Connecting To A Power Source; Figure 14: Power Inlet - Edge-Core SMCGS26C-Smart Installation Manual

C
ONNECTING TO A
To connect a switch to a power source:
Insert the power cable plug directly into the AC inlet located at the back of
1.
the switch.

Figure 14: Power Inlet

Plug the other end of the cable into a grounded, 3-pin, AC power source.
2.
For International use, you may need to change the AC line cord.
N :
OTE
You must use a line cord set that has been approved for the wall socket
type in your country.
Check the front-panel LEDs as the device is powered on to be sure the
3.
Power LED is on green. If not, check that the power cable is correctly
plugged in.
P S
OWER OURCE
– 40 –
| Installing the Switch
C 3
HAPTER
Mounting
