◇ W eight: 5Kgs
◇ D imension: 830 × 1 71 × 2 02mm
3. H ow T o S et T he U nit
3.1 C ontrol P anel
1. F USE ( T 6 .3A):
P rotects t he u nit f rom o ver-­‐voltage o r s hort c ircuit
2. P OWER I N/OUT:
3. D MX I N/OUT:
D MX512 l ink, u se 3 -­‐pin X LR c able t o l ink t he u nit a nd t he D MX c ontroller
4. D ISPLAY:
S hows t he v arious m enus a nd t he s elected f unctions.
5. L ED:
a. D MX
b. M ASTER
c. S LAVE
d. S OUND
6. B UTTON:
C onnects t o p ower s upply.
On
On
On
Flashing
DMX i nput p resent
Master M ode
Slave M ode
Sound a ctivation
4
