©2011, Videolarm, Inc. All Rights Reserved
D e p u t y D o m e ™
Bullet-Resistant IP Camera Housing
Installation and Operation Instructions for the following models:
DDW10CN2
DeputyDome™, Bullet-Resistant IP Camera System, PTZ and 26x Day/
Night Camera System features Heavy-Duty Metal Gear Pan/ Tilt. MPEG-4
and MJPEG video compression format, full D1. Clear dome, with 24Vac
input, heater/ blower Tough enough to stop a 9mm bullet
PDDW10CN2
(Pressurized Version)
DeputyDome™, Bullet-Resistant IP Camera System, PTZ and 26x Day/
Night Camera System features Heavy-Duty Metal Gear Pan/ Tilt. MPEG-4
and MJPEG video compression format, full D1. Clear dome, with 24Vac
input, heater/blower Tough enough to stop a 9mm bullet
B e f o r e a t t e m p t i n g t o c o n n e c t o r o p e r a t e t h i s p r o d u c t , p l e a s e r e a d t h e s e i n s t r u c t i o n s c o m p l e t e l y.
- 1 -
www.videolarm.com
81-IN5387
12-13-2011
Advertisement
Related Manuals for Moog Videolarm DeputyDome SERIES
Summary of Contents for Moog Videolarm DeputyDome SERIES
- Page 1 ©2011, Videolarm, Inc. All Rights Reserved D e p u t y D o m e ™ Bullet-Resistant IP Camera Housing www.videolarm.com Installation and Operation Instructions for the following models: DDW10CN2 DeputyDome™, Bullet-Resistant IP Camera System, PTZ and 26x Day/ Night Camera System features Heavy-Duty Metal Gear Pan/ Tilt.
-
Page 2: Important Safeguards
IMPORTANT SAFEGUARDS SAFETY PRECAUTIONS Read these instructions. Keep these instructions. CAUTION Heed all warnings RISK OF ELECTRIC SHOCK DO NOT OPEN Follow all instructions. Do not use this apparatus near water. CAUTION: TO REDUCE THE RISK OF Clean only with damp cloth. ELECTRIC SHOCK, DO NOT REMOVE COVER ( OR BACK). - Page 3 If Purchaser believes that the Product is defective in material or workmanship, then written notice with an explanation of the claim shall be given promptly by Purchaser to Moog Videolarm. All claims for warranty service must be made within the warranty period.
-
Page 4: Standard Installation Procedure
NOTE: WALL MOUNT INSTALLATION (cont.) The DeputyDome™ is packed in two separate boxes, one for the housing and one for the 4. After the wall mount is securely attached to the wall, remove the (3) 10-32 tamper pan/tilt and bullet-resistant liner. Installation should be completed as follows: resistant screws with the provided security tool (Figure 3) and take off the access plate. - Page 5 CAUTION: Using smaller than recommended cable sizes can result in poor performance Wiring Chart Non-Pressurized Receiver Version and damage to the heater and camera. A. Heater 1) Red - Heater 1 Wire Gauge 2) N/C 3) Red - Heater B. Camera Power 25ft 40 ft 64 ft...
- Page 6 REATTACHING THE DOME ON PRESSURIZED UNITS 6. The liner should still be able to move up by about 1/16" on an inch to allow the liner to move when shot and transfer the force to the housing instead of the pan/tilt. 1.
- Page 7 IP Instructions The factory default IP adress is 192.168.0.200. See IP Ready camera instruction for installation details. For Pan/Tilt control click on PTZ control icon in top right corner. Pan/Tilt control contains standard pan/tilt/camera control functions. To save preset, pull down #1 preset, move camera to desired position and then hit "save"...
- Page 8 PROCEDURES FOR PRESSURIZED HOUSINGS Filling and Refilling Pressurized housings provide maximum protection for CCTV cameras and lenses. The 1. Attach the barb to the regulator. charge of dry nitrogen inside the housing eliminates the effects of moisture, dust, insects and corrosive exhaust fumes. This allows a longer lifetime for your surveillance 2.
- Page 9 Exploded View for Replacement Parts - 9 -...
- Page 10 Exploded View for Replacement Parts (Pan/Tilt Assembly) - 10 -...
- Page 11 Exploded View for Replacement Parts (Pan Bearing Assembly) - 11 -...
- Page 12 Exploded View for Replacement Parts (Network Assembly) - 12 -...
- Page 13 Replacement Parts List Part No. Description 91-NTFL01 3/8-16 Flange Nut (4) 90-BTSEC06 1/4-20 x 1/2" Security screw SS (2) 50-VL1428 DDWC10 housing body 30-VL1405 DDWC10 accs mounting bracket 92-WSFL01 1/4 Flat Washer SS (4) 92-WSSL01 1/4 Split Lockwasher SS (4) 90-BTHH32 1/4-20 x 1/2"...
- Page 14 Should a problem arise, rest assure that Moog Videolarm stands behind its products by offering impressive warranty plans: 3 Years on all Housings, Poles, Power Supplies, and Accessories and 5 Years on camera systems (SView, QView, Warriors), and InfraRed Illuminators.
