WARNING:
The following instructions show how to open the OWC Mercury Pro Optical
!
enclosure and install an optical drive. If you purchased your OWC Mercury
Pro Optical as a preconfigured solution with an optical drive already installed,
opening the enclosure will
NOTE: You can find the installation video for this product on the OWC installation videos
web page:
1. To open the OWC Mercury Pro Optical, first remove the top two Phillips screws at the
rear of the enclosure, circled below in red. If you are assembling an OWC Mercury Pro
Optical that was purchased as an empty enclosure kit, these two screws have already
been removed.
2. Separate the top case from the bottom case by sliding the top case toward the rear
of the enclosure, as shown below. This may take a degree of force, as the connection
between the two halves is snug. Once the top case has moved back as far as it will go,
lift up to remove it and set it aside.
OWC MERCURY PRO OPTICAL

ASSEMBLY

http://www.macsales.com/installvideos
VOID YOUR WARRANTY.
3
ASSEMBLY
