1.5.7 PnP/PCI Configurations
Reset Configuration Data
Resources Controlled By
X IRQ Resources
PCI/VGA Palette Snoop
* PCI IRQ Assignment *
Slot 1,5
Slot 2
Slot 3
Onboard USB/Slot 4
↑↓→← Move
Enter:Select
F5:Previous Values
The settings on the screen are for reference only. Your version may not be
identical to this one.

1.5.8 PC Health Status

CPU Fan Protection
CPU Temp. Prot. Function
X CPU Temp. Prot. Alarm
Current System Temp.
Current CPU Temperature
Current CPU FAN Speed
Current Chassis FAN Speed
CPU(V)
+3.3 V
+5 V
+12 V
-12 V
-5 V
VBAT(V)
5VSB(V)
Shutdown Temperature
↑↓→← Move
Enter:Select
F5:Previous Values
The settings on the screen are for reference only. Your version may not be
identical to this one.
Phoenix - AwardBIOS CMOS Setup Utility
PnP/PCI Configurations
Disabled
Auto(ESCD)
Press Enter
Disabled
Auto
Auto
Auto
Auto
+/-/PU/PD:Value F10:Save
F6:Fail-Safe Defaults
Phoenix - AwardBIOS CMOS Setup Utility
PC Health Status
Disabled
Disabled
60
27C/80F
37C/98F
0 RPM
0 RPM
1.75 V
3.35 V
4.90 V
11.85 V
-11.45 V
-5.14 V
3.24 V
5.37 V
Disabled
+/-/PU/PD:Value
F10:Save
F6:Fail-Safe Defaults
Quick Setup Guide
Item Help
Menu Level
Default is Disabled.
Select Enabled to
reset Extended System
Configuration Data
(ESCD) when you exit
Setup if you have
installed a new add-on
and the system
reconfiguration has
caused such a serious
conflict that the OS
cannot boot.
ESC:Exit F1:General Help
F7:Optimized Defaults
Item Help
Menu Level
ESC:Exit F1:General Help
F7:Optimized Defaults
