Declaration of Conformity
We declare that our products (lighting equipments) comply with the
following specification and bears CE mark in accordance with the provision
of the Electromagnetic Compatibility (EMC) Directive 89/336/EEC.
EN55103‐1: 2009 ; EN55103‐2: 2009; EN62471: 2008;
EN61000‐3‐2: 2006 + A1:2009 + A2:2009; EN61000‐3‐3: 2008.
&
Harmonized Standard
EN60598‐2‐17:1989 + A2:1991; EN60598‐1:2008+ A11: 2009
EN 62471:2008; EN 62493: 2010
Safety of household and similar electrical appliances
Part 1: General requirements
VI‐10QW
User Manual
Please read the instructions carefully before use
Innovation, Quality, Performance
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for ACME V Inground VI-10QW
Summary of Contents for ACME V Inground VI-10QW
- Page 1 Declaration of Conformity We declare that our products (lighting equipments) comply with the following specification and bears CE mark in accordance with the provision of the Electromagnetic Compatibility (EMC) Directive 89/336/EEC. EN55103‐1: 2009 ; EN55103‐2: 2009; EN62471: 2008; EN61000‐3‐2: 2006 + A1:2009 + A2:2009; EN61000‐3‐3: 2008. & Harmonized Standard EN60598‐2‐17:1989 + A2:1991; EN60598‐1:2008+ A11: 2009 EN 62471:2008; EN 62493: 2010 Safety of household and similar electrical appliances Part 1: General requirements VI‐10QW User Manual Please read the instructions carefully before use Innovation, Quality, Performance...
-
Page 2: Troubleshooting
8. Troubleshooting TABLE OF CONTENT If the fixture does not work, no light, please check the connection of power cable and signal line, also measure the mains voltage on the main connector. 8. Cleaning And Maintenance 1. Safety Instructions ......................... 2 The cleaning must be carried out periodically to optimize light output. Cleaning frequency depends 2. Features ............................ 3 on the environment in which the fixture operates: moist, smoky or particularly dirty surrounding 3. Technical Specifications ......................... 3 can cause greater accumulation of dirt on the fixture. 4. Installation ............................ 4 Clean with lint‐free cloth using normal glass cleaning liquid. 5. Lumen Output .......................... 6 Always dry the parts carefully. 6. How To Control The Fixture ...................... 9 Clean the surface at least every 30 days. 7. DMX512 Configuration ........................ 9 8. Troubleshooting .......................... 10 8. -
Page 3: How To Control The Fixture
6. How To Control The Fixture 1. Safety Instructions Please operate the fixture by VD‐T (sold separately). VD‐T is a specially designed handy setup tool Please read the instructions carefully which includes important for all Visio integral fixtures and controllers. By connecting VD‐T to any fixture via XLR, you can information about the installation, operation and maintenance. easily setup DMX Address, Channel Modes, White Balance, Manual Colors, and Fade Speed WARNING Please keep this User Guide for future consultation. If you sell the fixture to another user, be ... -
Page 4: Technical Specifications
Avoid power wires together arounding other cables. Lumens: 255.789lm Replace fuse only with the same type. Efficacy:14.29lm/W In the event of serious operating problem, stop using the fixture immediately. Beam Angle: 30° Never turn on and off the fixture time after time. Luminous Intensity Distribution Zonal Flux Diagram The housing, the lenses, or the ultraviolet filter must be replaced if they are visibly damaged. Do not open the fixture as there are no user serviceable parts inside. Never try to repair the fixture by yourself. Repairs carried out by unskilled people can lead to damage or malfunction. Please contact the nearest authorized technical assistance center. Disconnect the mains power if the fixture is not used for a long time. Do use original packing materials once transport it again. Do not look directly at the LED light beam while the fixture is on. To protect the machine, power off 10s rear can electrify. ... -
Page 5: Installation
Lumens: 263.372lm 4. Installation Efficacy: 13.30lm/W Beam Angle: 20° 4.1 Before install the fixture, please ensure the power is off. 4.1.1 Choose the appropriate location and secure the embedded fittings (plastic sleeve) to the location, then connect power cable and signal line, finally place the aluminum barrel into it. Signal line Power cable 4.1.2 Run power cable and DMX signal line to junction box (sold separately), there are two colors red and black for power cable, red cable is positive, black cable is grounding. Three colors red, white and black for signal line, red line is (+), white line is (‐) and black line is grounding. ... - Page 6 5. Lumen Output 4.3 Connection Diagram Lumens: 299.35lm Efficacy: 20.65lm/W Beam Angle: 10° ...
