1
Quick Setup Guide
1.4.7 Game/MIDI Port and Audio Jacks
1.4.8 S/PDIF-out Connector
1 AVDD5
2 N. C.
3 SPDIF-out
4 Ground
5 SPDIF-in
16
Mic-in
Line-in
Line-out
2
15
1
Game/MIDI (J20)
Front Audio (J7)
1 Mic+
3 Mic Power
5 AuD_R_Out 6 AuD_R_Return (GND)
7 N. C.
9 AuD_L_Out
1 2 3 4 5
S/PDIF-in/out
(J32)
CN1
2 10
1 9
2 Ground
4 AuD_Vcc (Avcc)
8 Key
10 AuD_L_Return (GND)
2
10
1
9
Front audio
(J7)
