1
Quick Setup Guide

1.2 Jumpers

1.2.1 Clear CMOS Data - JP9
1.2.2 Onboard Audio Codec - JP5 and JP6
If you are not using the onboard audio codec, set pins 2 and 3 to On
(Disabled) and set the "VIA-3058 AC97 Audio" ("VIA OnChip PCI
Device" field) in the Integrated Peripherals submenu of the BIOS to
Disabled.
8
3
1-2 On:
2
Normal (default)
1
Clear
3
CMOS
2
(JP9)
1
3
2-3 On:
2
Clear CMOS Data
1
JP5 JP6
3
2
1
JP5 JP6
3
2
1
JP5
Audio
codec
3
2
setting
1
(JP5 & JP6)
JP6
1-2 On:
Enable the Onboard
Audio Codec
(default)
2-3 On:
Disable the Onboard
Audio Codec
