- Page 1 DELUGE LED-WAV-50W User Manual Please read the instructions carefully before use Innovation, Quality, Performance...
- Page 2 particularly dirty surrounding can cause greater accumulation of dirt on the fixture’s optics. Clean with soft cloth using normal glass cleaning fluid. Always dry the parts carefully. Clean the external optics at least every 20 days. Clean the internal optics at least every 30/60 days.
- Page 3 3 pin XLR connectors are more popular than 5 pins XLR. TABLE OF CONTENTS 3 pin XLR: Pin 1: GND, Pin 2: Negative signal (-), Pin 3: Positive signal (+) 5 pin XLR: Pin 1: GND, Pin 2: Negative signal (-), Pin 3: Positive signal (+), Pin4/5: not used 1.
- Page 4 1. Safety Introductions 6. DMX512 Connections Please read the instructions carefully which includes important The DMX512 is widely used in intelligent lighting control, with a maximum of 512 channels. information about the installation, operation and maintenance. WARNING Please keep this User Guide for future consultation. If you sell the unit to another user, be sure that they also receive this instruction booklet.
- Page 5 Do not allow children to operate the fixture. 4.3 DMX Controller Do not touch any wire during operation as there might be a hazard of electric shock. Avoid power wires together around other cables. Use universal DMX controller to control the units, you have to set DMX address from 1 to Disconnect mains power before fuse/lamp replacement or servicing.
- Page 6 3. How To Set The Fixture 4. How To Control The Unit 3.1 Control Panel You can operate the unit in three ways: 1. By master/slave built-in preprogram function 2. By easy controller 3. By DMX controller No need to turn the unit off when you change the DMX address, as new DMX address setting will be effected at once.
- Page 7 ○ (000-2555,clockwise/counterclockwise), or 4 Only for remote control: Connecting with CA-8/UC3 to control the unit for (125-255),press ENTER button to confirm and use DOWN and UP button to adjust the value, once select press ENTER Stand by, Function and Mode function button to setup or automatically exit menu mode without any change after one minute.
- Page 8 3.3 Main Function DMX 512 Address Setting To select any functions, press MENU button until the required one is shown on the display. Press the MENU button up to when the is shown on the display. Pressing ENTER Select the function by ENTER button and the display will blink. Use DOWN and UP button to button and the display will blink.
