Moog Videolarm DDW10CR Product Instructions page 12

E2 (MS nibble)
7
30H - 3FH
E1
8
30H - 3FH
E0 (LS nibble)
9
30H - 3FH
Terminator and
10
Checksum
Notes on "Goto position" command:
Pan position has a range of 0 – 2880. This represents the range of 0 to 360 degrees in steps of .15 degree. A pan position of 000 represents
the home position.
Tilt position has a range of 0 to 950. This represents a range of 0 to 95 degrees in steps of .10 degree. Position 0 is the maximum down position
and position 950 is the maximum up (horizontal) position. Home position is at 450.
3.6 Position Feedback
This command causes the platform to report the current pan and tilt position based on the motor encoders. Byte number 1 is the start of mes-
sage F8H, byte number 2 is the device address (default = 01), and byte number five is the message terminator byte.
FUNCTION
REQUEST POSITION
The response to this command is shown in the table below:
BYTE DATA
1 F8H
2 Address in hex
3 "P"
A2 (MS nibble) 30H
4
- 3FH
A1
5
30H - 3FH
A0 (LS nibble)
6
30H - 3FH
E2 (MS nibble)
7
30H - 3FH
E1
8
30H - 3FH
E0 (LS nibble)
9
30H -3FH
Terminator and
10
Checksum
3.7 GoTo Lens Position Commands Lens Position Commands
This command causes the lens to go to an absolute position based on the motor encoders. The "GOTO LENS POSITION" is shown in its
complete form in the following table:
Position data is 30H ored with data nibble
E11, E10, E09, E08 of elevation data.
Position data is 30H ored with data nibble
E07, E06, E05, E04 of elevation data.
nibble) ) Position data is 30H ored with data nibble
E03, E02, E01, E00 of elevation data.
80H - 8FH Most significant bit is always 1. Least significant (LS) nibble is the XOR
of all previous bytes (LS nibble only) except for leading autobaud character F8H.
Byte #3 Byte #4
"?"
"P"
DESCRIPTION
Sync character
Camera address (01H - DFH)
Upper case "P"
Position data is 30H ored with data nibble
A11, A10, A09, A08 of azimuth data.
Position data is 30H ored with data nibble
A07, A06, A05, A04 of azimuth data.
Position data is 30H ored with data nibble
A03, A02, A01, A00 of azimuth data.
Position data is 30H ored with data nibble
E11, E10, E09, E08 of elevation data.
Position data is 30H ored with data nibble
E07, E06, E05, E04 of elevation data.
nibble) ) Position data is 30H ored with data nibble
E03, E02, E01, E00 of elevation data.
80H - 8FH Most significant nibble is always 8. Least significant (LS) nibble is the
XOR of all previous bytes (LS nibble only) except for leading autobaud character
F8H.
DESCRIPTION
Get position. ASCII character upper case "p" followed
by the "?" character.
- 12 -
