1.4 Real Panel I/O Ports
1.4.1 PS/2 Mouse and PS/2 Keyboard Ports
J3
PS/2 Mouse
PS/2 Keyboard
Make sure to turn off your
computer prior to connecting or
disconnecting a mouse or keyboard.
Failure to do so may damage the
system board.
1.4.2 Serial Ports
J2
J1
COM 1
COM 2
Serial Port
Serial Port
13
