uIBX-200-VX800 Embedded System
MODEL:
uIBX-200-VX800
Ultra Compact Embedded System with CompactFlash® Slot
VGA, Gigabit Ethernet, 4 x USB, 802.11b/g Wireless,
Line out, Mic, 2 x RS-232, RoHS Compliant
Standard SIB

User Manual

Page i
Rev. 1.01 – 2009

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the uIBX-200-VX800 and is the answer not in the manual?

Questions and answers

Related Manuals for IEI Technology uIBX-200-VX800

Summary of Contents for IEI Technology uIBX-200-VX800

  • Page 1: User Manual

    Embedded System MODEL: uIBX-200-VX800 Ultra Compact Embedded System with CompactFlash® Slot VGA, Gigabit Ethernet, 4 x USB, 802.11b/g Wireless, Line out, Mic, 2 x RS-232, RoHS Compliant Standard SIB User Manual Page i Rev. 1.01 – 2009...
  • Page 2 Embedded System Revision Date Version Changes 4 December, 2009 1.01 Added BIOS chapter 27 August, 2009 1.00 Initial release Page ii...
  • Page 3 Embedded System Copyright COPYRIGHT NOTICE The information in this document is subject to change without prior notice in order to improve reliability, design and function and does not represent a commitment on the part of the manufacturer. In no event will the manufacturer be liable for direct, indirect, special, incidental, or consequential damages arising out of the use or inability to use the product or documentation, even if advised of the possibility of such damages.

  • Page 4: Table Of Contents

    Embedded System Table of Contents 1 INTRODUCTION ......................1 1.1 O ........................2 VERVIEW 1.2 B ........................2 ENEFITS 1.3 F ........................3 EATURES 1.4 T ..................3 ECHNICAL PECIFICATIONS 1.5 C ......................4 ERTIFICATIONS 2 DETAILED SPECIFICATIONS .................. 5 2.1 F...
  • Page 5 Embedded System 4.4.5 USB Connector ....................22 4.4.6 VGA Connector ....................23 4.5 M ..................24 OUNTING THE YSTEM 4.6 S ........................ 26 OFTWARE 5 BIOS ..........................28 5.1 I ......................29 NTRODUCTION 5.1.1 Starting Setup ....................29 5.1.2 Using Setup ...................... 29 5.1.3 Getting Help .....................
  • Page 6 Embedded System 5.8 E ......................... 60 A SAFETY PRECAUTIONS ..................62 A.1 S .................... 63 AFETY RECAUTIONS A.1.1 General Safety Precautions ................63 A.1.2 Anti-static Precautions ..................64 A.2 M ............64 AINTENANCE AND LEANING RECAUTIONS A.2.1 Maintenance and Cleaning ................64 A.2.2 Cleaning Tools ....................
  • Page 7 List of Figures Figure 1-1: uIBX-200-VX800 ......................2 Figure 2-1: Front Panel ........................6 Figure 2-2: uIBX-200-VX800 Peripheral Connectors ..............7 Figure 2-3: Physical Dimensions (millimeters) ................8 Figure 4-1: CompactFlash® Card Installation ................17 Figure 4-2: Peripheral Connectors (Rear) .................. 18 Figure 4–3: Peripheral Connectors (Front) ................
  • Page 8 Embedded System List of Tables Table 1-1: Technical Specifications ....................4 Table 3-1: Package List Contents ....................11 Table 3-2: Optional Items ......................12 Table 4-1: Jumpers ........................15 Table 4-2: AT/ATX Power Select Jumper Settings ..............15 Table 4-3: CompactFlash® Master/Slave Selection ..............16 Table 4-4: Clear BIOS Jumper Settings ..................

  • Page 9: Introduction

    Embedded System Chapter Introduction Page 1...

  • Page 10: Overview

    1.1 Overview Figure 1-1: uIBX-200-VX800 The uIBX-200-VX800 embedded system is an ultra small PC for installation between a computer screen and its stand. It is powered by the VIA® Eden™ ULV 1 GHz/500 MHz processor, uses the VIA® VX800 system chip and has 1.0 GB or 512 MB of DDR2 memory.

  • Page 11: Features

    One Gigabit Ethernet port Four USB 2.0 ports Two RS-232 serial ports RoHS compliant 1.4 Technical Specifications The uIBX-200-VX800 technical specifications are listed in Table 1-1. Specifications System VIA® Eden™ ULV 1 GHz/500 MHz processor 1.0 GB or 512 MB of DDR2 memory...

  • Page 12: Certifications

    120 mm x 44.4 mm x 125 mm Physical Dimensions Table 1-1: Technical Specifications 1.5 Certifications All uIBX-200-VX800 series models comply with the following international standards: RoHS CE, FCC Class A, CCC For a more detailed description of these standards, please refer to Appendix A.

  • Page 13: Detailed Specifications

    Embedded System Chapter Detailed Specifications Page 5...

  • Page 14: Front Panel

    2 x USB connectors 1 x Microphone input 1 x Line output 2.2 Rear Connector Panel All external peripheral interface connectors are located on the bottom panel of the uIBX-200-VX800 . The peripheral interface connectors are shown in Figure 2-2. Page 6...

  • Page 15: Figure 2-2: Uibx-200-Vx800 Peripheral Connectors

    Embedded System Figure 2-2: uIBX-200-VX800 Peripheral Connectors Connectors and buttons on the rear panel include the following. 1 x 5 V DC power input 1 x Power switch 1 x VGA output 2 x RS-232 ports 2 x USB ports...

  • Page 16: Dimensions

    The physical dimensions are shown and listed below: Width: 120 mm Height: 44.4 mm Depth: 125 mm Figure 2-3: Physical Dimensions (millimeters) 2.4 Maintenance Don't open the uIBX-200-VX800 (except the CompactFlash® door), there are no user-serviceable parts inside. Page 8...

  • Page 17: Unpacking

    Embedded System Chapter Unpacking Page 9...

  • Page 18: Anti-Static Precautions

    Electrostatic discharge (ESD) can cause serious damage to electronic components, including the uIBX-200-VX800. Dry climates are especially susceptible to ESD. It is therefore critical that whenever the uIBX-200-VX800 or any other electrical component is handled, the following anti-static precautions are strictly adhered to.

  • Page 19: Unpacking Checklist

    If some of the components listed in the checklist below are missing, please do not proceed with the installation. Contact your sales representative directly. To contact us http://www.emacinc.com/support/ The uIBX-200-VX800 is shipped with the following components: Quantity Item and Part Number Image...

  • Page 20: Optional Items

    Embedded System 3.4 Optional Items Quantity Item Image uIBXVK-200B Double side VESA mount kit for uIBX-200, black Table 3-2: Optional Items Page 12...

  • Page 21: Installation

    Embedded System Chapter Installation Page 13...

  • Page 22: Installation Precautions

    Electric shock and personal injury might occur if the rear panel of the uIBX-200-VX800 is opened while the power cord is still connected to an electrical outlet.

  • Page 23: Jumper Settings

    Embedded System 4.2 Jumper Settings NOTE: A jumper is a metal bridge used to close an electrical circuit. It consists of two or three metal pins and a small metal clip (often protected by a plastic cover) that slides over the pins to connect them. To...

  • Page 24: Compactflash® Master/Slave Selection

    Keep current BIOS setup Clear BIOS Table 4-4: Clear BIOS Jumper Settings 4.3 CompactFlash® Card Installation The uIBX-200-VX800 supports a single CompactFlash® card. To install, follow the steps below. Unlock and open the cover door. Step 1: Slide the CompactFlash® card into the slot.

  • Page 25: External Peripheral Interface Connectors

    Embedded System Figure 4-1: CompactFlash® Card Installation 4.4 External Peripheral Interface Connectors The uIBX-200-VX800 has the following connectors. Detailed descriptions of the connectors can be found in the subsections below. Power input Ethernet RS-232 Antenna connector Line out Page 17...

  • Page 26: Power Input

    Embedded System Figure 4-2: Peripheral Connectors (Rear) Figure 4–3: Peripheral Connectors (Front) 4.4.1 Power Input The power terminal block connects to the included 5 V DC power adapter. CN Label: Power Input Page 18...

  • Page 27: Audio Connector

    Embedded System CN Type: KYCON KPPX-3P See Figure 4-2 CN Location: See Figure 4-4 CN Pinouts: Figure 4-4: Power Terminal Block 4.4.2 Audio Connector CN Label: Line out, Mic Audio jacks CN Type: See Figure 4–3 CN Location: The audio jacks connect to external audio devices.

  • Page 28: Figure 4-6: Lan Connection

    Align the connectors. Align the RJ-45 connector on the LAN cable with one of Step 2: the RJ-45 connectors on the uIBX-200-VX800. See Figure 4-6. Figure 4-6: LAN Connection Insert the LAN cable RJ-45 connector. Once aligned, gently insert the LAN Step 3: cable RJ-45 connector into the on-board RJ-45 connector.

  • Page 29: Serial Port Connector

    Embedded System The RJ-45 Ethernet connector has two status LEDs, one green and one yellow. The green LED indicates activity on the port and the yellow LED indicates the port is linked. See Table 4-6. STATUS DESCRIPTION STATUS DESCRIPTION...

  • Page 30: Usb Connector

    Embedded System Figure 4-8: Serial Port Pinouts 4.4.5 USB Connector CN Label: USB port CN Type: See Figure 4-2 and Figure 4–3 CN Location: See Table 4-8 CN Pinouts: The USB ports are for attaching USB peripheral devices to the system.

  • Page 31: Vga Connector

    DB-15 connector on the external peripheral interface. Once the connectors are properly aligned with the insert the male Insert the VGA connector. connector from the VGA screen into the female connector on the uIBX-200-VX800. Figure 4-9: VGA Connector Figure 4-10: VGA Connector Description...

  • Page 32: Mounting The System

    Embedded System 4.5 Mounting the System To install the uIBX-200-VX800 on the VESA mounting slot, between the monitor stand and the monitor, follow the instructions below. Fasten the attachment onto the VESA mounting on the back of the monitor.

  • Page 33: Figure 4-14: System Attachment Screws

    Embedded System NOTE: It may be easier to perform the next two steps in reverse order, depending on installation conditions. Slide the uIBX-200-VX800 into the attachment and fasten the four screws Step 7: indicated. Figure 4–12: System Attachment Screws...

  • Page 34: Software

    Three common methods of mounting the uIBX-200-VX800 are listed in the subsections below. 4.6 Software The uIBX-200-VX800 comes with a pre-installed Windows XPE, CE 6.0 or Linux 2.6.x operating system and a rich software application development kit. For information about configuring the operating system, adding remote management tools or additional software and drivers, refer to the utility CD.
  • Page 35 Embedded System Free remote management tools installed in laptop for remotely configuring, monitoring, and managing your uIBX-200-VX800. Page 27...

  • Page 36: Bios

    Embedded System Chapter BIOS Page 28...

  • Page 37: Introduction

    Embedded System 5.1 Introduction The BIOS is programmed onto the BIOS chip. The BIOS setup program allows changes to certain system settings. This chapter outlines the options that can be changed. 5.1.1 Starting Setup The AMI BIOS is activated when the computer is turned on. The setup program can be activated in one of two ways.

  • Page 38: Getting Help

    Embedded System Function F2 /F3 key Change color from total 16 colors. F2 to select color forward. F10 key Save all the CMOS changes, only for Main Menu Table 5-1: BIOS Navigation Keys 5.1.3 Getting Help When F1 is pressed a small help window describing the appropriate keys to use and the possible selections for the highlighted item appears.

  • Page 39: Main

    Embedded System 5.2 Main The Main BIOS menu (BIOS Menu 1) appears when the BIOS Setup program is entered. The Main menu gives an overview of the basic system information. BIOS SETUP UTILITY Main Advanced PCIPNP Boot Security Chipset...

  • Page 40: Advanced

    Embedded System The System Overview field also has two user configurable fields: System Time [xx:xx:xx] Use the System Time option to set the system time. Manually enter the hours, minutes and seconds. System Date [xx/xx/xx] Use the System Date option to set the system date. Manually enter the day, month and year.

  • Page 41: Cpu Configuration

    Embedded System BIOS SETUP UTILITY Main Advanced PCIPNP Boot Security Chipset Exit Advanced Settings Configure CPU ⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯ WARNING: Setting wrong values in below sections may cause system to malfunction > CPU Configuration > IDE Configuration > SuperIO Configuration Select Screen ↑...

  • Page 42: Ide Configuration

    Embedded System FSB Speed: Lists the FSB speed Cache L1: Lists the CPU L1 cache size Cache L2: Lists the CPU L2 cache size 5.3.2 IDE Configuration Use the IDE Configuration menu (BIOS Menu 4) to change and/or set the configuration of the IDE devices installed in the system.

  • Page 43: Sata Channel

    Embedded System 5.3.2.1 SATA Channel Sets the IDE configuration of the SATA channels. BIOS SETUP UTILITY Main Advanced PCIPNP Boot Security Chipset Exit Primary IDE Master Select the type of device ⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯ connected to the system Device :Not Detected...
  • Page 44 Embedded System This option specifies an ATAPI Removable Media ARMD Device. These include, but are not limited to: LS-120 LBA/Large Mode [Auto] Use the LBA/Large Mode option to disable or enable BIOS to auto detects LBA (Logical Block Addressing). LBA is a method of addressing data on a disk drive. In LBA mode, the maximum drive capacity is 137 GB.
  • Page 45 Embedded System BIOS auto detects the PIO mode. Use this value if the IDE disk Auto EFAULT drive support cannot be determined. PIO mode 0 selected with a maximum transfer rate of 3.3 MB/s PIO mode 1 selected with a maximum transfer rate of 5.2 MB/s PIO mode 2 selected with a maximum transfer rate of 8.3 MB/s...
  • Page 46 Embedded System Ultra DMA mode 1 selected with a maximum data transfer UDMA1 rate of 25 MB/s Ultra DMA mode 2 selected with a maximum data transfer UDMA2 rate of 33.3 MB/s Ultra DMA mode 3 selected with a maximum data transfer...

  • Page 47: Super Io Configuration

    Embedded System 5.3.3 Super IO Configuration Use the Super IO Configuration menu (BIOS Menu 6) to set or change the configurations for the FDD controllers, parallel ports and serial ports. BIOS SETUP UTILITY Main Advanced PCIPNP Boot Security Chipset...

  • Page 48: Power Configuration

    Embedded System Disabled EFAULT Serial Port2 IRQ [3 Sets the interrupt request for serial port 2. EFAULT 5.3.4 Power Configuration The Power Configuration menu (BIOS Menu 7) configures the power options. BIOS SETUP UTILITY Main Advanced PCIPNP Boot Security...

  • Page 49: Acpi Configuration

    Embedded System 5.3.4.1 ACPI Configuration Use the ACPI Configuration menu (BIOS Menu 8) to select the ACPI state when the system is suspended. BIOS SETUP UTILITY Main Advanced PCIPNP Boot Security Chipset Power Exit General ACPI Configuration ⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯ Suspend Mode...

  • Page 50: Apm Configuration

    Embedded System 5.3.4.2 APM Configuration The APM Configuration menu (BIOS Menu 9) allows the advanced power management options to be configured. BIOS SETUP UTILITY Main Advanced PCIPNP Boot Security Chipset Exit Restore on AC Power Loss [Power Off] Power Button Mode...

  • Page 51: Remote Access Configuration

    Embedded System Resume on Ring [Disabled] Use the Resume on Ring BIOS option to enable activity on the RI (ring in) modem line to rouse the system from a suspend or standby state. That is, the system will be roused by an incoming call on a modem.
  • Page 52 Embedded System allows a remote host running a terminal program to display and configure the BIOS settings. BIOS SETUP UTILITY Main Advanced PCIPNP Boot Security Chipset Exit Configure Remote Access type and parameters ⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯ Remote Access [Disabled] Serial port number...
  • Page 53 Embedded System System is remotely accessed through COM1 COM1 EFAULT System is remotely accessed through COM2 COM2 NOTE: Make sure the selected COM port is enabled through the Super I/O configuration menu. Base Address, IRQ [3F8h,3] The Base Address, IRQ option cannot be configured and only shows the interrupt address of the serial port listed above.

  • Page 54: Usb Configuration

    Embedded System Redirection is always active (Some OSes may not Always EFAULT work if set to Always) Terminal Type [ANSI] Use the Terminal Type BIOS option to specify the remote terminal type. The target terminal type is ANSI ANSI...
  • Page 55 Embedded System USB 2.0 Ports Enabled [Enabled] The USB ports will only operate in the legacy USB 1.1 mode unless this setting is enabled. Disabled EFAULT Enabled Legacy USB Support [Enabled] Use the Legacy USB Support BIOS option to enable USB mouse and USB keyboard support.

  • Page 56: Usb Mass Storage Device Configuration

    Embedded System 5.3.6.1 USB Mass Storage Device Configuration Use the USB Mass Storage Device Configuration menu (BIOS Menu 12) to configure USB mass storage class devices. BIOS SETUP UTILITY Main Advanced PCIPNP Boot Security Chipset Exit USB Mass Storage Device Configuration ⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯...

  • Page 57: Pci/Pnp

    Embedded System Emulation Type [Auto] Use the Emulation Type BIOS option to specify the type of emulation BIOS has to provide for the USB device. BIOS auto-detects the current USB. Auto EFAULT The USB device will be emulated as a floppy drive.
  • Page 58 Embedded System BIOS SETUP UTILITY Main Advanced PCIPNP Boot Security Chipset Exit Advanced PCI/PnP Settings Available: Specified ⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯ IRQ is available to be used by PCI/PnP WARNING: Setting wrong values in below sections devices. may cause system to malfunction...
  • Page 59 Embedded System IRQ10 IRQ 11 IRQ 14 IRQ 15 DMA Channel# [Available] Use the DMA Channel# option to assign a specific DMA channel to a particular PCI/PnP device. The specified DMA is available to be used by Available EFAULT...

  • Page 60: Boot

    Embedded System 5.5 Boot Use the Boot menu (BIOS Menu 14) to configure system boot options. BIOS SETUP UTILITY Main Advanced PCIPNP Boot Security Chipset Exit Boot Settings Configure settings ⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯ during system boot. > Boot Settings Configuration > Boot Device Priority >...
  • Page 61 Embedded System Quick Boot [Enabled] Use the Quick Boot BIOS option to make the computer speed up the boot process. No POST procedures are skipped Disabled Some POST procedures are skipped to decrease Enabled EFAULT the system boot time Quiet Boot [Disabled] Use the Quiet Boot BIOS option to select the screen display when the system boots.

  • Page 62: Boot Device Priority

    Embedded System Allows the Number Lock on the keyboard to be enabled EFAULT automatically when the computer system boots up. This allows the immediate use of the 10-key numeric keypad located on the right side of the keyboard. To confirm this, the Number Lock LED light on the keyboard is lit.

  • Page 63: Hard Disk Drives

    Embedded System 5.5.3 Hard Disk Drives Use the Hard Disk Drives menu to specify the boot sequence of the available HDDs. Only installed hard drives are shown. BIOS SETUP UTILITY Main Advanced PCIPNP Boot Security Chipset Exit Hard Disk Drives Specifies the boot ⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯...

  • Page 64: Cd/Dvd Drives

    Embedded System 5.5.5 CD/DVD Drives Use the CD/DVD Drives menu to specify the boot sequence of the available CD/DVD drives. When the menu is opened, the CD drives and DVD drives connected to the system are listed as shown below:...

  • Page 65: Security

    Embedded System 5.6 Security Use the Security menu (BIOS Menu 20) to set system and user passwords. BIOS SETUP UTILITY Main Advanced PCIPNP Boot Security Chipset Exit Security Settings ⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯ Supervisor Password :Not Installed User Password :Not Installed Change Supervisor Password...

  • Page 66: Northbridge Via® Vx800 Configuration

    Embedded System WARNING! Setting the wrong values for the Chipset BIOS selections in the Chipset BIOS menu may cause the system to malfunction. BIOS SETUP UTILITY Main Advanced PCIPNP Boot Security Chipset Exit Advanced Chipset Settings Options for VIA® VX800 ⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯...

  • Page 67: Southbridge Via® Vx800 Configuration

    Embedded System VGA Frame Buffer Size [Auto] Specifies how much memory is allocated to the graphics. 16MB 32MB 64MB 128MB EFAULT 256MB 5.7.2 Southbridge VIA® VX800 Configuration The Southbridge VIA® VX800 Configuration configures the system chipset. BIOS SETUP UTILITY...

  • Page 68: Exit

    Embedded System 5.8 Exit Use the Exit menu (BIOS Menu 24) to load default BIOS values, optimal failsafe values and to save configuration changes. BIOS SETUP UTILITY Main Advanced PCIPNP Boot Security Chipset Exit Exit Options Exit system setup after ⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯...
  • Page 69 Embedded System Load Failsafe Defaults Use the Load Failsafe Defaults option to load failsafe default values for each of the parameters on the Setup menus. F8 key can be used for this operation. Page 61...

  • Page 70: A Safety Precautions

    Embedded System Appendix Safety Precautions Page 62...

  • Page 71: General Safety Precautions

    Embedded System A.1 Safety Precautions WARNING: The precautions outlined in this appendix should be strictly followed. Failure to follow these precautions may result in permanent damage to the uIBX-200-VX800. Please follow the safety precautions outlined in the sections that follow: A.1.1 General Safety Precautions...

  • Page 72: Anti-Static Precautions

    When maintaining or cleaning the uIBX-200-VX800, please follow the guidelines below. A.2.1 Maintenance and Cleaning Prior to cleaning any part or component of the uIBX-200-VX800, please read the details below. Except for the LCD panel, never spray or squirt liquids directly onto any other components.

  • Page 73: Cleaning Tools

    In such case, the product will be explicitly mentioned in the cleaning tips. Below is a list of items to use when cleaning the uIBX-200-VX800.  C loth – Although paper towels or tissues can be used, a soft, clean piece of cloth is recommended when cleaning the uIBX-200-VX800.

  • Page 74: B Hazardous Materials Disclosure

    Embedded System Appendix Hazardous Materials Disclosure Page 66...

  • Page 75: Ipb Products Cercury

    Embedded System B.1 Hazardous Materials Disclosure Table for Products Certified as RoHS Compliant Under 2002/95/EC Without Mercury The details provided in this appendix are to ensure that the product is compliant with the Peoples Republic of China (China) RoHS standards. The table below acknowledges the presences of small quantities of certain materials in the product, and is applicable to China RoHS only.
  • Page 76 Embedded System Part Name Toxic or Hazardous Substances and Elements Lead Mercury Cadmium Hexavalent Polybrominated Polybrominated (Pb) (Hg) (Cd) Chromium Biphenyls Diphenyl (CR(VI)) (PBB) Ethers (PBDE) Housing Display Printed Circuit Board Metal Fasteners Cable Assembly Fan Assembly Power Supply...
  • Page 77 Embedded System 此附件旨在确保本产品符合中国 RoHS 标准。以下表格标示此产品中某有毒物质的含量符 合中国 RoHS 标准规定的限量要求。 本产品上会附有”环境友好使用期限”的标签，此期限是估算这些物质”不会有泄漏或突变”的 年限。本产品可能包含有较短的环境友好使用期限的可替换元件，像是电池或灯管，这些元 件将会单独标示出来。 部件名称 有毒有害物质或元素 铅 汞 镉 六价铬 多溴联苯 多溴二苯 醚 (Pb) (Hg) (Cd) (CR(VI)) (PBB) (PBDE) 壳体 显示 印刷电路板 金属螺帽 电缆组装 风扇组装 电力供应组装 电池 O: 表示该有毒有害物质在该部件所有物质材料中的含量均在 SJ/T11363-2006 标准规定的限量要求以下。 X: 表示该有毒有害物质至少在该部件的某一均质材料中的含量超出 SJ/T11363-2006 标准规定的限量要求。...
