2. MEET THE BLOCKHEAD II MOVING HEAD™

MAIN FEATURES:

• 5x5 pixel matrix moving head w/25x CREE® 12W RGBW LEDs
• Infinite pan and tilt
• 3-phase pan/tilt motors with 16-bit resolution
• Full RGBW color in standalone & DMX mode
• Display built-in numbers, letters, and graphic effects
• 7 degree beam angle
• Built-in sound active programs
• Built-in automated programs via master/slave
• Built-in sound activated programs via master/slave
• 3-pin male input and 3-pin female output
• PowerCon™ compatible AC power In/Out connectors

CONTROL:

• USITT DMX-512 (19/29/117-channels)
• 3-pin Input/Output
• 4-button menu with LCD display
DMX Quick Reference (19-Channel Mode)
Channel What is does
1 Pan (0-540 degree)
2 Infinite Pan
3 Tilt (0-270 degree)
4 Infinite Tilt
5 Pan/Tilt Speed (fast <--> slow)
6 Dimmer (0% <--> 100%)
7 Strobe (slow <--> fast)
8 Red Intensity (0% <--> 100%)
9 Green Intensity (0% <--> 100%)
10 Blue Intensity (0% <--> 100%)
11 White Intensity (0% <--> 100%)
12 Numbers (0-9), Symbols, and Patterns
13 Letters (A-Z)
14 Static Pattern Effects
15 Number & Letter Colors
16 Dynamic Pattern Effects
17 Effect Speed
18 Built-in Programs / Auto Mode / Sound Active
19 Motor Reset (251-255)
BlockHead™ II User Manual Rev. A
Page 5
(c) 2015 Blizzard Lighting, LLC
