Intercomp CS3000 User Manual page 16

The above diagram is the S400 switch pack layout, The SA2000 has pack C below B.
The switch is to the right for on and to the left for off.
Switch #
1
2
3
4
5
6
7
8
The above switches should be set on switch packs A, B, and C.
Pack C, SW 1 to 4:
Baud Rate C-1
9600 ON
4800 OFF
2400 ON
1200 OFF
600 ON
300 OFF
150 ON
75 OFF
Pack A Pack B
OFF OFF
ON
ON OFF
ON OFF
ON
OFF
OFF
ON
C-2 C-3
ON ON
ON ON
ON OFF
OFF ON
OFF OFF
ON OFF
OFF OFF
OFF ON
Page 16 of 35
Pack C
See next page
ON "
"
"
ON ON
ON ON
ON OFF
ON OFF
C-4
OFF
OFF
OFF
OFF
ON
OFF
OFF
ON
CS3000, Users
Rev A, January, 2011
