| Installing the Switch
C 3
HAPTER
Mounting
D S
ESKTOP OR HELF
Attach the four adhesive feet to the bottom of the first switch.
1.

Figure 13: Attaching the Adhesive Feet

Set the device on a flat surface near an AC power source, making sure there
2.
are at least two inches of space on all sides for proper air flow.
If installing a single switch only, go to
3.
page 40.
If installing multiple switches, attach four adhesive feet to each one. Place
4.
each device squarely on top of the one below, in any order.
M
OUNTING
– 39 –
"Connecting to a Power Source" on
