Jumpers - DFI AD77 INFINITY User Manual

1
Quick Setup Guide

1.3 Jumpers

1.3.1 Clear CMOS Data - JP3
1.3.2 CNR Settings - JP7
10
1
1-2 On:
Normal (default)
1
2-3 On:
Clear CMOS Data
1 2 3
Clear CMOS
(JP3)
1-2 On:
Secondary (default)
2-3 On:
Primary
1 2 3
CNR setting
(JP7)
2 3
2 3
1 2 3
1 2 3
