Figure 11-87. CS8.5 (spec. 92xxxx), CS10, CS12.
Governor Lever Installation.
3. Connect the throttle link and the shorter end of
dampening spring, from the top down, into the
hole(s) in long end of governor lever as shown in
Figures 11-86, 11-87, and 11-88.
Figure 11-88. CS8.5 (spec. 95xxxx), CS10, CS12.
Governor Linkage Connected to Governor Arm.
Model
CS4 All models
CS6 All models except listed
specs.
CS6 Specs: 911510
CS8.5 All models except listed
specs.
CS8.5 Spec: 921509
CS8.5 Spec: 951511
CS10 All models except listed
specs.
CS10 Specs: 931512, 931612
931614, 931615
CS10 Spec: 931618
Figure 11-90. CS8.5 (spec. 92xxxx), CS10, CS12.
Spring Hole Position.
Figure Hole
Number Position
11-89 2
11-89 1
11-89 2
11-90 3
Figure 11-91. CS8.5 (spec. 95xxxx). Spring Hole
Position.
11-90 1
11-90 2
11-90 3
11-91 4
11-91 2
Figure 11-89. CS4, CS6. Spring Hole Position.
