User's Manual
SW-2001T-CL
3CCD High Speed Color
Line Scan Camera
Document Version: Ver.1.1
SW-2001T-CL_Ver.1.1_Dec2020

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SW-2001T-CL and is the answer not in the manual?

Questions and answers

Related Manuals for JAI SW-2001T-CL

Summary of Contents for JAI SW-2001T-CL

  • Page 1 User's Manual SW-2001T-CL 3CCD High Speed Color Line Scan Camera Document Version: Ver.1.1 SW-2001T-CL_Ver.1.1_Dec2020...
  • Page 2 JAI Ltd., Japan and may only be used by the purchasers of the product. JAI Ltd., Japan makes no warranty for the use of its product and assumes no responsibility for any errors which may appear or for damages resulting from the use of the information contained herein.
  • Page 3 SW-2001T-CL Supplement The following statement is related to the regulation on “ Measures for the Administration of the control of Pollution by Electronic Information Products “ , known as “ China RoHS “. The table shows contained Hazardous Substances in this camera.

  • Page 4: Table Of Contents

    Rear panel indicator ................19 Configuring the camera ................... 20 7.1. SW-2001T-CL Command list ................ 20 Functions listed alphabetically by command acronyms ..........24 Command AHRS – Request status after One-Push AWB ........24 Command AL – Automatic Line Rate Reference Level ......... 24 Command AR –...
  • Page 5 8.35 Factory default settings ................33 8.36 Serial communication ................34 Camera Control Tool for SW-2001T-CL ..............36 9.1 Control Tool Windows ................. 36 9.2 Camera Control Tool Interface ............... 37 9.3 Using Camera Control Tool ................39 10 External appearance and Dimensions ..............40 11 Specifications ....................

  • Page 6: General

    1. General SW-2001T-CL is a 3CCD line scan camera using three 2048 pixel line sensors mounted on a prism, for the R, G and B channels. It operates with a 40 MHz pixel clock, resulting in a maximum line rate of 19 047 lines per second.

  • Page 7: Locations And Functions

    SW-2001T-CL 4. Locations and functions 12pin connector Fig. 1 Location of external features 1 Camera Link base connector (1) (*Note) 2 Camera Link medium connector (2) (*Note) 3 12-pin connector for DC +12, External trigger and RS-232C 4 LED indicator...

  • Page 8: Connectors

    Cables, transmission systems and frame grabbers/acquisition boards that do not comply with the Camera Link standard may work with this camera, but JAI Camera Solutions cannot be held responsible for loss in performance or damage of equipment, including the camera.

  • Page 9: Input And Output Circuits

    11(-),24(+) 12(-),25(+) 13,26 Shield The SW-2001T-CL follows the Camera Link standard in all respects. Please refer to the Camera Link version 1.1 specifications for detailed information on bit assignments of 24-bit RGB and 30-bit bit output. 5.3. Input and output circuits 5.3.1.

  • Page 10: Een / Xeen Output (Exposure Enable)

    SW-2001T-CL 5.3.2. EEN / XEEN output (Exposure Enable) This output corresponds to the exposure (accumulation) time of the camera. It works together with all operation modes. It is, however, not active when the test pattern function is enabled. The EEN signal is available at the Camera Link connector and at the 12-pin connector at the same time.

  • Page 11: Functions And Operation

    (the inverse of line rate). This also allows a fixed exposure time, independent of the line rate. In the SW-2001T-CL the exposure time can be set individually for all three channels.

  • Page 12: Pixel Gain (Flat-Field) Correction (Prnu Correction)

    SW-2001T-CL 6.2. Pixel Gain (flat-field) correction (PRNU correction) Pixel Response Non-Uniformity is, as the name expresses, a non-uniformity of the response of each individual pixel. This means that for a fixed light level each pixel will have a slightly different output level (response).

  • Page 13: Shading Correction

    SW-2001T-CL under the operating conditions (exposure time and line rate) that will be used by the application. After correction: Flat dark signal response from pixel to pixel Average 6.4. Shading correction Shading is caused either by illumination with uneven distribution of light across the surface, or by vignetting towards the edges of a lens.

  • Page 14: Operation Modes

    6.6. Operation modes The SW-2001T-CL provides three basic modes of operation: No-shutter, Shutter-Select and Pulse Width Control (PWC). The Shutter-Select and PWC modes also allow the user to set the exposure time independently from the scan rate, by making use of the electronic shutter (the Exposure Control Gate of the CCD sensor).

  • Page 15: Shutter Mode With Internal Line Rate Generator

    SW-2001T-CL 6.6.1. No-Shutter mode with Internal line rate generator In this mode the camera does not accept an external trigger signal, as the line rate is generated from an internal clock (user programmable, command LR). The exposure time is directly proportional to the line rate (T = 1/line rate).

  • Page 16: Shutter Mode With External Trigger

    SW-2001T-CL 6.6.2. No-Shutter mode with External Trigger In this mode, the exposure time is directly proportional to the line rate. The line rate is generated externally by a trigger signal. This mode is used when an external trigger signal is available, e.g.

  • Page 17: Shutter-Select Mode With External Trigger

    SW-2001T-CL EI=1(tracking with G) Programmable exposure PER/PEG/PEB=80 to 2150400 (in 25ns steps) Important note: • If using individual exposure, the EEN signal represents the channel with the longest exposure time Fig. 11 Shutter-Select mode with Internal line rate generator (and individual exposure) 6.6.4.

  • Page 18: Pulse Width Control (Pwc) Mode

    SW-2001T-CL Important note: • If using individual exposure, the EEN signal represents the channel with the longest exposure time Fig. 12 Shutter-Select mode with External trigger (and individual exposure) 6.6.5. Pulse Width Control (PWC) mode In this mode, the user has full control of both the line rate and the exposure time of each line via the External Trigger input.

  • Page 19: Auto Reset Mode

    6.6.6. Auto Reset mode In this mode, when the interval of the trigger pulse is more than 55ms, the SW-2001T-CL automatically returns to continuous operation with the line rate of 52.5μs . At this time, DVAL and Video OUTPUT are disable in order to prohibit charge due to dark current to add up in the sensor in standby periods.

  • Page 20: Scan Rate And Exposure Time Range

    SW-2001T-CL Auto Reset Mode > 55ms < 53.7ms <53.7ms Trigger LVAL Exposure DVAL ＜55ms：　 ＞55ms：　Auto reset operation Normal Trigger Normal Trigger operation DVAL & Video Out disable operation 6.7. Scan rate and exposure time range 6.7.1. Minimum cycle time of external trigger...

  • Page 21: Rear Panel Indicator

    SW-2001T-CL Shutter-Select Internal External External 6.10. Rear panel indicator There is a multi-color LED on the rear panel of the camera. It has the following functions: Green (Steady) Operating, but not receiving external trigger input Green (Flashing) Operating and receiving external trigger input.

  • Page 22: Configuring The Camera

    Link connector or via RS-232C on the 12-pin connector. Chapter 7.1 shows the complete list of ASCII commands. Chapter 7.2 describes the commands in detail, in alphabetical order (sorted by command the acronym) 7.1. SW-2001T-CL Command list Command Format Parameter...
  • Page 23 SW-2001T-CL PER=[Param.]<CR><LF Programmable 80 to 2150400, in 25ns > Only valid for TR=1 Exposure - Red increments PER?<CR><LF> Programmable PEG=[Param.]<CR><LF 80 to 2150400, in 25ns Exposure > Only valid for TR=1 increments Green PEG?<CR><LF> Programmable PEB=[Param.]<CR><LF 80 to 2150400, in 25ns Exposure >...
  • Page 24 SW-2001T-CL Black Level - BL=[Param.]<CR><LF> 0 to 127 Master BL?<CR><LF> Black Level - BLR=[Param.]<CR><LF> -64 to 63 BLR?<CR><LF> Black Level - BLB=[Param.]<CR><LF> -64 to 63 Blue BLB?<CR><LF> 0=Manual/One push AWB WB=[Param.]<CR><LF> 1=3900K White Balance WB?<CR><LF> 2=4600K 3=5600K Activate AW=[Param.]<CR><LF> 0=Activate one-push AWB One-push AWB <Camera replies >...
  • Page 25 SW-2001T-CL correction, store to user area 0=Shading correction not Inquire the yet completed. status after SDS?<CR><LF> 1=Succeeded. shading 2=Error1 - Timeout error correction occurred. Select pixel 0=Off (Bypass) gain PGC=[Param.]<CR><LF> 1=Factory area Only valid for SHC=0. correction PGC?<CR><LF> 2=User area...

  • Page 26: Functions Listed Alphabetically By Command Acronyms

    SW-2001T-CL Functions listed alphabetically by command acronyms Command AHRS – Request status after One-Push AWB This command returns the status of the One-Push AWB function, with the following parameters: 0=AWB not completed yet 1=Succeeded 2=Error1: Green image too bright 3=Error2: Green image too dark 4=Error3: Timeout occurred Command AL –...

  • Page 27: Command Ah - Activate One-Push Auto White Balance (Awb) - Shutter

    SW-2001T-CL white balance may not be obtained. • The data can be stored in camera memory for use at next start up. • This function can work on External trigger mode. • Please refer Chapter 7.5 operation mode for the details.

  • Page 28: Commands Blr And Blr - Black Level Red And Black Level Blue

    SW-2001T-CL Settings: 0 to 127 Associated functions: Command BLR - black level for the red channel. Command BLB – black level for the blue channel. 8.10 Commands BLR and BLR – Black level red and black level blue In conjunction with Command BL, these commands allow individual setting of the black level in all channels.

  • Page 29: Commands Ksr, Ksg And Ksb - Knee Slope For R, G And B

    SW-2001T-CL Fig. 14 Principle of Knee function Settings: 0=off, 1=on Associated functions: Commands KSR, KSG and KSB – Knee slope for R, G and B Commands KPR, KPG and KPG – Knee point for R, G and B 8.15 Commands KSR, KSG and KSB – Knee slope for R, G and B...

  • Page 30: Command Nosr - Enable Noise Reduction

    SW-2001T-CL Important note • The data can be stored in the camera memory for next start up. 8.18 Command NOSR – Enable noise reduction This command enables (or disables) the “Noise Reduction” function. Settings: 0 = Off 1 = On 8.19...

  • Page 31: Command Pgc - Enable Flat-Field Correction (Pixel Gain)

    SW-2001T-CL Settings: 80 to 2,150,400 in 25ns steps Associated functions: EI (R and G exposure interlocked with G) 8.24 Command PGC – Enable Flat-field correction (Pixel gain) This command enables (or disables) the “pixel gain” (flat-field) correction function, which compensates for Pixel Response Non Uniformity (PRNU) for individual pixels.
  • Page 32 SW-2001T-CL Individual shading correction per channel Important note: • Depending on the optics and/or illumination used together with the camera, it may not be possible to fully compensate for shading. Operating procedure for individual R, G and B channel shadings correction: 1.

  • Page 33: Command Sds - Request Status After Executing Shading Correction Command

    SW-2001T-CL 8.28 Command SDS – Request status after executing shading correction command This command returns the status of the shading correction function, with the following parameters: 0=Shading correction not completed yet 1=Successful 3=Error1 – Timeout occurred 8.29 Command TG – Trigger Origin Selects whether an external signal or an internal clock generator is used as a trigger source.

  • Page 34: Command Ts - Test Pattern

    SW-2001T-CL 8.33 Command TS – Test pattern This allows the camera to output a number of test patterns for set-up and troubleshooting. Settings: 0=off 1=Color bar 2=Gray wedge 3=Gray bars 4=White (890LSB) Signal 32 (8) 10bit (8-bit) Pixel count 2048 Fig.

  • Page 35: Command Wb - White Balance

    SW-2001T-CL 890 (222) 10bit (8-bit) Signal (RGB) 32 (8) 10bit (8-bit) Pixel count 2048 Fig. 19 White level test pattern 8.34 Command WB – White Balance The white balance function can be used for manual setting, One-Push automatic white balance (AWB) and fixed color temperatures (3 selections)

  • Page 36: Serial Communication

    8.36 Serial communication The SW-2001T-CL can communicate by serial communication via the Camera Link connector or via RS232C in the 12-pin connector. The Baud Rate is fixed at 9600 bps. Switch SW1 at the rear panel of the camera is used to select which way the serial communication is set up.
  • Page 37 SW-2001T-CL Transmit the following to have a command list: HP?<CR><LF> The camera answers: A list with all commands and possible settings Invalid parameters send to camera: (99 is an invalid parameter) SH=99<CR><LF> The camera answers: 02 Bad Parameters!!<CR><LF> To see firmware number.

  • Page 38: Camera Control Tool For Sw-2001T-Cl

    SW-2001T-CL 9 Camera Control Tool for SW-2001T-CL From www.jai.com Camera Control Tool for Windows NT/2000/XP can be downloaded. The control tool contains a camera control program and tools for making your own program. For the integrator and experienced user, the Camera Control Toll is much more than a program with a window interface.

  • Page 39: Camera Control Tool Interface

    The about window contains a picture of the camera and information about the version of the program, Internet connection to JAI A/S and access to the help documents. The List box that contains the help documents will list all files, which have the extension .pdf and that are found in...
  • Page 40 SW-2001T-CL area contains 2 list boxes now. RS-232 communication: 1. Select ’COM-ports’ from the ’CL Manufacturer/COM-ports’ list Box. 2. Select the communication port, where the serial cable is connected to the camera from the ’Serial Port’ list box or click the ‘Auto’ button to search for a camera on communication port 1 to 16.

  • Page 41: Using Camera Control Tool

    3. It is possible to work with the Camera Control Tool when the camera is online and when the camera is offline. 4. The newer JAI cameras always start up with the last used user area (but for some old models it will start up with the last saved user area.) 5.

  • Page 42: External Appearance And Dimensions

    SW-2001T-CL 10 External appearance and Dimensions Fig.20 External Appearance and Dimensions...

  • Page 43: Specifications

    SW-2001T-CL 11 Specifications 11.1 Typical data Scanning system Line Scan Pixel clock 40.00 MHz No-shutter Line rate: 52.5 μs (No-Shutter mode with Internal trigger) Line Frequency: 19,048 kHz Line Rate (total number of pixels per line: 2100 ( Standard ) Shutter-Select Line rate: 53.75 μs (No-Shutter mode with Internal trigger)
  • Page 44 SW-2001T-CL Synchronization By external trigger pulse, or internal clock Operation mode No-Shutter, Shutter-Select, Pulse Width Control (PWC) 12Pin : 4.0±2.0Vp-p TTL or Camera link : LVDS (CC1) Trigger input Possible to change Negative Logic or Positive Logic Minimum trigger width : more than 1.2μs(SHUTTER-SELECT) , 1.2μs(PWC)

  • Page 45: Spectral Sensitivity

    SW-2001T-CL Refer to chapter 5. Connectors. 11.2 Spectral sensitivity...

  • Page 46: Appendix

    Remove power from the camera when changing switch settings. 12.2 Typical Sensor Characteristics The image sensors used in the SW-2001T-CL have been chosen for their superior performance. There may, however, always be artifacts visible in the scanned image originating from pixel imperfections in the camera.

  • Page 47: User's Record

    Company and product names mentioned in this manual are trademarks or registered trademarks of their respective owners. JAI A-S cannot be held responsible for any technical or typographical errors and reserves the right to make changes to products and documentation without prior notification.
