Moog Videolarm DDW10CR Product Instructions page 14

Z0 (LS nibble)
6
30H - 3FH
F2 (MS nibble)
7
30H - 3FH
F1
8
30H - 3FH
F0 (LS nibble)
9
30H - 3FH
Terminator and
10
Checksum
3.9 Latch Commands
The camera commands control parameters of camera operation. All the Camera commands generate a Latch Status response message.
FUNCTION
MANUAL IRIS TOGGLE
CAMERA POWER TOGGLE
LENS SPEED TOGGLE
TOGGLE AUX1 &
AUTO WHITE BALANCE
INCREASE BLUE GAIN**
INCREASE RED GAIN**
STOP COLOR GAIN**
PRESET STATUS REQUEST
3.10 Latch Status Response Message
BYTE DATA
1 F8H
2 Address in hex
3 "L"
nibble) ) Position data is 30H ored with data nibble
Z03, Z02, Z01, Z00 of zoom lens position data.
Position data is 30H ored with data nibble
F11, F10, F09, F08 of focus data.
Position data is 30H ored with data nibble
F07, F06, F05, F04 of focus data.
nibble) ) Position data is 30H ored with data nibble
F03, F02, F01, F00 of focus data.
80H - 8FH Most significant nibble is always 8. Least significant (LS) nibble is the
XOR of all previous bytes (LS nibble only) except for leading autobaud character
F8H.
Byte #3 Byte #4
"L" "M"
"L" "P"
"L" "L"
"L" "1"
"B" "1"
"B" "2"
"B" "0"
"L" "?"
DESCRIPTION
Snyc character
Camera address (01H - DFH)
Upper case "L"
DESCRIPTION
Toggles iris operation between auto iris and manual iris.
Toggles camera operation on and off.
Toggles between high speed and low speed zoom
Toggles AUX1 output. Also puts camera into auto white AUX1 output. Also puts camera into auto white
balance.
Increase Blue gain in camera.
Increase Red gain in camera.
Stop Red/Blue increase.
Requests current camera status
- 14 -
