The connection to an Intercomp S400 display is:
CS3000
TXD (F)
GND (B)
The connection to an Intercomp SA2000 display is:
CS3000
TXD (F)
GND (B)
The connection to a 9-pin PC communication port is:
CS3000
TXD (F)
GND (B)
Note: For some setups it may be necessary to jump pins [6, 1, and 4] together, and pins
[7 and 8] together on the PC port connector.
The connection to a 25-pin PC communication port is:
CS3000
TXD (F)
GND (B)
Note: For some setups it may be necessary to jump pins [6, 8, and 20] together, and
pins [4 and 5] together on the PC port connector.
S400
2 (RXD)
7 (GND)
SA2000
3
7
PC 9-pin
2
5
PC 25-pin
3
7
