Width Control Mode In Pulse Width Control (PWC) Mode, the exposure time is controlled by the external trigger. When an external trigger is applied, one discharge signal (Vsub) is generated right after the active edge of the trigger.
  • Page 74: Particle Imaging Velocimetry Fixed Exposure Mode

    TM/TMC/RM/RMC-2030GE 10.5.5 Particle Imaging Velocimetry Fixed Exposure Mode In Particle Imaging Velocimetry (PIV) Fixed Exposure Mode, when an external trigger is applied, the first time exposure starts the same as PWC mode does. It lasts a very short period (8µs). The second time exposure starts during the transferring time of the first image accumulated in the first exposure time.
  • Page 75: Pwc Piv Mode

    TM/TMC/RM/RMC-2030GE 10.5.6 PWC PIV Mode The PWC PIV is based on PIV Fixed Exposure. In this mode, the first time exposure is controlled by the pulse width of the external trigger, which is similar to PWC mode. The real exposure time of the first image is equal to the pulse width of the external trigger.
  • Page 76: Camera Timing Charts

    TM/TMC/RM/RMC-2030GE 10.6 Camera Timing Charts Figure 61. Camera Timing Chart Figure 62. Digital Data Output Order for Configuration Operation - 62 -...
  • Page 77: Figure 63. Field Video Timing--Continuous Mode

    TM/TMC/RM/RMC-2030GE Figure 63. Field Video Timing--Continuous Mode - 63 - Operation...
  • Page 78: Troubleshooting

    Following are troubleshooting tips for common problems. In general, the problems listed in this sec- tion are solved by following these instructions. If there is no solution listed to the problem you are encountering, contact a JAI, Inc. representative. 11.1.1 Symptom: No Video Remedies: Check that the following are properly connected and operational.
  • Page 79: Symptom: Notebook Computer Driver Installation Problems

    Remedies: The IBM T-42 laptop is unable to properly install. 11.1.6 Information and Support Resources For further information and support: North American Technical Support Phone 408-383-0300 E-Mail: camerasupport@jai.com European Technical Support Phone: +45 4457 8916 E-Mail: camerasupport@jai.com Japan/Asia Technical Support Phone +81 45 440 0154 E-Mail: tsh@jai.com...
  • Page 80: Appendix

    TM/TMC/RM/RMC-2030GE 12Appendix 12.1 Specifications Table 9. TM-2030GE Camera Specifications Table Feature TM-2030GE Sensor 1" progressive scan interline transfer CCD Active Area 14.2mm x 8.0mm Active Pixels 1920 (H) x 1080 (V) Cell Size 7.4µm x 7.4µm Readout Mode 1920 (H) x 1080 (V) @ 32 Hz (dual tap) or 16 Hz (single tap) selectable (Active Pixels) Sync Internal/External auto switch...
  • Page 81: Tm-2030Ge Physical Dimensions

    TM/TMC/RM/RMC-2030GE 12.1.1 TM-2030GE Physical Dimensions Figure 64. Physical Dimensions 4X M3 X – 6.0 [0.23] ┬ 40.8 [1.60] 1”– 32 50.8 GigE POWER 40.8 [2.00] [1.60] 25.4 [1.00] Gigabit Ethernet 7.0 [0.28] 17.7 [0.70] 25.4 [1.00] EFFECTIVE 50.8 [2.00] IMAGE AREA 85.2 [3.35] 93.9 [3.69] 22.0 [0.87]...
  • Page 82: Spectral Response

    TM/TMC/RM/RMC-2030GE 12.1.2 Spectral Response Figure 65. Spectral Response 0.35 0.25 0.15 0.05 1000 Wavelength (nm) 0.45 0.40 0.35 0.30 0.25 0.20 0.15 0.10 0.05 0.00 1000 Wavelength (nm) Appendix - 68 -...
  • Page 84 User’s Manual Europe, Middle East & Africa Phone +45 4457 8888 Fax +45 4457 8880 Asia Pacific Phone +81 45 440 0154 Fax +81 45 440 0166 Americas Phone (Toll Free) 1 800 445 5444 Phone 1 408 383 0301...
