Device Setup; Assembly - OWC EXPRESS 4M2 Assembly Manual & User Manual

DEVICE SETUP

2.1 Assembly

Please follow the instructions below to install one or more M.2 SSDs into the OWC Express
4M2 enclosure. If you have any concerns please
1. Remove the Express 4M2 from its packaging then loosen
the two thumbscrews on the back of the device until they
spin freely.
2. Holding the front cover, carefully slide the
inner chassis out of the outer enclosure.
3. Set the outer enclosure aside. Notice there is a fan
housing affixed to the inner chassis; this covers the area
where SSDs are installed, so it will need to be removed
temporarily. Set the inner chassis on your work surface so
the fan is facing upward before proceeding to Step 4.
OWC Express 4M2
contact our technical support
3
team.
Device Setup
