Intelix DIGI-HD-4X2 Installation Manual
26
Technical Specifications
Vertical Frequency Range ..................................................................... 24 - 60 Hz
Output Video ....................................................................... HDMI 1.2/HDMI 1.3
Signaling Rate ................................................................. 2.25 gigabits per second
Input DDC Signal .................................................................... 5.0 volts p-p (TTL)
Input Video Signal ..................................................................... 0.5 – 1.0 volts p-p
Video Amplifier Bandwidth .................................................................... 255 MHz
Input Connectors ............................................. Four (4) HDMI type A connectors
Output Connectors ........... Two (2) HDMI type A connectors with locking screws
Supported Video Resolutions ............ 480i, 480p, 576i, 576p, 720p, 1080i, 1080p
Supported Audio ......... Dolby TrueHD 7.1, Dolby TrueHD 5.1, Dolby Digital 5.1
DTS-HD Master Audio 7.1, DTS-HD Master Audio 5.1,
Diagnostic .......................................................... Front panel input to output LEDs
Operating Temperature Range ................................................. -41 to 95 degrees F
Operating Humidity Range ............................................ 5 to 90% non-condensing
Included Accessories ............................................. One (1) 12 VDC power supply
Control ............................................ Front panel channel, RS232, IR and Ethernet
Dimensions ................................................................... 17.375" x 8.375" x 1.625"
Enclosure ............................................................................................. Black metal
Max Power Consumption ......................................................................... 11 watts
Power ........................................................................................................ 12 VDC
Regulatory ............................................................................................. CE, RoHS
Compatible Intelix Twisted Pair Receivers ............................. DIGI-HD-UHR2-R
Shipping Weight .......................................................................................... 7.1 lbs
Intelix Part Number ........................................................................ DIGI-HD-4X2
Warranty ..................................................................................................... 2 years
www.intelix.com
Two (2) dual twisted pair connectors
8, 10, 12 bits per channel
DTS 5.1, PCM 2.0, PCM 5.1
Front panel keylock LED
-5 to 35 degrees C
Two (2) 19" rack mounting ears
One (1) remote control
Four (4) shelf mount feet
(1) IR receiver
(4) IR emitters
DIGI-HD-IR2-R
1 RU
