Perfect Aire 1PAMSHQCW12-15 User Manual

12,000 btu / 15 seer quick connect ductless mini-split with 11,500 btu heat pump
Hide thumbs Also See for 1PAMSHQCW12-15:
Table of Contents

Advertisement

Quick Links

See also: Installation Manual
12,000 BTU / 15 SEER QUICK CONNECT
DUCTLESS MINI-SPLIT
With 11,500 BTU Heat Pump
USER MANUAL
FOR MODELS:
1PAMSHQCW12-15
Indoor Wall Unit
1PAMSHQCW12-15
Outdoor Condenser
Before using your air conditioner,
please read this manual carefully
and keep it for future reference,
along with your receipt.
Your Source for Home Comfort

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 1PAMSHQCW12-15 and is the answer not in the manual?

Questions and answers

Related Manuals for Perfect Aire 1PAMSHQCW12-15

Summary of Contents for Perfect Aire 1PAMSHQCW12-15

  • Page 1 Your Source for Home Comfort 12,000 BTU / 15 SEER QUICK CONNECT DUCTLESS MINI-SPLIT With 11,500 BTU Heat Pump USER MANUAL FOR MODELS: 1PAMSHQCW12-15 Indoor Wall Unit 1PAMSHQCW12-15 Outdoor Condenser Before using your air conditioner, please read this manual carefully and keep it for future reference, along with your receipt.

  • Page 2: Table Of Contents

    Contents This manual provides the information needed for proper use and maintenance of this air conditioner. Basic preventative care can help extend the life of this unit. The “Troubleshooting Tips” section in this manual contains a chart with solutions to the most common problems. Referring to this section may save time and prevent the need for a service call in the event of a problem.

  • Page 3: Safety Precautions

    Safety Precautions To prevent injury to the user or other people and property damage, the following instructions must be followed. Incorrect operation due to ignoring instructions may cause harm or damage. Failure to adhere to each of the following precautions can lead to results classified as follows: WARNING This symbol indicates the possibility of death or serious injury.

  • Page 4: Caution

    Safety Precautions (continued) CAUTION • Never flip any switches with a wet hand. It • The air conditioned space should be may cause an electric shock. ventilated periodically. • Never use the device for any purpose • Always turn off power at the electrical other than the intended use.

  • Page 5: Identification Of Parts

    Identification Of Parts Part Names Indoor Unit  Front panel  Air inlet  Air filter  Air outlet  Horizontal air flow grille  Vertical air flow louver (inside)  Display panel Outdoor Unit Air inlet (rear) Air inlet (side)  Connecting pipe  Connecting cable  Stop valve...

  • Page 6: Operating Instructions

    Operating Instructions Special Functions Refrigerant Leakage Detection The indoor unit will sound an alarm and display the code "EC" on the LED display panel when the outdoor unit detects a condition indicating refrigerant leakage. Louver Angle Memory The unit will memorize the open angle of the horizontal louver (within the louver's range of safe use).If the louver is placed outside an angle of safe operation, you can return it to a standard angle by: (1) pressing the manual control button and (2)turn off power at the electrical supply disconnect or main electrical breaker panel.

  • Page 7: Airflow Direction Control

    Operating Instructions (continued) Airflow Direction Control Adjust the air flow direction properly to avoid discomfort or uneven room temperatures. Adjust louvers while the unit is in operation To set the horizontal air flow (left–right): • Manually adjust the vertical louvers using the deflector rod. To set the vertical air flow (up–down): Range •...

  • Page 8: Air Conditioner Operating Modes

    Operating Instructions (continued) Air Conditioner Operating Modes AUTO Mode • When you set the air conditioner in AUTO mode, it will automatically select cool, heat, or fan only operation depending on set temperature and the room temperature. • The air conditioner will control room temperature automatically to the temperature point you set. SLEEP Mode •...

  • Page 9: Care And Maintenance

    Care and Maintenance Before Performing Maintenance Turn the system off before cleaning. Power supply must be disconnected before cleaning the indoor unit. Cleaning the Indoor Air Handler • Power supply must be disconnected to prevent shock or fire hazard. The cabinet of the indoor unit may be dusted with an oil-free cloth or with a cloth dampened in a solution of warm water and mild liquid dishwashing detergent.

  • Page 10: Troubleshooting Tips

    Troubleshooting Tips Normal functions of the air conditioner The following occurrences may take place during normal operation: 1. Protection of the Air Conditioner • Compressor protection - The compressor will not restart for 3-4 minutes after it stops. • Anti-cold air - When the indoor heat exchanger is in one of the following three situations and the set temperature has not been reached, the unit is designed not to blow cold air on HEAT mode: (1) Heating has just started, (2) unit is defrosting, or (3) low temperature heating is occurring.

  • Page 11: Troubleshooting Guide

    Compressor protection has been activated. (3-4 minutes). If the issue has not been corrected utilizing the above troubleshooting tips, please contact Perfect Aire Consumer Services at 877-365-6274 or a trained service provider. Do not attempt to repair the unit yourself.
  • Page 12 Your Source for Home Comfort Distributed by: Perfect Aire, LLC 5151 Belt Line Rd. Suite 878 Dallas, TX 75254 877-365-6274 www.perfectaire.us Specification and performance data is subject to change without notice. Printed in China...
