Set Up and Operation

Before plugging the unit in, always make sure that the power supply matches the product specification
voltage. Do not attempt to operate a 120V specification product on 230V power, or vice versa.
Remove all packing materials from the Compact Lightset. Check that all foam and plastic padding is
removed.
Always disconnect from electric mains power supply before cleaning or servicing.
Damages caused by non-observance are not subject to warranty.

Control Modes

There are 6 modes:
One Compact Lightset
1. Fasten the effect light
2. Plug the end of the electric mains power cord into a proper electric power supply socket.
3. When the Compact Lightset is not connected by a DMX-cable, it functions as a stand-alone device.
Please see page 13+14 for more information about the built-in programs.

One Compact Lightset (Sound-control)

1. Fasten the effect light
2. Plug the end of the electric mains power cord into a proper electric power supply socket.
3. Turn on the music. If device is set to
react to the beat of the music.
options.
Multiple Compact Lightsets
1. Fasten the effect light
2. Always use a safety cable (ordercode 70140 / 70141).
3. Use a 3-p XLR cable to connect the Compact Lightset.
The pins:
4. Link the units as shown in (Fig. 2), Connect a DMX signal cable from the first unit's DMX "out" socket to
the second unit's "in" socket. Repeat this process to link the second, third, and fourth units.
use the same functions on the master device as described on page 13+14 (Built-in Programs, Auto
Run, Static Color or
operation Mode and all slave devices will react the same as the master device.
5. Supply electric power: Plug electric mains power cords into each unit's IEC socket, then plug the
other end of the mains power cord into proper electric power supply sockets, starting with the first
unit. Do not supply power before the whole system is set up and connected properly.
• Built-in Programs
• Auto Run
• Static Color
• Sound-controlled
• Master/Slave
• DMX512
(Built-in Programs, Auto Run, Static
onto firm trussing Leave at least 1 meter on all sides for air circulation.
onto firm trussing Leave at least 1 meter on all sides for air circulation.
Please see page 13 for more information about the sound-control
(Master/Slave control)
onto firm trussing Leave at least 1 meter on all sides for air circulation.
1. Earth
2. Signal -
3. Signal +
Music control). This means on the master device you can set your desired
Multiple Compact Lightsets
Color)
(Audio) and you have pressed enter, then the fixture will
(Master/Slave control)
8
You can
Fig. 2
