| Introduction
C 1
HAPTER
Overview

Table 2: Port Status LEDs

LED
RJ-45 Gigabit Ethernet Ports (Ports 1-24)
LINK/ACT
SFP Gigabit Ethernet Ports (Ports 25-26)
(LINK/ACT)

Table 3: System Status LEDs

LED
PWR
DIAG
P S
OWER UPPLY
There is one power inlet on the rear panel of the switch. The standard power
inlet is for the AC power cord.
Condition Status
On/Flashing Port has established a valid 10/100 Mbps network
Amber connection. Flashing indicates activity.
On/Flashing Port has established a valid 1000 Mbps network
Green connection. Flashing indicates activity.
Off There is no valid link on the port.
On/Flashing Port has established a valid 100 Mbps network
Amber connection. Flashing indicates activity.
On/Flashing Port has established a valid 1000 Mbps network
Green connection. Flashing indicates activity.
Off There is no valid link on the port.
Condition Status
On Green The unit's internal power supply is operating normally.
Off The unit has no power connected.
On Green The system diagnostic test has completed successfully.
On Amber Internal error is detected when sysetem is booting.
Off The system diagnostic has completed.
I
NLET
– 25 –
