Page 1: Operation Manual
CH-1601TXRX HDMI/Audio over CAT5e/6/7 Extender with 48V PoE Operation Manual Operation Manual... - Page 2 DISCLAIMERS The information in this manual has been carefully checked and is believed to be accurate. Cypress Technology assumes no responsibility for any infringements of patents or other rights of third parties which may result from its use. Cypress Technology assumes no responsibility for any inaccuracies that may be contained in this document.
-
Page 3: Safety Precautions
SAFETY PRECAUTIONS Please read all instructions before attempting to unpack or install or operate this equipment, and before connecting the power supply. Please keep the following in mind as you unpack and install this equipment: • Always follow basic safety precautions to reduce the risk of fire, electrical shock and injury to persons. -
Page 4: Table Of Contents
CONTENTS 1. Introduction ..........1 2. Applications ........... 1 3. Package Contents ........ 1 4. System Requirements ......1 5. Features ..........2 6. Operation Controls and Functions ..3 6.1 Transmitter’s Front Panel ....3 6.2 Transmitter’s Rear Panel ....4 6.3 Receiver’s Front Panel .....5 6.4 Receiver’s Rear Panel .....6 6.5 IR Cable Pin Assignment....7... -
Page 5: Introduction
1. INTRODUCTION This HDMI and Audio over Single CAT5e/6/7 Transmitter and Receiver set can send uncompressed audio/video along with controls, IP and USB data over a single run of CAT5e/6/7 cable up to 100m. It has the added benefit of control through the built-in RS-232 and IR ports and a bidirectional LAN serving connection. -
Page 6: Features
5. FEATURES • Supports HDBaseT 2.0 specification supporting over a single CAT6/7 cable up to 100m/328ft and CAT5e cable up to 90m/295ft • Fully compliant with HDMI 1.4, and compatible with HDMI 2.0 (4K2K 60Hz with 4:2:0) • Receiver features 2 USB 2.0 ports •... -
Page 7: Operation Controls And Functions
6. OPERATION CONTROLS AND FUNCTIONS 6.1 Transmitter’s Front Panel RS 232 IN IR IN 2 IR OUT 1 CAT5e/6/7 OUT DC 48V POWER RS-232 IN Connect to a PC or Laptop with D-Sub 9- pin female cable for the transmission of RS-232 commands. IR IN 2 Connect to the supplied IR Extender cable for IR signal reception. -
Page 8: Transmitter's Rear Panel
6.2 Transmitter’s Rear Panel HDMI IN COAX AUDIO IN OUT 1 IN 2 HDMI IN Connect to HDMI source equipment such as a DVD or Blu-ray player. Connect from PC or Laptop for data transmit to or control from the Receiver’s USB slots. -
Page 9: Receiver's Front Panel
6.3 Receiver’s Front Panel RS 232 OUT IR IN 1 IR OUT 2 CAT5e/6/7 IN POWER RS-232 OUT Connect to the device that is to be controlled (via D-Sub 9-pin male cable) by RS-232 commands. IR IN1 Connect to the supplied IR Extender cable for IR signal reception. Ensure that remote being used is within the direct line-of-sight of the IR Extender. -
Page 10: Receiver's Rear Panel
6.4 Receiver’s Rear Panel HDMI OUT COAX AUDIO OUT OUT 2 IN 1 POWER LINK 1 LINK 2 HDMI OUT Connect to a HDMI equipped TV/monitor for display of the HDMI input source signal. Connect to USB peripheral devices such as printer, keyboard, flash driver or …etc. -
Page 11: Ir Cable Pin Assignment
6.5 IR Cable Pin Assignment IR Blaster Power IR Blaster Signal IR Receiver IR Signal Power Grounding 6.6 D-Sub 9-Pin Assignment Define TX / RX TxD / RxD RxD / TxD... -
Page 12: Connection Diagram
7. CONNECTION DIAGRAM HDMI IN COAX AUDIO IN OUT 1 IN 2 HDMI DVD or Blu-ray Player Active Speakers DVD or Blu-ray Player 60° PC or Note Book 1.5m 1.5m RS232 Equipped HDMI Switcher 60° 60° IR Extender IR Blaster RS-232 Note Book RS 232 IN... -
Page 13: Specifications
8. SPECIFICATIONS Video Bandwidth 340MHz/10.2Gbps Transmitter Input Ports 1 x HDMI 1 x LAN, 1 x RS-232, 1 x IR, 1 x USB, 1 x Coaxial, 1 x L/R Output ports 1 x CAT5e/6/7, 1 x IR 1 x Coaxial Receiver Input Ports 1 x CAT5e/6/7, 1 x IR,... -
Page 14: Acronyms
Power Consumption 9. ACRONYMS ACRONYM COMPLETE TERM Digital Theater System Digital Visual Interface EDID Extended Display Identification Data HDCP High-bandwidth Digital Content Protectionl HDMI High-Definition Multimedia Interface HDTV High-Definition Television High-Definition Multimedia Interface Liquid Crystal Monitor Video Graphics Array WUXGA Wide Ultra Extended Graphics Array... - Page 15 CYPRESS TECHNOLOGY CO., LTD Home page: http://www.cypress.com.tw MPM-CH1601TXRX...
