2.1 Quick Start

Follow the steps below to use the OWC Drive Guide utility to format your Elite Pro
Dual for Mac (OS X 10.4 and later) or Windows (XP and later). If you installed your
own drives, please use the formatting method you are most familiar with or check
Section 3.1 for a link to our online formatting tips.
1. Power on the Elite Pro Dual and plug it into to your computer using the proper data
cable. If you prefer to use a different formatting utility, do so at this time and skip
the rest of these steps.
2. The disk will mount and your operating system will display it as "OWC SETUP".
Open the disk icon to view its contents.
3. Double-click the OWC Drive Guide application.
4. Follow the simple on-screen instructions to complete the formatting process.
Once the formatting is finished the drive is ready to use.

2.2 Assembly

NOTE: these assembly instructions are written for users who purchased the Elite Pro
Dual as an empty enclosure. The instructions show how to open the Elite Pro Dual in
order to change the RAID settings and install drives. If you purchased the Elite Pro
Dual with drives already installed, opening the Elite Pro Dual before the expiration
of the original warranty will
drives after the expiration of the original warranty, you may do so at that time.
1. Remove the Elite Pro Dual from the retail box and the protective plastic bag. Set
the Elite Pro Dual on its side and look at the bottom of the enclosure. Use a Phillips
screwdriver to remove the two screws, as circled below in red.
OWC MERCURY ELITE PRO DUAL

DEVICE SETUP

the warranty. If you wish to remove or replace the
VOID
4
DEVICE SETUP
