Page 1: Operation Manual
CH-110TX & CH-110RX HDMI & IR over CAT6 Extender Operation Manual Operation Manual... - Page 2 DISCLAIMERS The information in this manual has been carefully checked and is believed to be accurate. Cypress Technology assumes no responsibility for any infringements of patents or other rights of third parties which may result from its use. Cypress Technology assumes no responsibility for any inaccuracies that may be contained in this document.
-
Page 3: Safety Precautions
SAFETY PRECAUTIONS Please read all instructions before attempting to unpack, install or operate this equipment and before connecting the power supply. Please keep the following in mind as you unpack and install this equipment: • Always follow basic safety precautions to reduce the risk of fire, electrical shock and injury to persons. -
Page 4: Table Of Contents
CONTENTS 1. Introduction ..........1 2. Applications ........... 1 3. Package Contents ........ 1 4. System Requirements ......1 5. Features ..........2 6. Operation Controls and Functions ..3 6.1 Transmitter Front and Rear Panels ..3 6.2 Receiver Front and Rear Panels ..4 6.3 EQ Selection Chart ......4 7. -
Page 5: Introduction
1. INTRODUCTION The HDMI & IR Transmitter and Receiver over ONE CAT6 is a tool for extending your HDMI & IR signal over long distances to a compatible display. Instead of using expensive HDMI cables, your existing CAT6 cables/sockets can be utilized to perform functions like transferring 8 bits/ color video and new lossless compressed (Dolby TrueHD, Dolby Digital Plus and DTS-HD Master Audio) digital audio, with a bandwidth up to 165MHz. -
Page 6: Features
5. FEATURES • HDMI, HDCP and DVI compliant • Supports digital video formats with 3D at up to 24 bits (8 bits/color) • Supports LPCM 7.1Ch, Dolby TrueHD, Dolby Digital Plus and DTS-HD Master Audio transmission • Uses CAT6 cable for data/DDC transmission •... -
Page 7: Operation Controls And Functions
6. OPERATION CONTROLS AND FUNCTIONS 6.1 Transmitter Front and Rear Panels CAT6 OUT IR OUT HDMI IN DC 5V SERVICE IR OUT: Connect the IR Blaster cable included in the package for IR signal transmission. Pace the IR blaster in direct line-of-sight of the equipment to be controlled. -
Page 8: Receiver Front And Rear Panels
6.2 Receiver Front and Rear Panels CAT6 IN IR IN HDMI OUT DC 5V SERVICE MIN. MAX. IR IN: Connect to the IR Extender for IR signal reception. Ensure that remote being used is within the direct line-of-sight of the IR extender. -
Page 9: Connection Diagram
7. CONNECTION DIAGRAM DVD or Blu-ray Player 1.5m 60° CAT6 OUT IR OUT HDMI IN DC 5V SERVICE CAT6 IN IR IN HDMI OUT DC 5V SERVICE MIN. MAX. 1.5m 60° IR BLASTER 60° Display / Monitor IR Extender... -
Page 10: Specifications
8. SPECIFICATIONS Transmitter Input Ports 1 x HDMI, 1 Mini USB (for service only) Output Ports 1 x IR Blaster, 1 x CAT6 Receiver Input Ports 1 x IR Extender, 1 x CAT6, 1 x Mini USB (for ser- vice only) Output Ports 1 x HDMI HDMI Cable Distance... -
Page 11: Acronyms
9. ACRONYMS ACRONYM COMPLETE TERM Dolby Dolby Laboratories, Inc Digital Theater System... - Page 12 CYPRESS TECHNOLOGY CO., LTD Home page: http://www.cypress.com.tw MPM-CH110TXRX...
