Moog Videolarm QView QRHPC2-50NA Instructions Manual

Qview series qrh rugged dome

Advertisement

Quick Links

Product
Instructions
QView Series QRH Rugged Dome
QRHW & QRHP
Before attempting to connect or operate this product,
please read these instructions completely.
81-IN5338
8/8/05

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the QView QRHPC2-50NA and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Moog Videolarm QView QRHPC2-50NA

  • Page 1 Product Instructions QView Series QRH Rugged Dome QRHW & QRHP Before attempting to connect or operate this product, please read these instructions completely. 81-IN5338 8/8/05...
  • Page 2: Limited Warranty

    1. NOTIFICATION OF CLAIMS: WARRANTY SERVICE: If Purchaser believes that the Product is defective in material or workmanship, then written notice with an explanation of the claim shall be given promptly by Purchaser to Videolarm but all claims for warranty service must be made within the warranty period.
  • Page 3 CABLE AND POWER GUIDELINES This chart shows the proper current needed for power supplies for Q-View™ cameras. Use Class 2 Power only. Input voltage must be 24 VAC/VDC. CAMERAS VOLTAGE CURRENT 24 VAC/VDC 102mA 24 VAC/VDC 210mA 24 VAC/VDC 331mA 24 VAC/VDC 487mA Use the formula below to select the correct power supply for...
  • Page 4 1. This unit includes a 1 1/2" NPT housing for a standard 1 1/2" NPT pipe. The RH7C can be used with other brackets designed with 1 1/2" male pipe threads, such as the Videolarm WM20G and WM20 wall mount brackets.
  • Page 5: Cable And Power Guidelines

    NOTE: The above table is based on a "worst-case" power supply. Using a regulated or switching power supply can increase your cable distance. Videolarm recommends using our PS24 power supply, or a CSA/UL listed Class 2 power supply. The QRH is setup with (2) individual power inputs.
  • Page 6 CAMERA ADJUSTMENT 1. Access the cameras by removing the dome. Loosen the locking screws on the lip of the dome. DO NOT TAKE THESE SCREWS OUT. Once the screws are loosened, turn the dome counter clockwise until it stops, then pull the dome off. CAMERA FOCUSING (FOR EACH CAMERA) Fixed Lens: Loosen the set screw in the lens mount.
  • Page 7: Nvt Instructions

    HIGH-RES COLOR, FIXED LENS FIXED AND FIXED VARI-FOCAL LENSES. There are no user adjustable settings on these units (Figure 14) AUTO IRIS LENSES: The auto iris can be adjusted if needed. See the Troubleshooting section for instructions. Figure 14 HIGH-RES COLOR & DAY/NIGHT w/AUTO-IRIS NOTE: This hi-res color camera uses a 1/4"...
  • Page 8: Wiring Notes

    Wiring Notes Wire — What to DO 1. DO use point-to-point Unshielded Twisted Pair wire, gauge 24 or thicker, stranded or solid, Category 2, 3, 4, or 5. 2. The video signal may co-exist in the same wire bundle as other video, telephone, data, control signals, or low-voltage power.
  • Page 9 NVT TROUBLESHOOTING If you are experiencing problems, attempt to simplify your setup. Test each cable segment separately. For example, test the camera and monitor together without the other equipment. Then add in the NVT transceivers, back-to-back. Test each segment of a long cable-run independently.
  • Page 10: Troubleshooting

    LINE LOCK All cameras are all shipped from the factory with the line lock function disabled. If your application requires Line Lock contact Videolarm. AUTOMATIC BROWN OUT FEATURE The camera includes an automatic brown out feature which is acti- vated whenever the incoming voltage drops below 10 VAC or VDC.
  • Page 11 QRHW / QRHP - Exploded Diagram for Replacement Parts - 11 -...
  • Page 12: Replacement Parts List

    QRHW / QRHP - Replacement Parts List Part Number RPRH701 RPRH702 RC7T RC7C RPRH703 RPFD072 RPFD080 RPFD050 (Model RH7HB) RPRH706 (Model RH7FHB) RPRH707 (Model RH7NHB) RPFD060 RPFD040 RPRH709 RPRH710 WM10 RPQF01 RPQF02 RPQRH71000 RPQRH71010 RPQF20NF3 RPQF20NA RPQF50NF3 RPQF50NA RPQF70NA RPQRH72000 Description Lower Trim Ring (Gray) Lower Trim Ring (White)
  • Page 13 Mounting Template R .733 2.132 5.500 1.537 2.981 2.000 3.250 - 13 -...
