- Page 1 CH-1109TXC & RXC HDMI to CAT5e/6 with LAN/PoE/IR Extender Operation Manual Operation Manual...
- Page 2 DISCLAIMERS The information in this manual has been carefully checked and is believed to be accurate. Cypress Technology assumes no responsibility for any infringements of patents or other rights of third parties which may result from its use. Cypress Technology assumes no responsibility for any inaccuracies that may be contained in this document.
-
Page 3: Revision History
PRECAUTIONS Please read all instructions before attempting to unpack, install or operate this equipment and before connecting the power supply. Please keep the following in mind as you unpack and install this equipment: • Always follow basic safety precautions to reduce the risk of fire, electrical shock and injury to persons. -
Page 4: Table Of Contents
CONTENTS 1. Introduction ..........1 2. Applications ..........1 3. Package Contents ........1 4. System Requirements ......1 5. Features ............ 2 6. Operation Controls and Functions ..3 6.1 Transmitter Front and Rear Panels ..3 6.2 Receiver Front and Rear Panels ..4 6.3 IR Cable Pin Assignment....5 6.4 D-Sub 9 Pin Definitions .......5 7. -
Page 5: Introduction
1. INTRODUCTION The device that can make your home or office more efficient, the CH-1109TXC & RXC is capable of sending HDMI (uncompressed audio/video), 3 Ethernet connections and control ports (through the built-in RS-232 and IR ports) over a single CAT5e/CAT6 up to a distance of 100m (300 ft.). -
Page 6: Features
5. FEATURES • HDMI 1.4 compliant with 3D formats and 4k×2k resolution support • Supports CEC bypass function • Simultaneous transmission of uncompressed video and audio (1080p@60Hz/-Deep Color) over a single CAT5e/6 type cable for up to 100 m (300 ft.). •... -
Page 7: Operation Controls And Functions
6. OPERATION CONTROLS AND FUNCTIONS 6.1 Transmitter Front and Rear Panels Rear Front HDMI DC 24V HDMI In Power Bypass Link IR 1 IR 2 Blaster Extender RS232 In LAN 1 LAN 2 LAN 3 CAT5e/6 Out Power LED: The red LED will illuminate when the 24 V DC Adaptor is connected to the AC outlet. -
Page 8: Receiver Front And Rear Panels
6.2 Receiver Front and Rear Panels Rear Front HDMI Out Power Link IR 1 IR 2 Extender Blaster RS232 Out CAT5e/6 In LAN 1 LAN 2 LAN 3 Power LED: The red LED will illuminate when the 24 V DC Adaptor is connected to the AC outlet. -
Page 9: Ir Cable Pin Assignment
6.3 IR Cable Pin Assignment IR Blaster Power 5 V IR Blaster Signal IR Receiver IR Signal Power 5 V Grounding 6.4 D-Sub 9 Pin Definitions Define TX/RX TxD / RxD RxD / TxD... -
Page 10: Connection Diagram
7. CONNECTION DIAGRAM Blu-ray/DVD Player PC with RS232 Control IR Blaster Modem/Router Media Server HDMI HDMI In Bypass Power LAN 1 LAN 2 LAN 3 Supply DC 24V Power Link IR 1 IR 2 Blaster Extender RS232 In CAT5e/6 Out Single CAT5e/6 RS232 Controlled Device... -
Page 11: Specifications
8. SPECIFICATIONS Video Bandwidth 300 MHz/9 Gbps Ethernet Speed 100 Mbps Transmitter Input 1×HDMI , 3×Ethernet 1×RS-232, 1×IR Extender Output 1×CAT5e/6, 1×HDMI Bypass, 1×IR Blaster Receiver Input 1×CAT5e/6, 1×IR Extender Output 1×HDMI, 1×RS-232 3 ×Ethernet, 1×IR Blaster HDMI In/Out Cable Up to 10 Meters Distance CAT6 In/Out Cable... -
Page 12: Acronyms
9. ACRONYMS ACRONYM COMPLETE TERM CAT6 Category 6 Cable HDMI High Definition Multimedia Interface... - Page 13 CYPRESS TECHNOLOGY CO., LTD Home page: http://www.cypress.com.tw...
