- Page 1 Product Instructions IP Ready Series ™ FDW75C12N & FDP75C12N Before attempting to connect or operate this product, please read these instructions completely. 81-IN5329 04/28/06 - -...
-
Page 2: Limited Warranty
iMPoRtant safEGuaRDs 1. Read Instructions - All the safety and operating instructions should be read before the unit is operated. 2. Retain Instructions - T he safety and operating instructions should be retained for future reference. 3. Heed Warnings - All warnings on the unit and in the operating instructions should be adhered to. 4. Follow Instructions - All operating & user instructions should be followed. 5. Electrical Connections - Only a qualified electrician should make electrical connections. 6. Attachments - Do not use attachments not recommended by the product manufacturer as they may cause hazards. 7. Cable Runs - All cable runs must be within permissible distance. 8. Mounting - This unit must be properly and securely mounted to a supporting structure capable of sustaining the weight of the unit. Accordingly: a. Installation should be made by a qualified installer. b. Installation should be in compliance with local codes. c. Care should be exercised to select suitable hardware to install the unit, taking into account both the composition of the mounting surface and the weight of the unit. Be sure to periodically examine the unit and the supporting structure to make sure that the integrity of the installation is intact. Failure to comply with the foregoing could result in the unit... -
Page 3: General Instructions
FDW75C12N, FDP75C12N IP Ready Network Housing IP Ready Network Housing with 12Vdc input, wall mount or pendant mounting, heater & blowers, ready for standard IP PTZ cameras. ELECTRICAL SPECIFICATIONS (OUTDOOR ONLY): Power 12Vdc, Class 2 Only Total Power: 21 watts Housing only Accessories (Heater/Blower): 21 watts Heater: 20 watts Blower: 1 watt... -
Page 4: Table Of Contents
See specific instruction for the model that matches the unit you have. INDEX OF CAMERAS AXIS 213 AXIS 214 CANON VB-C10R CANON VB-C50iR CANON VC-C4R / VC-C50iR ELMO PTC-200C ELMO PTC-201 ELMO PTC-400C ELMO PTC-401 JVC VN-C30U PANASONIC BB-HCM381 / KX-HMC280... -
Page 5: Axis 213
INSTALLING QUICK RELEASE BRACKETS AXIS 213 2539 Mounting Plate: Attach camera using these (2) holes 1. Install the camera to the 2539 mounting plate using (2) 10-32 screws and lockwashers provided. 2. The Axis 213 camera requires 3.5" of spacing for optimal position within the housing. -
Page 6: Axis 214
INSTALLING QUICK RELEASE BRACKETS AXIS 214 2685 Mounting Plate: Attach camera using these (3) holes 1. Install the AXIS 214 camera to the 2685 mounting plate using the (3) 3mm x 12mm bolt and lock washers provided. 2. The AXIS 214 camera requires 2” of spacing for optimal position within the housing. -
Page 7: Canon Vb-C10R
1. Install the camera to the 2539 mounting plate using (2) 10-32 screws and lockwashers provided. 2. The Canon VB-C10R camera requires 4" of spacing for optimal position within the housing. Use (4) 2" spacer(s), plus (4) 1" spacer(s) and (4) ½" spacer(s) provided in the (2) hardware packets. -
Page 8: Canon Vb-C50Ir
1. Install the camera to the 2539 mounting plate using (2) 10-32 screws and lockwashers provided. 2. The Canon VB-C50iR camera requires 3.5" of spacing for optimal position within the housing. Use (4) 2" spacer(s), plus (4) 1" spacer(s) and (4) ½" spacer(s) provided in the (2) hardware packets. -
Page 9: Canon Vc-C4R / Vc-C50Ir
1. Install the camera to the 2539 mounting plate using (2) 10-32 screws and lockwashers provided. 2. The Canon VC-C4R / VC-C50iR camera requires 4" of spacing for optimal position within the housing. Use (4) 2" spacer(s), plus (8) 1" spacer(s) provided in the (2) hardware packets. -
Page 10: Elmo Ptc-200C
INSTALLING QUICK RELEASE BRACKETS ELMO PTC-200C Mounting plate for this unit is included in the housing packet. Remove existing mounting plate installed in the unit before proceeding. 2539 Mounting Plate: Attach camera using these (4) holes 1. Place the camera onto the quick release bracket using the (4) metric 3M Phillips head screws provided with the kit. -
Page 11: Elmo Ptc-201
INSTALLING QUICK RELEASE BRACKETS ELMO PTC-201 Mounting plate for this unit is included in the housing packet. Remove existing mounting plate installed in the unit before proceeding. 2539 Mounting Plate: Attach camera using these (4) holes 1. Place the camera onto the quick release bracket using the (4) metric 3M Phillips head screws provided with the kit. -
Page 12: Elmo Ptc-400C
INSTALLING QUICK RELEASE BRACKETS ELMO PTC-400C Mounting plate for this unit is included in the housing packet. Remove existing mounting plate installed in the unit before proceeding. 2539 Mounting Plate: Attach camera using these (4) holes 1. Place the camera onto the quick release bracket using the (4) metric 3M Phillips head screws provided with the kit. -
Page 13: Elmo Ptc-401
INSTALLING QUICK RELEASE BRACKETS ELMO PTC-401 Mounting plate for this unit is included in the housing packet. Remove existing mounting plate installed in the unit before proceeding. 2539 Mounting Plate: Attach camera using these (4) holes 1. Remove the mounting plate from the camera and place it onto the quick release bracket using the (4) metric 3M Phillips head screws provided with the kit. -
Page 14: Jvc Vn-C30U
INSTALLING QUICK RELEASE BRACKETS JVC VN-C30U 2539 Mounting Plate: Attach camera using these (3) holes 1. Remove the mounting plate from the camera and place it onto the quick release bracket using the (3) metric 3M Phillips head screws provided with the kit. Then place the mounting plate back onto the JVC VN-C30U. -
Page 15: Panasonic Bb-Hcm381 / Kx-Hmc280
INSTALLING QUICK RELEASE BRACKETS PANASONIC BB-HCM381 / KX-HMC280 2539 Mounting Plate: Attach camera using this hole 1. Install the camera to the 2539 mounting plate using the ¼ x 20, washer and lockwasher provided. 2. The Panasonic BB-HCM381 / KX-HMC280 requires 3½" of spacing to properly position the camera within the housing. -
Page 16: Pixord 261 / 262
INSTALLING QUICK RELEASE BRACKETS PIXORD 261 / 262 2630 Mounting Plate: Attach camera using these (3) holes 1. Install the camera to the 2630 mounting plate using the (3) 8 x 32 x .5 flat head screws, nuts and washers provided. -
Page 17: Sony Sncrz30
INSTALLING QUICK RELEASE BRACKETS SONY SNCRZ30 2539 Mounting Plate: Attach camera using this hole 1. Attach the camera to the 2539 mounting plate using the (1) ¼ x 20 bolt, washer and lockwasher provided. 2" 2. The SNCRZ30 require 2” of spacing to properly position the camera within the housing. -
Page 18: Sony Sncrz50
INSTALLING QUICK RELEASE BRACKETS SONY SNCRZ50 2539 Mounting Plate: Attach camera using this hole 1. Attach the SNCRZ50 camera to 2539 mounting plate using 3mm x 8mm bolt lockwashers provided. ½" 2" 2. The SONY SNCRZ50 require 2 ½ ” of spacing to properly position the camera within the housing. -
Page 19: Toshiba Ik-Wb21A
INSTALLING QUICK RELEASE BRACKETS TOSHIBA IK-WB21A 2539 Mounting Plate: Attach camera using these (4) holes 1. Remove the quick release bracket from the camera. Using (4) 8 x 32 x 3/8 bolts and star washers attach the quick release place to the 2539 mounting plate. 1"... -
Page 20: Wiring Instructions
WIRING INSTRUCTIONS Wiring Color Code Power and Control Inputs AFTER CAMERA INSTALLATION Make inside housing wiring connections following Chart B below. Chart A Wiring Color Code Power and Control Inputs (Outside of housing) POWER Camera Power (+12 VDC) Camera Power (-12 VDC) Accessory Power (+12 VDC) Accessory Power (-12 VDC) CONTROL... -
Page 21: Installing Wall Mount
3. Mount the housing assembly to the mounting bracket and housing coupling. A safety cable is included with the housing to temporarily hold it while making wiring connections. Loop the safety cable over one of the set screws on the housing coupling and make the appropriate connections using the (2) screw-down connectors supplied. - Page 22 Exploded View for Replacement Parts 1 1 1 - - Not included on 12Vdc housings...
- Page 23 Replacement Parts List Part Number RPFD7501 FD7T FD7C RPFD703 RPFD072 RPFD080 RPFD060 RPFD050 (MODEL FD7HB) RPRH707 (MODEL FD7NHB) CONNECTION PCB (NETWORK MODELS) (24VAC ONLY) RPFD040 RPFD709 RPFD2612 WM10 RPNET02 RPNET04 SD0170 SD0180 SD0160 RPPKH2090 RPPKH2071 RPPKE1100 RPPKE1125 RPTRAN02 Description LOWER TRIM RING TINTED REPLACEMENT CAPSULE CLEAR REPLACEMENT CAPSULE DOME CLAMPING BRACKET...
- Page 24 Mounting Template R .733 2.132 5.500 1.537 2.981 2.000 3.250 - -...
