Page 1: Operation Manual
CH-1527TXPL & RXPL HDMI over CAT5e/6/7 Extender with IR/RS-232/PoE Operation Manual Operation Manual... - Page 2 DISCLAIMERS The information in this manual has been carefully checked and is believed to be accurate. Cypress Technology assumes no responsibility for any infringements of patents or other rights of third parties which may result from its use. Cypress Technology assumes no responsibility for any inaccuracies that may be contained in this document.
-
Page 3: Safety Precautions
SAFETY PRECAUTIONS Please read all instructions before attempting to unpack, install or operate this equipment and before connecting the power supply. Please keep the following in mind as you unpack and install this equipment: • Always follow basic safety precautions to reduce the risk of fire, electrical shock and injury to persons. -
Page 4: Table Of Contents
CONTENTS 1. Introduction ..........1 2. Applications ........... 1 3. Package Contents ........ 1 4. System Requirements ......1 5. Features ..........2 6.1 Transmitter Front and Rear Panels ..3 6.2 Receiver Front and Rear Panels ..4 6.3. IR Cable Pin Assignment....5 6.4. -
Page 5: Introduction
1. INTRODUCTION The HDMI over single CAT5e/6/7 Transmitter and Receiver set can send uncompressed audio/video and IP data over a single run of CAT5e/6/7 cable at a distance up to 60 meter. It has the added benefit of control through the built-in RS-232 and IR ports. The Receiver (PD) can be powered by the PoE 48V function of the Transmitter (PSE), allowing for greater flexibility in installations. -
Page 6: Features
5. FEATURES • HDMI with 3D, 4K2K support, HDMI & DVI Compliant • Supports CEC bypass • Simultaneous transmission of uncompressed data over a single CAT5e/6/7 cable up to 60m • 4Play™ convergence: HDMI, PoE & Control (IR & RS-2232) •... -
Page 7: Transmitter Front And Rear Panels
3. 6. OPERATION CONTROLS AND FUNCTIONS 6.1 Transmitter Front and Rear Panels Front Rear RS-232 IN POWER BLASTER STD UPDATE HDMI IN LINK DC 48V EXTENDER DC 48V: Plug the 48V DC power supply into the unit and connect the adaptor to an AC outlet. IR1 BLASTER: Connect to the supplied IR Blaster cable for IR signal transmission. -
Page 8: Receiver Front And Rear Panels
6.2 Receiver Front and Rear Panels Front Rear RS-232 OUT POWER BLASTER STD UPDATE HDMI OUT EXTENDER LINK IR2 BLASTER: Connect to the supplied IR Blaster cable for IR signal transmission. Place the IR Blaster in direct line-of-sight of the equipment to be controlled. -
Page 9: Ir Cable Pin Assignment
6.3. IR Cable Pin Assignment IR Blaster Power IR Blaster Signal IR Signal IR Extender Power Grounding 6.4. D-Sub 9 Pin Definitions Define TX / RX TxD / RxD RxD / TxD... -
Page 10: Connection Diagram
7. CONNECTION DIAGRAM RS-232 Equipped PC or Notebook 1.5m 60° DVD or Blu-ray Player RS-232 IR Blaster Power Supply RS-232 IN POWER STD UPDATE HDMI LINK BLASTER 60° HDMI IN DC 48V EXTENDER IR Extender IR Extender 60° BLASTER HDMI OUT TV or Monitor IR Blaster EXTENDER... -
Page 11: Specifications
8. SPECIFICATIONS Video Bandwidth 340MHz / 10.2Gbps Transmitter Inputs 1 x HDMI 1 x IR Extender 1 x RS-232 Outputs 1 x CAT5e/6/7 1 x IR Blaster Receiver Inputs 1 x CAT5e/6/7, 1 x IR Extender Outputs 1 x HDMI, 1 x RS-232, 1 X IR Blaster HDMI I/O Resolution HD: 480i~4K2K@24/25/30 &... -
Page 12: Cat5E/6/7 Cable Specification
Power Consumption 15w (Max) Operating 0 °C~40 °C/32 °F ~104 °F Temperature Storage Temperature −20 °C~60 °C/−4 °F~140 °F Relative Humidity 20~90 % RH (non-condensing) 8.1 CAT5e/6/7 Cable Specification Cable Range Pixel clock Video Data Supported Video Type rate Rate CAT5e/6/7 60 m <=225 MHz... -
Page 13: Acronyms
4096x2160p@50/60(YUV_420) 480I/576I 480P/576P 720P@50/60 1080I@50/60 1080P@50/60 1080P@24/25/30 9. ACRONYMS ACRONYM COMPLETE TERM CAT5e Category 5 Cable CAT6 Category 6 Cable CAT7 Category 7 Cable Consumer Electronics Control Digital Visual Interface HDCP High-bandwidth Digital Content Protection HDMI High Definition Multimedia Interface Infrared Powered Device Power Sourcing Equipment... - Page 14 CYPRESS TECHNOLOGY CO., LTD Home page: http://www.cypress.com.tw MPM-CH1527TXRXPL...
