Perfect Aire 1PACV25000E Owner's Manual

Perfect Aire 1PACV25000E Owner's Manual

Window air conditioner inverter
Hide thumbs

Advertisement

Quick Links

Download this manual
OWNER'S MANUAL
WINDOW AIR CONDITIONER
INVERTER
MODEL 1PACV25000E

Advertisement

loading
Need help?

Need help?

Do you have a question about the 1PACV25000E and is the answer not in the manual?

Questions and answers

Related Manuals for Perfect Aire 1PACV25000E

Summary of Contents for Perfect Aire 1PACV25000E

  • Page 1 OWNER’S MANUAL WINDOW AIR CONDITIONER INVERTER MODEL 1PACV25000E...
  • Page 3 TABLE OF CONTENTS IMPORTANT SAFETY INSTRUCTION ......................4 INSTALLATION INSTRUCTIONS ........................13 WHAT IS IN THE PACKAGE ..............................13 PREPARE THE FOLLOWING TOOLS ............................14 BEFORE THE INSTALLATION ..............................14 WINDOW REQUIREMENTS ..............................14 INSTALLATION OVERVIEW ..............................15 ASSEMBLE YOUR AC CABINET .............................16 INSULATE YOUR WINDOW ..............................18 INSTALL THE AC IN THE WINDOW ............................19 SECURE THE AC ..................................22 ONE MORE THING ..................................23...
  • Page 4 IMPORTANT SAFETY INSTRUCTION READ THESE SAFETY PRECAUTIONS BEFORE INSTALLATION AND OPERATION. For your safety, it is important that you read and follow the instructions in this manual to minimize the risk of personal injury, fire or electrical shock. Inside you will find many helpful hints on how to use and maintain your air conditioner properly. Just a little preventive care on your part can save you a great deal of time and money over the life of your air conditioner.
  • Page 5 IMPORTANT SAFETY INSTRUCTION (Continued) • Do not clean unit when power is on as it may • The appliance with electric heater shall have at cause fire and electric shock, it may cause least 1 meter space to the combustible materials. an injury.
  • Page 6 IMPORTANT SAFETY INSTRUCTION (Continued) • Your air conditioner must be used in a properly NOTE (Continued) grounded wall receptacle. If the wall receptacle you intend to use is not adequately grounded or • The power supply cord with this air Always protected by a time delay fuse or circuit breaker, make sure the RESET button is pushed in for have a qualified electrician install the proper...
  • Page 7 IMPORTANT SAFETY INSTRUCTION (Continued) • When handling the air conditioner, be careful to • Appliance shall be installed, operated and avoid cuts from sharp metal fins on front and stored in a room with a floor area larger than rear coils. 43 sq.
  • Page 8 IMPORTANT SAFETY INSTRUCTION (Continued) CAUTION: Risk of fire flammable materials Explanation of symbols displayed on the unit This symbol shows that the operation manual should be read carefully. CAUTION This symbol shows that a service professional should be handling this equipment CAUTION with reference to the installation manual.
  • Page 9 IMPORTANT SAFETY INSTRUCTION (Continued) • The ventilation machinery and outlets are WARNING operating adequately and are not obstructed. For using R32 refrigerant • If an indirect refrigerating circuit is being used, the secondary circuit shall be checked 5. Presence of a fire extinguisher: If any hot for the presence of refrigerant.
  • Page 10 IMPORTANT SAFETY INSTRUCTION (Continued) REMOVAL AND EVACUATION WARNING • When breaking into the refrigerant circuit to make For using R32 refrigerant repairs—or for any other purpose - conventional CABLING procedures shall be used. However, for flammable refrigerants it is important that best practice is •...
  • Page 11 IMPORTANT SAFETY INSTRUCTION (Continued) • Before attempting the procedure ensure that: WARNING • When breaking into the refrigerant circuit For using R32 refrigerant to make repairs or for any other purpose, conventional procedures should be used. CHARGING PROCEDURES • Mechanical handling equipment is available, •...
  • Page 12 IMPORTANT SAFETY INSTRUCTION (Continued) WARNING IMPORTANT NOTICE: For using R32 refrigerant WARRANTY VOID FOR IMPROPER INSTALLATION RECOVERY Please note that the warranty for the • When removing refrigerant from a system, window air conditioner will be void if it is either for servicing or decommissioning, it is installed in a wall sleeve through a wall recommended good practice that all refrigerants...
  • Page 13 INSTALLATION INSTRUCTIONS WHAT IS IN THE PACKAGE Bottom Rail Foam Seal Window Sash Ground wire (with glue) Seal Foam Air Conditioner Unit Remote Top Rail and Foam (with glue) and batteries Foam insert R1 Insulation Safety Lock and Foam (with glue) Safety Lock Sill Angle Bracket (for Vinyl-Clad Window)
  • Page 14 INSTALLATION INSTRUCTIONS (Continued) PREPARE THE FOLLOWING TOOLS WINDOW REQUIREMENTS *Tools not included Gloves Scissors Pencil Drill Screwdriver 18.5in (469.9mm) 28in to 40.5in (711.2mm to 1028.7mm) Level Ruler or tape measure Your air conditioner is designed to install in BEFORE THE INSTALLATION standard double hung windows with opening widths of 28 to 40.5 inches (711.2 to 1028.7 mm) and a minimum height of 18.5 inches (469.9 mm).
  • Page 15 INSTALLATION INSTRUCTIONS (Continued) INSTALLATION OVERVIEW Sash Lock and 5/8in Screws Air Conditioner unit Top Rail and 3/8in Screws Side Retainer (both side) Frame Assembly (Left) Window Sash Seal Foam Safety Lock and 5/8in Screw Remote Frame Assembly (Right) IMPORTANT NOTICE: WARRANTY VOID FOR IMPROPER INSTALLATION Please note that the warranty for the window air conditioner will be void if it is installed in a wall sleeve or any other type of enclosure that interferes with any air vents.
  • Page 16 INSTALLATION INSTRUCTIONS (Continued) Disconnect the connector plug of the display panel ASSEMBLE YOUR AC CABINET from the unit and place front panel to one side. WHAT YOU NEED STEP 2 REMOVE AIR CONDITIONER STEP 1 FROM CABINET REMOVE THE FRONT PANEL Remove shipping screws from top of unit and also FROM THE UNIT on the side by the base if installed.
  • Page 17 INSTALLATION INSTRUCTIONS (Continued) STEP 3 STEP 5 INSTALL TOP ANGLE AND SIDE BRACKET INSTALL THE PANELS Attach foam gasket to top angle above holes. Place cabinet on floor, a bench, or a table. Slide "I " section of window filler panel into side retainer on the both side of the cabinet.
  • Page 18 INSTALLATION INSTRUCTIONS (Continued) STEP 7 STEP 1 THE CABINET IS DONE INSERT THE FOAM TO THE GAPS Before you rush to the next installation phase, In order to improve the operation of the equipment please first confirm the following installation is in and reduce the noise generated during operation, place.
  • Page 19 INSTALLATION INSTRUCTIONS (Continued) STEP 2 INSTALL THE AC IN THE WINDOW SCREW THE CABINET TO THE WINDOW SILL (Wooden Window or Vinyl-Clad Window) Shift cabinet left or right as needed to line up center of cabinet on center line marked on inner sill. Bring window down temporarily behind top angle to hold cabinet in place.
  • Page 20 INSTALLATION INSTRUCTIONS (Continued) For Vinyl-Clad window Hand tighten, but allow for any changes later. Place two safety locks into the holes located Install support brackets (with sill angle brackets in the bottom of the cabinet and drive two attached) to correct hole in bottom of cabinet. #5-Screw locking screws through the safety Tighten all 6 bolts securely.
  • Page 21 INSTALLATION INSTRUCTIONS (Continued) STEP 5 STEP 7 EXTEND WINDOW FILLER PANELS INSTALL R1 INSULATION Carefully raise window to expose filler panel In order to minimize air leaks and ensure optimal locking screws. Loosen screws so filler panels insulation, it is necessary to install the included slide easily.
  • Page 22 INSTALLATION INSTRUCTIONS (Continued) STEP 8 WHAT YOU NEED INSTALL WEATHER STRIPPING Slide the R1 insulation panel into the side curtain, the side with pattern should facing the indoor. Repeat on the other side. STEP 1 DRIVE LOCKING SCREWS R1 Insulation SECURE THE AC Drive #8-Screw locking screws through the frame lock and into the sill (Only wooden windows).
  • Page 23 INSTALLATION INSTRUCTIONS (Continued) THE FINAL DETAILS ONE MORE THING STEP 1 STEP 1 CUT THE WINDOW SASH SEAL FOAM TO IF AC IS BLOCKED BY STORM WINDOW FIT THE WIDTH OF YOUR WINDOW Add wood as shown in Caution illustration on page Measure and cut the foam to be the width of your 16, or remove storm window before air conditioner window from the left to right side.
  • Page 24 OPERATION INSTRUCTIONS GET TO KNOW YOUR AC NOTE: The following two types of product appearance for reference only, The machine you purchase may be a little different. Status Display Display Rear Condenser Vents Air Direction Filter disassemble buckle Front Intake Grille (The filter is behind this) Power Button Levers...
  • Page 25 OPERATION INSTRUCTIONS (Continued) FRESH AIR VENT CONTROL ADJUST YOUR AC DIRECTION The Fresh Air Vent allows the air conditioner to: CAUTION Do not stick your fingers in the air 1. Recirculate inside air - outlet, it may cause an injury. Vent Closed (Fig.A) FOUR-WAY ADJUSTMENT (UP OR DOWN, LEFT OR RIGHT)
  • Page 26 OPERATION INSTRUCTIONS (Continued) GET TO KNOW THE FEATURES WARNING • To reduce the risk of fire, electric shock, or injury to persons, read the IMPORTANT SAFETY INSTRUCTIONS before operating this appliance. • Please always wait 3 minutes when turning unit off then on again, and when changing from cool to fan and back to cool.
  • Page 27 OPERATION INSTRUCTIONS (Continued) 5. TO SELECT THE OPERATING MODE 6. ENERGY SAVER/ECO FEATURE To choose operating mode, press Mode button. Press Energy Saver/ECO button to initiate this Each time you press the button, a mode is function. This function is available on COOL, DRY, selected in a sequence that goes from AUTO, AUTO (only AUTO-COOLING and AUTO-FAN) COOL, DRY, and FAN.
  • Page 28 OPERATION INSTRUCTIONS (Continued) 9. CHECK FILTER FEATURE NOTE: When the unit is operating under high This feature is a reminder to clean the Air Filter temperature, the fan speed may be increased for more efficient operation. The LED (light) will to ensure that the machine can operate illuminate after 250 hours of operation.
  • Page 29 CARE & MAINTENANCE CHECK THE AIR FILTER ONCE A MONTH TO SEE IF CLEANING IS NECESSARY The air filter should be checked at least once a month to see if cleaning is necessary. Trapped particles in the filter can build up and cause an accumulation of frost on the cooling coils.
  • Page 30 TROUBLESHOOTING Before calling for service, review this list. It may save your time and expense. This list includes common occurrences that are not the result of defective workman-ship or materials in this appliance. Problem Solution Wall plug disconnected. Push plug firmly into wall outlet. House fuse blown or circuit breaker tripped.
  • Page 31 5 minutes. It is also recommended to try another wall outlet. For further assistance, contact customer service at 844-472-2473. The design and specifications are subject to change without prior notice for product improvement. Any updates to the manual will be uploaded to the Perfect Aire website (www.perfectaire.us), please check for the current version.
  • Page 32 SCAN CODE TO LEAVE A REVIEW THANK YOU FOR YOUR PURCHASE! We’d love to hear how you are enjoying your Perfect Aire product! Please take a minute to tell us (and others) about your experience. 5401 Dansher Road Countryside, IL 60525...
