The Blockhead™ Ii Pin-Up Picture - Blizzard Lighting Blockhead II User Manual

Figure 1: The BlockHead™ II Pin-Up Picture
Head/Arms
Carry Handle
Figure 2: The Rear Connections
Artnet Input
Artnet Output
BlockHead™ II User Manual Rev. A
DMX Input Power Input
DMX Output
Page 7
25x CREE® 12w
RGBW LEDs
4-Button Control
Panel Menu with
LCD Display
Power Switch
Power Out Fuse
(c) 2015 Blizzard Lighting, LLC
