1
I
NTRODUCTION
O
VERVIEW
The SMCGS26C-Smart is a Gigabit Ethernet Layer 2 switch with 24 10/100/
1000BASE-T ports, and 2 Small Form Factor Pluggable (SFP) transceiver slots,
(see "Front Panel" on page 22, Ports 9-10).
The switch also includes an SNMP-based management agent, which provides in-
band access for managing the switch.
The switch provides a broad range of powerful features for Layer 2 switching,
delivering reliability and consistent performance for your network traffic. It
brings order to poorly performing networks by segregating them into separate
broadcast domains with IEEE 802.1Q compliant VLANs, and empowers
multimedia applications with multicast switching and CoS services.

Figure 1: Front Panel

Reset Button
System Indicators
Port Status Indicators
1000BASE-T/SFP Ports
10/100/1000 Mbps RJ-45 Ports

Figure 2: Rear Panel

– 22 –
