Qvis MINI-PTZ-23X-H User Manual

23x zoom analogue ptz camera
Hide thumbs
Table of Contents

Advertisement

Quick Links

MINI-PTZ-23X-H
23X ZOOM ANALOGUE PTZ CAMERA
User's Manual
V1.0 10 / 2013

Advertisement

Table of Contents
loading

Related Manuals for Qvis MINI-PTZ-23X-H

Summary of Contents for Qvis MINI-PTZ-23X-H

  • Page 1 MINI-PTZ-23X-H 23X ZOOM ANALOGUE PTZ CAMERA User’s Manual V1.0 10 / 2013...

  • Page 3: Table Of Contents

    Table of Contents FEATURES AND FUNCTIONS ....................1 General Introduction ............................1 Features ................................1 1.2.1 On-Screen Menu ............................. 1 1.2.2 Proportional Pan and Tilt ..........................1 1.2.3 On-screen Tips ..............................1 1.2.4 Preset Setup and Call ............................1 1.2.5 Auto Scan ................................
  • Page 4 Combination Cable Connection........................20 FAQ ............................21 Daily Maintenance ............................21 Problems and Solutions ..........................21...
  • Page 5 Welcome Thank you for purchasing the MINI-PTZ-23X-H PTZ camera. This user’s manual is designed to be a reference tool for the installation and operation of your system. Here you can find information about the corresponding IP camera’s features and functions, as well as a detailed installation method.

  • Page 6: Important Safeguards And Warnings

    Important Safeguards and Warnings 1．Electrical safety  All installation and operation here should conform to your local electrical safety codes.  We assume no liability or responsibility for all the fires or electrical shock caused by improper handling or installation. ...
  • Page 7  If there is too much dust, please use the water to dilute the mild detergent first and then use it to clean the device. Finally use the dry cloth to clean the device. 6. About Accessories Always use all the accessories recommended by manufacturer. Before installation, please open the package and check that all the components are included in the package.

  • Page 8: Features And Functions

    1 Features and Functions 1.1 General Introduction This 4-inch analogue intelligent PTZ dome camera not only gives you 23X optical zoom but also the ability to digitally zoom in to the video footage up to 16X, to scrutinise far away objects much more closely. It adopts a new configuration design and is easy to install during project construction.

  • Page 9: Auto Touring

    1.2.6 Auto Touring Add addresses into a routine in a desired order and then set time and stop duration for each address. The dome will begin an auto touring between these addresses. Each touring path can contain max 32 presets. 1.2.7 Auto Pattern Memorises dome operations such as pan, tilt, and zoom to repeat.

  • Page 10: Intelligent Location

    1.2.15 3D Intelligent Location It supports the 3D intelligent positioning function, where the camera can auto track to the specified zone. 1.2.16 Idle Status When there is no available order, you can use menu to set dome idle status after specified duration. 1.2.17 Image Stabilizer/Flip You can enable image stabiliser function and flip in the menu.

  • Page 11: Menu

    2 Menu 2.1 Screen Menu Index Note: ERR means current setup is invalid; you need to restores speed dome factory default setup. Slight difference may be found due to different series. SYSTEM SETTING SYSTEM INFORMATION ADDR INFORMATION SET NORTH LANGUAGE FACTORY DEFAULT RESTART BACK...

  • Page 12: Self-Diagnosis System Information

    Note:  ERR means current setup is invalid.  Please make sure all the cable connections are correct. 2.2 Self-diagnosis System Information ：001-H ADDR ：9600 BAUD RATE ：NONE PARITY ：V1.03.0.RHAJDV SOFTWARE BACK EXIT After installation, please connect speed dome to power. The system goes on a self-diagnosis routine, and then it pops up the above interface to show the system information.

  • Page 13: Menu Operation

     FUNCTION SETTING: Set preset, pan, scan, auto cruise, pattern, idle function, time task and privacy mask function.  ALARM SETTING：Set dome alarm number, action, contact, replay out, reset time, etc.  EXIT: Log out of the system menu. 2.4 Menu Operation In the PTZ camera main menu, you can use the left/right button on the keyboard or in the camera’s terminal menu to configure the system menu.

  • Page 14: Display Setting

    2.4.1.1 System information ： 001-H ADDR ：9600 BAUD RATE ：NONE PARITY ：V1.03.0.RHAJDV SOFTWARE BACK EXIT Move the cursor to SYSTEM INFORMATION and then click the confirm button, you will see the above interface. Here you can view the dome’s basic information. 2.4.1.2 Address Information ：HARD ADDR TYPE...

  • Page 15: Camera Setting

     AZIMUTH DISP: Displays the cameras current coordinates or not. Please use the left/right button on the keyboard or in the speed dome terminal menu to set  POSITION: Displays the angle between the benchmark and then current location. Please use the left/right button on the keyboard or in the speed dome terminal menu to set.
  • Page 16  NEXT PAGE: This includes the following options: DIGITAL ZOOM, PICTURE FLIP, FREEZE FUNCTION, CAMERA FACTORY DEFAULT SETUP and CAMERA RESTART. Please use the left/right button on the keyboard or in the speed dome terminal menu to set.  BACK: Go back to previous menu. ...
  • Page 17  SHUTTER: Please use the left/right button on the keyboard or in the speed dome terminal menu to set.  IRIS SETTING: Please use the left/right button on the keyboard or in the speed dome terminal menu to set.  EXPOSURE COM: Please use the left/right button on the keyboard or in the speed dome terminal menu to set.
  • Page 18 2.4.3.4 Day/Night Setting Move the cursor to DAY/NIGHT SETTING and then click confirm button, you can then go to the submenu. ： AUTO DAY/NIGHT ： 05 THRESHOD BACK EXIT  DAY/NIGHT: Please use the left/right button on the keyboard or in the speed dome terminal menu to set. ...

  • Page 19: Function Setting

    2.4.3.6 Next Page Move the cursor to NEXT PAGE and then click confirm button, you can go to the submenu. ： OFF DIGITAL ZOOM ：OFF PICTURE FLIP ： OFF FREEZE FUNC CAMERA FACTORY DEFAULT CAMERA RESTART BACK EXIT  DIGITAL ZOOM: You can use the left/right button to enable/disable the digital zoom function. ...
  • Page 20  NEXT PAGE: This includes: PRIVACY MASKING, PTZ SPEED, SET ZERO, POWER UP, MENU PASSWORD, MENU IDEL, PTZ AUTO STOP, and HEATER. Move the cursor to the item and then click the confirm button to set. .  BACK: Go back to previous menu. ...
  • Page 21 2.4.4.2 Pan ：5 PAN SPEED CALL STOP BACK EXIT Move the cursor to PAN button and then click confirm button to go to setup interface.  PAN SPEED: Set dome rotation speed. Please use the left/right button on the keyboard or in the speed dome terminal menu to set.
  • Page 22 2.4.4.4 Tour ： 1 TOUR NO： TOUR SETTING DELETE TOUR CALL STOP BACK EXIT Move the cursor to highlight TOUR item and then click confirm button to go to set interface.  TOUR NO ：This is to set the tour number. Please use the left/right button on the keyboard or in the speed dome terminal menu to set.
  • Page 23 2.4.4.5 Pattern ： PATTERN NO PROGRAM START PROGRAM STOP CALL STOP BACK EXIT The Pattern function can store a PTZ operation to the camera’s memory, which can include when you need camera to focus zoom either in or out. From the start position, the camera begins auto movement repeatedly. ...
  • Page 24  IDLE TIME: System idle period. Please use the left/right button on the keyboard or in the speed dome terminal menu to set.  IDLE MOTION：There are five functions you can select: NONE/PRESET/SCAN/TOUR/PATTERN. Please use the left/right button on the keyboard or in the speed dome terminal menu to set. ...
  • Page 25 Note:  For security reasons, please set privacy zone a little bit larger than the privacy object size.  Each time, after modifications you need to move the cursor to SAVE button and then click confirm button to get all setup activated. Otherwise, privacy zone may not move correspondingly with the object. 2.

  • Page 26: Alarm Setup

     PARAMTER: Here you can set the serial number of the corresponding operation such as the scan, preset, pattern, tour. Please use the left/right button to set.  BACK: Go back to the previous menu.  EXIT: Log out the system menu. 2.4.5 Alarm Setup ：1 ALARM NO...

  • Page 27: Cable Connection

    3 Cable Connection 3.1 Combination Cable Connection The camera’s combination cable includes network, audio/video cable port, RS485 connection port, alarm input and output port connectors. Please refer to the label for detailed information.  Please note the Internet Explorer 6 does not support alarm upload function. Please use Internet Explorer 7 or higher.

  • Page 28: Daily Maintenance

    4 FAQ 4.1 Daily Maintenance Please clean dome cover regularly to get continue to receive vivid images. Handle the cover with care. Use water to wash. Don’t use cloth to clean. Use mild detergent to clean if there is too much dust. Note: The sweat from your hand may erode plating surface, your nail may scrape dome cover resulting in blur image.
  • Page 29 For more information about our DVRs and available cameras & accessories, please visit our website: www.adata.co.uk Alternatively scan this QR code with your smart phone to be directed instantly to our website:...
