- Page 1 TS-2030EN/TS-2076EN/ TS-1327EN Series Progressive Scan Cameras Document Version: C Document P/N:10490...
- Page 3 The material contained in this manual consists of information that is proprietary to JAI Inc., and may only be used by the purchasers of the product. JAI Inc. makes no warranty for the use of its product and assumes no responsibility for any errors which may appear or for damages resulting from the use of the information contained herein.
- Page 4 Changes or modifications to this unit not expressly approved by the party responsible for FCC compliance could void the user’s authority to operate the equipment. EN Camera Series Operation Manual JAI Inc. 625 River Oaks Parkway San Jose, CA 95134...
-
Page 5: Table Of Contents
RS-232 Communication Cable ............... 26 Power Supplies and Power Cable Setup ............27 5.3.1 Power Supplies ..................27 5.3.2 JAI Inc. Power Cables ................27 5.3.3 Building Your Own Power Cable ..............28 5.3.4 Attaching the Power Cable to the Connector ............ 28 Attaching the Camera Lens................ - Page 6 EN Camera Series Camera Features..................29 Progressive Scanning ................. 29 Asynchronous Reset .................. 29 ADR (Automatic Dynamic Range) Control ............32 6.3.1 Camera ADR Control Related Registers ............32 6.3.2 Electronic Shutter ..................33 6.3.3 Video Amplifier Gain Control ............... 34 Flash/Nighttime Light Control ..............
- Page 7 12-Pin Connector..................25 Figure 12. 26-Pin HD-Sub Connector ................25 Figure 13. Serial Communications Cable RS-232B-12 (JAI Inc. part number: 310 132 19)....26 Figure 14. 12P-02S Interface Cable (optional) ..............27 Figure 15. Timing Chart 1 (TS-2030EN) ................. 30 Figure 16.
- Page 8 EN Camera Series viii List of Figures...
- Page 9 EN Camera Series List of Tables Table 1 Firmware Names and Descriptions ..............17 Table 2 12-Pin Connector..................25 Table 3 D-Sub Connector Pinout Configuration (10226-6212 VC) ........25 Table 4 10/100 BaseT Ethernet Pinout Configuration ............ 26 Table 5 EN Exposure Times..................
- Page 10 EN Camera Series List of Tables...
-
Page 11: Introduction
EN Camera Series 1. Operation Manual Introduction 1 Introduction 1.1 Scope of this Manual This manual covers the operation of the following traffic control cameras: the TS-2030EN, TSC- 2030EN, TS-2076EN, TSC-2076EN, TS-1327EN, and TSC-1327EN. The remainder of this manual will use the term “EN camera”... - Page 12 EN Camera Series Typical applications include Automatic Number Plate Reader (ANPR/ LPR), vehicle fingerprints (vehicle matching technology), optical character recognition (OCR), and region-of-interest extraction (ROI), as used in the market for ITS (Intelligent Transportation Systems). The EN camera supports external event triggering, dynamic light sensor, and provides the best quality and sensitivity images for ITS applications.
-
Page 13: Getting Started
• Cat5e/6 Ethernet cable • 10/100/1000 Ethernet switch • Debug-232 serial/power cable (JAI Inc. part number 31013219) 2.2 Network Settings 2.2.1 Default Network Settings for the EN Camera The factory default network setting for the EN camera is as follows:: IP address : 10.0.0.65... -
Page 14: Installing The Required Software
EN Camera Series 2. Next, open the EN setup software. If you are starting this software for the first time, you will be asked to type your password. Your case-sensitive user name and password are as follows: User name: Administrator Password: Password 3. -
Page 15: Tutorial
EN Camera Series 3 Tutorial This section demonstrates typical operations of the EN camera that most applications will require. This tutorial is intended for first-time users of the EN camera. Go through this section step-by-step to familiarize yourself with the EN camera’s operations. 3.1 Image Capturing 3.1.1 Start Up the EN Setup Software... -
Page 16: Live Image Capturing/Focusing
EN Camera Series Figure 4. Camera Properties 3.1.3 Live Image Capturing/Focusing Click the “Video” button. Highlight the icon of the camera you want to see. Click the “Full Size” and “Live” video buttons. You will now see a live video image. The live image is generated by an internal trigger mechanism inside the EN camera. -
Page 17: Figure 5. Live Image Capturing
EN Camera Series Figure 5. Live Image Capturing Figure 6. Focus Bar Use the “Focus Bar” button to make precise adjustments to the lens focus. Tutorial... -
Page 18: Figure 7. Measuring Box Position
EN Camera Series Figure 7. Measuring Box Position Use the “Measuring Box” button to make sure the license plate or particular target is in the correct side of the video field of view. Figure 8. Half Size Image Position The “Half Size” image button is useful for situations in which two EN cameras together cover a single lane. -
Page 19: Figure 9. Quad Size Image Button
EN Camera Series Figure 9. Quad Size Image Button Click the “Quad Size” image button to capture four images. Each image will then be reduced from the full 1920 x 512 resolution to 960 x 256 resolution for the TS-2030EN; from 1920 x 768 resolution to 960 x 384 for the TS-2076EN;... -
Page 20: Image Properties
EN Camera Series 3.1.4 Image Properties You can monitor the image properties of captured images, whether it’s “Live,” “Snap,” or “Trigger - Sniffing” mode. On the Video Window menu, select “Image Properties” under “View.” You can also use the EN setup software to monitor the image properties of saved images and FTP images. Tutorial... -
Page 21: Image Transfer
EN Camera Series 3.2 Image Transfer 3.2.1 FTP Image Transfer To transfer images via FTP, first make sure to set up the FTP server properly. Please check the following items: The username/password or anonymous login must be set for FTP server. Set the permission of the read/write/create directory. - Page 22 EN Camera Series In the camera’s “Properties” window, set up the light sensor’s IP address and Port number. These numbers must be consistent with Moxa’s setting. You can connect up to two light sensors. If two IP addresses and port numbers are identical, then the EN camera tries to connect only a single light sensor.
-
Page 23: Flash Nighttime Light Control
EN Camera Series 3.3.2 Flash Nighttime Light Control The strobe and continuous nighttime light can be manually turned on and off. Set “Flash Auto/Manual” and “Night light Control” registers to Manual OFF or ON. Generate an Ethernet trigger or input TTL trigger to see Flash. The “Live” or “Snap” button does not generate Flash, because they are independent from normal trigger operation. -
Page 24: Time Synchronization
EN Camera Series 3.4 Time Synchronization The EN camera supports NTP (network time protocol) synchronization. If you disable NTP by clearing the “NTP Client Control” register, then the internal clock will drift approximately 1.5 seconds per day. To reset the clock, set the “Real Time Clock” register to your current local time. If you decide to take advantage of the NTP feature, make sure to set up the NTP server, preferably with GPS input. -
Page 25: Dhcp Client
If you know the current IP address of the camera, you can telnet directly to the EN camera. Login as User name = root, Password = JAI PULNiX. If you want to assign a new IP address temporarily, you can use the “ifconfig” utility. If you want to assign a new IP address permanently, you can use the “test_libcamera”... -
Page 26: Maintenance
EN Camera Series 3.6 Maintenance 3.6.1 Debug Counters For debugging purposes, some status registers are available as debug counters. Detailed information for each debugging counter is included in the LC-EN Interface document. This tutorial covers the following debug counters. • Trigger Filter Noise count = number of hardware TTL triggers that failed trigger noise filter. -
Page 27: Firmware Upgrade
EN Camera Series If you set the POST trigger filter to 10ms but the TTL trigger has only 9ms stable POST condition, then the “POST Filter Noise count” must be incremented. Unlike PRE trigger, “VINIT count” is also incremented, because trigger pulse is sent to CCD anyway before finishing validation of POST condition. -
Page 28: Rs-232 Powerpc Debug Port
EN Camera Series 3.6.3 RS-232 PowerPC Debug Port If you have the debug RS-232 serial/power cable, you can debug EN cameras over the serial port. This is useful when Ethernet is not available. In this tutorial, we suppose we have accidentally assigned an invalid IP address to the EN camera, and now we cannot communicate with the EN camera over Ethernet. - Page 29 EN Camera Series After typing the “/” key, you should see the following monitor menu. Enter “3” to select “Change IP addresses” mode. Enter “1” to select Ethernet interface 1. Enter “1” again to select “Change local address. Enter the new IP address. ”...
- Page 30 EN Camera Series Enter the command “ifconfig” to see if the network is up and running. Eth0 is the network interface of the EN camera. In the above example, the EN’s network is set to the following: IP address = 10.0.0.65. Subnet mask = 255.255.255.0. If eth0 is not running or if you want to change to a different IP address, you can set the temporary network setting just to enable a FTP, TELNET, or Ethernet connection Enter the command “ifconfig eth0 <NEW IP ADDRESS>...
-
Page 31: Uploading The Firmware
JAIPULNiX Type “en-v” to see the version numbers for all firmware currently running. #en-v > version.txt #more version.txt Welcome to JAI-PULNiX EN Camera EN version : 050812A0 OS version : 050810A0 Lib/drv version : 050812A0 FPGA version : 050805C0 4.1.2... -
Page 32: Updating The Fpga Bitfile
EN Camera Series 4. Select “Update EN Application.” 5. Reboot the EN camera for the updates to take effect. Note: You cannot update the identical EN application version. 4.3 Updating the FPGA Bitfile You can update the FPGA bitfile by using the EN setup software. To do so, follow the steps below. 1. - Page 33 EN Camera Series 2. Type “ps” to see the process running. Kill the “dhcpcd” process, if it is running in the background. 3. Assign a static IP address to the network interface. Example: To assign a static IP=10.0.0.65 and subnetmask =255.255.255.0, enter this command: ifconfig eth0 10.0.0.65 netmask 255.255.255.0 4.
- Page 34 EN Camera Series Uploading Firmware...
-
Page 35: Connectors And Cables
Figure 11. 12-Pin Connector The JAI EN camera has a 12-pin Hirose connector for power input, serial communication, and signal integration. Pin #1 is Ground and pin #2 is +12V DC. Other pins handle a number of input and output functions, as shown in Table 2. -
Page 36: 10/100 Baset Ethernet
5.2 RS-232 Communication Cable Figure 13. Serial Communications Cable RS-232B-12 ( JAI Inc. part number: 310 132 19 The RS-232B-12 interface cable is used to debug the PowerPC processor. This debug port is useful when the network is down and RS-232 is the only choice to connect with the EN camera. See Section 3.6.3 on page 24 and Section 4.7 on page 31 for detailed information on how to use the debug... -
Page 37: Power Supplies And Power Cable Setup
JAI Inc. Power Cables If you are using JAI Inc. power cables such as the 12P-02S, please refer to the 12-pin connector pin- out diagram. The cable pin-out diagram is shown in Figure 14 below. The color-coded leads use Gray for Ground and Yellow for +12V. -
Page 38: Building Your Own Power Cable
EN Camera Series Note: Make sure that the unused leads are not touching and that there is no possibility that exposed wires could cause the leads to short. 5.3.3 Building Your Own Power Cable Refer to the 12-pin connector pin-out in Figure 14 on page 35. Connect the Ground lead to pin #1, and the +12V DC lead to pin #2 of the 12-pin connector. -
Page 39: Camera Features
500 lines. The JAI EN camera uses a state-of-the-art progressive scanning interline transfer CCD which scans all lines sequentially from top to bottom at one frame rate. Like a non-interlace computer screen, it generates a stable, and crisp image without alternating lines. -
Page 40: Figure 15. Timing Chart 1 (Ts-2030En)
EN Camera Series Figure 15. Timing Chart 1 (TS-2030EN) Camera Features... -
Page 41: Figure 16. Timing Chart 2 (Ts-1327En)
EN Camera Series Figure 16. Timing Chart 2 (TS-1327EN) Camera Features... -
Page 42: Adr (Automatic Dynamic Range) Control
EN Camera Series 6.3 ADR (Automatic Dynamic Range) Control ADR (Automatic Dynamic Range) control is a key algorithm of EN cameras. The ADR algorithm controls the EN camera parameters on a continuous basis to maintain the contrast-to-noise of the license plates on passing vehicles to a suitable level required for automatic license plate reading algorithms. -
Page 43: Electronic Shutter
“ADR White to Blue Ratio” is the ratio between a white plate and blue plate, and is used to optimize the camera parameters. This value is optimized by JAI, and should be kept at factory default. Please do not change it. -
Page 44: Video Amplifier Gain Control
EN Camera Series Table 5 EN Exposure Times TS-2030EN/TS-2076EN TS-1327EN (55.0 μ s x H + 28.7 μ s) (633 μ s x H + 5.1 μ s) Shutter Dial Exposure Time Exposure Time ( μ s) Exposure Time Exposure Time ( μ s) 83.7 36.8 138.7... -
Page 45: Table 7 Gain Table (Bw En Camera)
EN Camera Series information). Normally, gain would be manually adjusted only when a different gain (and electronic shutter setting) is needed to see the vehicle and focusing targets used for setup in whatever road lighting is available at the installation site. The following table shows the gain setting against the actual gain (dB): Gain Table (BW EN Camera) Table 7 Gain Table (BW EN Camera) -
Page 46: Flash/Nighttime Light Control
8-bit monochrome image. The necessary DLL is available from JAI Inc.. The JAI Inc. EN Camera cameras use the Bayer color mosaic filter pattern (see Figure 16 below). The CFA contains 50% green photo sites and 25% red and 25% blue photo sites. -
Page 47: Image Formats
EN Camera Series Figure 17. CFA Pattern Because the color filter array contains only a single R, G or B color in each pixel, the restored image has to fill in colors in the missing pixel locations. The software uses neighboring pixel information to "guess"... -
Page 48: Jpeg Format
EN Camera Series Please refer to the "LC to EN Interface" document for the detailed TIF header. 6.7.2 JPEG Format JPEG is the industry-standard format for lossy image compression. Output file size, quality and speed of the encoding depends on the quality setting. The user can set the proper quality setting by accessing the "JPEG Quality Factor"... -
Page 49: Image Buffering
An API (application program interface) for Windows is available. Using an API, the time required to develop software for device discovery, command communication, and image transfer can be shortened. Please contact JAI Inc. for further information. 6.9 Image Buffering Full size TIF images, JPEG images, and ODD/EVEN field images are independently managed in image buffers. -
Page 50: Ntp (Network Time Protocol)
EN Camera Series 6.11 NTP (Network Time Protocol) The EN Camera supports the NTP (Network Time Protocol) client. NTP is the industry-standard time synchronization mechanism over the network. For LAN, the synchronization accuracy within a few milliseconds is achievable. Normally, the EN cameras can maintain the accuracy within 10ms as a worst-case scenario in LAN. -
Page 51: Frequently Asked Questions And Troubleshooting
EN Camera Series 7 Frequently Asked Questions and Troubleshooting 7.1 Problem 1: What Password Allows Login from a RS232 Debug Port or Telnet Session to the EN Camera? User name = root, password = JAIPULNiX 7.2 Problem 2: What is a Password to Start the EN Setup Software? The factory default setting is, user name = Administrator;... -
Page 52: Problem 7: Jpeg Image Is Either Corrupt Or Not A Full-Size Image
7.9 Problem 9: FTP servers switch between primary server and second server, even if the hard disk is not full. 1. JAI has tested various FTP servers to compare performance differences. For Linux, we recommend PureFTP server. We do not recommend vsFTP server. For Windows, we recommend Cerberus FTP server. -
Page 53: Problem 12: Io Board Communication Error
EN Camera Series 1. Access to HTTP server of MOXA (RS-485 to Ethernet converter). Check the version of firmware. Firmware must be 2.2 or later. If not, update the firmware. 2. Go to “Operating Settings” -> “Port 1” Change the following parameters. 3. -
Page 54: Problem 14: The Day Time Image Is Too Bright And Whites Out Or Saturates The License Plate
Phone: (408) 383-0300 (Request ITS technical support when the telephone call is answered.) Toll-free: (800) 445-5444 Fax: (408) 383-0301 E-mail Americas: solutionssupport.americas@jai.com E-mail Europe, Middle East, or Africa: solutionssupport.emea@jai.com Mail: JAI Inc. ATTN: Traffic Solutions 625 River Oaks Parkway San Jose, CA 95134 Web Site: www.jai.com FAQ and Troubleshooting... -
Page 55: Appendix
Digital: 1920 (H) x 512 (V) 1920 (H) x 768 (V) S/N Ratio 50dB min (BW) 48dB min. (Color) Video Output Digital output: JAI Inc. proprietary protocol over TCP/IP Gamma Gamma 0.55 forBW Linear for Color Lens Mount C-mount Power Req. - Page 56 EN Camera Series Model TS-1327EN/TSC-1327EN Sensor 2/3” progressive scan interline transfer CCD Active Area 8.94mm x 6.71mm Active pixels 1392 (H) x 1040 (V) @ 15 fps Cell size 6.45 µm x 6.45 µm Pixel clock 27.5 MHz Resolution Digital: 1392 (H) x 1040 (V) S/N ratio Mono / Color 52 dB min.
-
Page 57: Physical Dimensions
EN Camera Series 8.2 Physical Dimensions Figure 19. Physical Dimensions 8.3 Spectral Response Figure 20. Spectral Response (B/W CCD) TS-2030EN/TS-2076EN Specifications... -
Page 58: Figure 21. Spectral Response (B/W Ccd) Ts-1327En
EN Camera Series Figure 21. Spectral Response (B/W CCD) TS-1327EN Figure 22. Spectral Response (Color CCD) TSC-2030EN/TSC-2076EN Specifications... -
Page 59: Figure 23. Spectral Response (Color Ccd) Tsc-1327En
EN Camera Series Figure 23. Spectral Response (Color CCD) TSC-1327EN Table 11 IR Cut Filter Optical Characteristics Wavelength Transmission from 450 to 650 nm Average 80% above 730 ±20 am Average 50% from 800 to 1,150 nm Average 10% below Figure 24. -
Page 60: Figure 25. Red Filter Optical Characteristics
EN Camera Series Figure 25. Red Filter Optical Characteristics Specifications... -
Page 61: Configurable Order Options For En Cameras
9 Configurable Order Options for EN Cameras 9.1 OP-IR Monochrome only, No IR cut filter. 9.2 OP-RED Monochrome only, Red filter. Options... - Page 64 Europe, Middle East & Africa Phone +45 4457 8888 Fax +45 4491 8880 Asia Pacific Phone +81 45 440 0154 Fax +81 45 440 0166 Americas Phone (Toll-Free) 1 800 445-5444 Phone +1 408 383-0301 www.jai.com...
