Before using your air conditioner, please read
this manual carefully and keep it for future reference along with your receipt.
INVERTER SINGLE ZONE
SPLIT-TYPE AIR
CONDITIONER
Read This Manual
This manual provides the information needed for
proper use and maintenance of this air conditioner.
Basic preventive care can help extend the life of
this unit. The "Troubleshooting Tips" contains a
chart with solutions to the most common problems.
Referring to this section may save time and prevent
the need for a service call in the event of a problem.
Advertisement
Table of Contents
Related Manuals for Perfect Aire 1PAMSH30-SZW-16
Summary of Contents for Perfect Aire 1PAMSH30-SZW-16
- Page 1 Before using your air conditioner, please read this manual carefully and keep it for future reference along with your receipt. INVERTER SINGLE ZONE SPLIT-TYPE AIR CONDITIONER Read This Manual This manual provides the information needed for proper use and maintenance of this air conditioner. Basic preventive care can help extend the life of this unit.
-
Page 2: Table Of Contents
CONTENTS SAFETY PRECAUTIONS Warning ..........................2 Caution ...........................3 OPERATING INSTRUCTIONS Parts names ...........................4 Operating temperature......................6 Manual operation ........................6 Airflow direction control ......................7 How the air conditioner works ....................8 CARE AND MAINTENANCE Care and maintenance ......................9 OPERATION TIPS Operation tips ........................11 TROUBLESHOOTING TIPS Troubleshooting tips ......................13 CAUTION Contact an authorized service technician for repair or maintenance of this unit. -
Page 3: Safety Precautions
SAFETY PRECAUTIONS To prevent injury to the user or other people and property damage, the following instructions must be followed. Incorrect operation due to ignoring of instructions may cause harm or damage. The seriousness is classified by the following indications. This symbol indicates the possibility of death or serious injury. -
Page 4: Caution
SAFETY PRECAUTIONS CAUTION Do not clean the indoor unit Ensure proper ventalation, When the air filter is to be with water. Use only soft especially in rooms with removed, do not touch the a stove or other appliance metal parts of the unit. cloth or slightly damp cloth. -
Page 5: Operating Instructions
OPERATING INSTRUCTIONS Parts names Indoor unit Note: The indoor unit you purchased may look Indoor unit like one of the following: 1. Signal receptor Air inlet 2. Display panel 3. Panel frame 4. Chassis 5. Front panel 6. Horizontal louver 7. -
Page 6: Led Display Panel
OPERATING INSTRUCTIONS LED display panel The display panel of the air conditioner you purchased may look like one of the following: TIMER indicator This indicator illuminates when TIMER program is set “ON/OFF”. AUTO indicator This indicator illuminates when Signal the air conditioner is in “AUTO” receptor operation. -
Page 7: Operating Temperature
OPERATING INSTRUCTIONS NOTE: This manual does not include Remote Control Operations, see the <<Remote Control Instruction>> packed with the unit for details. Operating temperature Mode Cooling operation Heating operation Drying operation Temperature Room temperature 86ºF(30ºC) 50ºF(10ºC) 62ºF(17ºC) 32ºF~122ºF (0ºC~50ºC) 5ºF~86ºF 32ºF~122ºF Outdoor temperature (-15ºC~30ºC) -
Page 8: Airflow Direction Control
OPERATING INSTRUCTIONS Airflow direction control Adjust the air flow direction properly, otherwise, it may cause discomfort or cause uneven room temperatures. Adjust the horizontal louver using the remote control. Adjust the vertical louver manually. To set the vertical air flow (Up--Down) direction Range Perform this function while the unit is in operation. -
Page 9: How The Air Conditioner Works
OPERATING INSTRUCTIONS How the air conditioner works AUTO operation SLEEP operation When you set the air conditioner in “AUTO” mode, it will 7 hours timer off automatically select cooling, heating (cooling/heating models only), or fan only operation depending on what 2ºF/1ºC temperature you have selected and the room 2ºF/1ºC... -
Page 10: Care And Maintenance
CARE AND MAINTENANCE Care and maintenance Cleaning the Grill, Case and Remote Control Turn the system off before cleaning. To clean, wipe with a soft, dry cloth. Do not use bleach or abrasives. NOTE: Supply power must be disconnectd before cleaning the indoor unit. - Page 11 CARE AND MAINTENANCE 4. Remove the Air Freshening Filter from its support frame (on some models). (The optional filters include: Plasma Dust Collector/ Silver Ion filter/Bio filter/Vitamin C filter/3M air purifier filter, etc. The removing and installation methods are slightly different, see the pictures marked on the left.
-
Page 12: Operation Tips
OPERATION TIPS The following events may occur during normal operation. 1. Protection of the air conditioner. Compressor protection The compressor can't restart for 3 minutes after it stops. Anti-cold air (Cooling and heating models only) The unit is designed not to blow cold air in HEAT mode, when the indoor heat exchanger is in one of the following three situations and the set temperature has not been reached. - Page 13 OPERATION TIPS 7. Dripping water may generate on the surface of the indoor unit when cooling in a high relative humidity (relative humidity higher than 80%). Adjust the horizontal louver to the maximum air outlet position and select HIGH fan speed. 8.
-
Page 14: Troubleshooting Tips Troubleshooting Tips
TROUBLESHOOTING TIPS Troubleshooting Tips If one of the following faults occur, stop the air conditioner immediately, disconnect the power and then connect it again. If the problem still exists, disconnect the power and contact the nearest authorized customer service center. OPERATION indicator or other indicators continue flashing. - Page 16 2020331A2042...
