- Page 1 1x8 HDMI v1.3 Splitter #15109 Operation Manual...
- Page 2 Introduction With eight HDMI outputs and capable of distributing 3D content the HDMI v1.3 1 by 8 splitter is a forward looking device that helps you handle futuristic technology today. Compatible with HDMI v1.3 which defines the ability to transfer 3D content, Deep Color (10-bit and 12-bit) video and new lossless compressed (Dolby TrueHD, Dolby Digital Plus and DTS-HD Master Audio) digital audio, this device doesn’t merely handle splitting and distributing, far from it, it also amplifies and equalizes...
- Page 3 Operation Controls and Functions Front Panel 1. HDMI OUT 7/8/1: Using HDMI cables connect these slots to displays in order to show HDMI/3D content. Note: When the input signal contains 3D data the display must support 3D content in order to display an image. A.
- Page 4 1080p@60/12bits for video and LPCM 2Ch for audio, to allow the source to send a signal to the connected displays. 2. HDMI OUT 2~6: Using HDMI cables connect these slots to displays in order to show HDMI/3D content. Note: When the input signal contains 3D data the display must also have 3D support in order to receive the signal.
- Page 5 Connection and Installation...
